Content Application ....................3 Features ....................3 III. Technical Parameter ................4 Dimension ....................5 Installation instruction ................6 Operation instruction ................10 VII. Testing ....................14 VIII. Precautions ..................15 Maintenance ..................16 Trouble shooting for common faults ..........17 WI-FI SETTING ...................
Page 3
Not following such indications can cause damage to the heat pump or any user of the product. If any questions arise at any point, please reach out to the technical service team at Moov Pool Products.
Page 4
The recommended heating temperature is 85’F. The unit can work above and below this recommendation up to a specific capacity depending on operating conditions. Please contact Moov for more information. C. Don’t put obstacles near the air inlet and outlet of the heat pump.
Moov Pool Products directly. Do not try to repair the heat pump yourself. Application 1- Set swimming pool water temp efficiently and economically to provide you comfort and pleasure. 2- User may choose the model based off technical parameters presented in this manual.
Always refer to your pool expert on the correct unit for the size of your pool and your needs as these will vary depending on operating conditions. You may also contact Moov Pool Products for confirmation. Related parameters are subject to adjustment periodically for technical improvement without further notice.
Note: The picture above is the specification diagram of the pool heater, for technician’s installation and layout reference only. The product is subject to adjustment periodically for improvement without further notice. Installation instruction 1. Drawing for water pipes connection. (Notice: The drawing demonstration and layout of the pipes is only for reference.)
2. Electric Wiring Diagram Grounding Grounding Note: 1) Must be hard wired, no plug allowed. 2) The swimming pool heater must be grounded. 3) WARNING: Before obtaining access to terminals, all supply circuits must be disconnected. Options for protecting devices and cable specification MODEL MI(C)500 MI(C)650X...
Page 10
3. Installation and Requirements The swimming pool heater must be installed by a pool professional. End users are not qualified to install the heater. Damage may occur to the heater or threaten the safety of the user. Pool professional guidelines will vary depending on your country, state or province regulation and can include HVAC technicians or electricians.
Page 11
2) Heater must be grounded. 3) Wiring must be handled by a professional technician respecting circuit diagram. 4) Moov Inverter units do not require a GFCI to function. If required by code, please respect following guidelines. i. Set GFCI according to the local code for wiring (current leakage ≤ 30mA).
Operation instruction 1.1. Notice before using 1.1.1 For longer service life, please ensure water pump is on before heat pump starts to work, and water pump is off after heat pump is off. 1.1.2 Ensure no water leakage on piping system, then unlock screen and power on heat pump.
Page 13
Speed Select Smart/Silence mode Up / Down Adjust set temperature Turn on or off Spa function Note: ( will be light all the time when power is on) 1.2.1. Standby screen display When the screen is locked, the key lamp will be off. Will show “0%”...
Page 14
Water inlet temperature Water outlet Smart/ temperature Silence mode Heating Cooling Auto Heating capacity percentage Wi-Fi connection Water inlet Water outlet Power On: Press for 3 seconds to light up screen, then press power on heat pump. Adjust Set Temperature: When screen is unlocked, press...
Page 15
display or adjust the set temperature. Mode Selection: Press to select mode. Heating: Adjustable temperature range 64°F~104°F. Cooling: Adjustable temperature range 54°F~86°F. Auto: Adjustable temperature range 54°F~104°F. Spa function When the screen is on, press the once to activate the SPA function. icon shows on the screen.
Compulsory Defrosting: When heat pump is heating, press together for 5 seconds to start compulsory defrosting, and will be flashing. After defrosting, will stop flashing. Note: Compulsory defrosting intervals should be more than 30 minutes and the compressor should run for more than 10 minutes. Temperature display conversion between °C and °F Press together for 5 seconds to switch between °C and °F.
D. If there are abnormal conditions such as noise, smell, smoke, electrical issues or leakage, please switch off the machine immediately and contact the local dealer or Moov Pool Products. Don’t try to repair it yourself; E. Don’t use or stock combustible gas or liquid such as thinners, paint and fuel to avoid fire;...
D.If the machine is stopped for a long time, please cut off the power supply and drain water clear of the machine by opening the tap of inlet pipe and outlet pipe. Maintenance Caution: Danger of electric shock power supply of the heater before cleaning, examination and repairing 1.
Air outlet blocked Remove the obstacles heating 3minutes protection Wait patiently Set temp too low Set proper heating temperature If the above solution doesn’t work, please contact your dealer or Moov Pool Products. Don’t try to repair the heater yourself.
Failure code Display Not failure description No water protection Power supply excesses operation range Excessive temp difference between inlet and outlet water(Insufficient water flow protection) Ambient temperature too high or too low protection Anti-freezing reminder Display Failure description High pressure protection Low pressure protection Phases lack protection (three phase model only) Water outlet temp too high or too low protection...
WI-FI SETTING 1.1. APP Download Android Mobile please download from iPhone please download from 1.2. Account registration Registration by Cell phone number/Email...
Page 22
Cell phone number registration 1.3. Create family Please set a name for the family and choose the room of the device.
Page 23
1.4. Three methods of device binding Please connect your phone to the Wi-Fi network first. 1.4.1. Auto Discovery (Bluetooth) Please make sure the Bluetooth function is enabled on your phone. Press for 3 seconds after the screen unlock, will be flashing rapidly to enter Wi-Fi binding status.
Page 24
1.4.2. EZ Mode (Easy-connect) Activate the Wi-Fi module Press for 3 seconds after the screen unlocks, will be flashing rapidly to enter Wi-Fi binding status. Click "Add device", and follow the instructions below to finish binding. display on the screen once the Wi-Fi connection success. Note: After allowing the APP to locate, it can read the Wi-Fi name automatically.
Page 25
1.4.3. AP Mode Activate Wi-Fi module Press for 10 seconds after the screen unlock, will be flashing slowly to enter Wi-Fi binding status. Click "Add device", and follow the instructions below to finish binding. display on the screen once the Wi-Fi connection success. Note: If it doesn't jump automatically, click "Confirm hotspot connection, next".
Page 26
Press for 10 seconds, will be flashing slowly for 60 seconds. Then will be off. The original binding will be removed. Follow steps above for rebinding. Remarks: Please make sure the router is configured at 2.4 GHz.
Page 27
1.5. Operation instructions The following instructions are for heat pumps with heating and cooling functions. More share device Heating capacity percentage Indicate the working status The current swimming pool water temp Switching °C/°F Setting temp Temp adjustment slider Smart/Silence Selection Heating/Cooling/Auto Selection Cloud Timer ON/OFF...
Page 28
1.6. Share devices with your family members After binding, if your family members also want to control the device. Please let your family members register the APP first, and then the administrator can operate as below (The following pictures are for reference only): Then your family members will see this heat pump once they log in to the APP.
Warranty is only valid upon first install. Some claims will not be approved under any circumstances by Moov Pool Products. Such claims include and are not limited to: Heat Exchanger broken due to water left in through unproper winterization.
Page 30
Moov Inverter MI(C)500-MI(C)650X-MI(C)900- MI(C)1100-MI(C)1400 Thermopompe Inverter pour piscine Veuillez lire le guide attentivement...
Page 31
Table des matières Utilisation ....................3 Caractéristiques ..................3 III. Paramètres techniques ................ 4 Dimensions ..................... 5 Instructions d’installation ..............6 Mode d’emploi ..................10 VII. Vérifications ..................15 VIII. Précautions ..................16 Entretien....................18 Dépannage en cas de défaillances courantes ........ 19 WI-FI réglage ..................
Page 32
On sait à quel point votre temps est important et on souhaite s’assurer que vous profitiez autant de la saison de piscine que possible. En choisissant Moov Pool Products, vous choisissez une entreprise parmi les plus innovantes sur le marché.
Page 33
85’F. L’unité fonctionne au-dessus et sous cette recommandation, dépendamment des conditions d’utilisation. Veuillez contacter Moov si vous avez des questions. C. Ne placez pas d’objets près de l’entrée et de la sortie d’air de la thermopompe.
étranges ou une fuite, coupez immédiatement le courant et communiquez avec votre détaillant, votre installateur local ou Moov Pool Products. Ne tentez pas de réparer la thermopompe vous-même. Utilisation a) Réglez la température de l’eau de la piscine de façon adéquate, tout en considérant les coûts, pour en profiter pleinement.
F. L’efficacité de l’appareil n’est pas garantie lorsqu’il fonctionne au-delà de ces températures. Sachez que la performance et les paramètres de la thermopompe varient en fonction des conditions. Contactez votre piscinier ou Moov Pool Products pour confirmer la bonne unité recommandé dépendamment de votre installation.
1400 39.8 20.5 32.3 40.8 39.2 20.9 41.5 ※ Les données présentées ci-dessus peuvent changer sans préavis. Remarque : L’image ci-dessus représente le diagramme des spécifications de la thermopompe en vue de l’installation par le technicien et se veut uniquement un plan de référence. Dans le but d’améliorer le produit, il peut faire l’objet d’ajustement périodique sans préavis.
Schéma de câblage Remarque : Raccordement par fils, pas de connecteurs. La thermopompe de la piscine doit être mise à la terre. AVERTISSEMENT: Avant d'accéder aux bornes, tous les circuits d'alimentation doivent être déconnectés. Options pour protéger les appareils et spécifications pour les câbles.
l (mA) Fusible Cordon d’alimentation 2×12 2×10 2×10 2×8 2×8 (AWG) Câble de signal 2×20 2×20 2×20 2×20 2×20 (AWG) ※ Les données ci-dessus peuvent changer sans préavis. Remarque : Les données ci-dessus sont adaptées à un cordon d’alimentation ≤ 393.7in.
Page 40
Certains DDFT peuvent causer des déclenchements intempestifs avec des produits à vitesse variable. Consultez un électricien certifié, votre détaillant ou Moov pour confirmer la connexion. La garantie du produit ne couvre pas les connexions électriques. 5) La disposition du cordon d’alimentation et du câble de signal doit être ordonnée pour que les câbles n’interfèrent pas l’un avec l’autre.
1. La thermopompe doit être installée à l’EXTÉRIEUR dans un endroit bien ventilé afin d’empêcher la recirculation de l’air ou dans un endroit où l’espace est suffisant à l’installation et à l’entretien. Veuillez consulter le diagramme ci- dessous pour les unités side-fan (MI(C)500-MI(C)650X-MI(C)900). 2.
Page 42
1.1.2 Contrôlez s’il n’y a pas de fuite de l’eau dans les tuyaux, puis débloquez l’écran et allumer la pompe à chaleur. 1.2. Mode d’emploi Symbole Identification Fonction Power On/Off ON/OFF WI-FI réglage Pressez-le pour 3 seconds pour bloquer et débloquer Une fois l'écran déverrouillé, appuyez sur Bloquer /...
Page 43
Activer ou désactiver la fonction Spa Annotation: Ce bouton est allumé en permanence, lorsqu'il y a du courant sur l'appareil 8.1.1. Affichage de l’écran de veille Lorsque l’écran est verrouillé, l’indicateur lumineux sera éteint. Affiche " 0% " lors de l’écran de veille 8.1.2.
Page 44
Température d'eau entrée Smart/ Température Silence d'eau sortie mode chauffer Refroidissement Auto Puissance capacité chauffer en pourcentage Wi-Fi connexion Entrée d’eau Sortie d’eau 1. Allumer: poussez pendant 3 secondes pour éclairer l’écran, puis poussez pour allumer la pompe à chaleur.
Page 45
2. Fixer la temperature: quand l’écran est débloqué, poussez pour régler la température 3. Sélection du mode : Appuyez sur pour sélectionner le mode. Chauffage : Plage de température réglable 64°F~104°F. Refroidissement : Plage de température réglable 54°F~86°F. Auto : Plage de température réglable de 54°F~104°F. 4.
Dégeler a. Dégel automatique: quand la pompe à chaleur est en train de dégeler, clignotera. Le cliignotement arrête après le dégel. b. Dégel obligatoire: quand la pompe à chaleur est en train de chauffer, poussez ensemble pendant 5 secondes pour activer le dégel obligatoire. clignotera et après le dégel le clignotement arrêtera.
étranges, une perte de courant ou une fuite, coupez immédiatement le courant et communiquez avec votre détaillant, installateur local ou Moov Pool Products. Ne tentez pas de réparer la thermopompe vous-même. E. Afin de prévenir les incendies, n’utilisez pas ou n’entreposez pas de gaz ou de liquides combustibles, comme des diluants, de la peinture ou de l’essence près de la thermopompe.
Page 48
F. Afin d’optimiser le chauffage, veuillez installer un isolant sur les tuyaux qui raccordent la thermopompe à la piscine. Durant les périodes pendant lesquelles la thermopompe fonctionne, veuillez utiliser une toile solaire pour conserver la chaleur. G. Les tuyaux qui raccordent la thermopompe à la piscine doivent être ≤ 393.7in, sinon le chauffage ne peut être garanti.
Entretien Mise en garde : Risque de choc électrique 1. Coupez le courant à la thermopompe avant de procéder à un nettoyage, à une inspection et à une réparation. 2. Ne touchez pas aux composants électroniques avant que les témoins lumineux sur la carte de circuit imprimé...
Température réglée est Réglez adéquatement la mais ne trop basse température chauffe pas Si les solutions proposées ci-dessus ne règlent pas le problème, communiquez avec votre détaillant ou Moov Pool Products. Ne tentez pas de réparer la thermopompe vous-même.
Codes d’erreur Affichage Description de pas de panne Protection manque de débit d’eau Anomalie dans la puissance d’alimentation Différence de température entre l’entrée et la sortie trop élevée (protection du débit d’eau insuffisant) Protection température ambiante trop élevée/faible Rappel anti-congélation Affichage Description de défaillance Protection haute pression de gaz...
WI-FI réglage 1.1. APP Télécharger Au Android système, téléchargez-le sur Au système Iphone, téléchargez-le sur 1.2. Inscription Inscription avec Numéro Mobile ou E-mail.
Page 53
Numéro Mobile Inscription 1.3. Créer une famille Veuillez définir le nom de famille et choisir la pièce sur l’appareil.
Page 54
1.4. Trois méthodes de liaison des appareils Veuillez d'abord connecter votre téléphone au réseau Wi-Fi. 1.4.1. Découverte automatique (Bluetooth) Please make sure the Bluetooth function is enabled on your phone. Pressez pour 3 seconds puis le déverrouge de l’écran, clignotera et entra dans le programme de reliure Wi-Fi.
Page 55
1.4.2. Mode EZ (Easy-connect) Activez le module Wi-Fi Appuyez sur pendant 3 secondes après le déverrouillage de l'écran, clignote rapidement pour indiquer l'état de la liaison Wi-Fi. Cliquez sur "Add device", suivez les instructions ci-dessous pour terminer la liaison. s'affiche à l'écran une fois la connexion Wi-Fi réussie. Note: Après avoir permis à...
Page 56
auomatiquement. 1.4.3. AP (Activez le module Wi-Fi) Activate Wi-Fi module Appuyez pendant 10 secondes après le déverrouillage de l'écran, l'écran clignotera lentement pour entrer dans le statut de liaison Wi-Fi. Cliquez sur "Add device", suivez les instructions ci-dessous pour terminer la liaison.
Page 57
1.4.5. Rebranchement Wi-Fi (Lorsque le mot de passe Wi-Fi change ou que la configuration du réseau change) Appuyez sur la touche pendant 10 secondes, le voyant clignotera lentement pendant 60 secondes. Puis s'éteindra. La reliure originale sera retirée. Suivez l'étape ci-dessus pour une nouvelle reliure.
Page 58
1.5. Opération Les instructions suivantes concernent les pompes à chaleur avec fonctions de chauffage et de refroidissement. Plus Partager des devices Pourcentage de la capacité de chauffage Indiquer le statut de travail Le température actuelle d’eau dans la piscine Choisir ℃/℉ La température de consigne Curseur de réglage de la température...
Page 59
1.6. Partager des devices à vos membres familiaux Après avoir réalisé la reliure APP, si vos membres familiaux veulent contrôler en même Après avoir réalisé la reliure APP, si vos membres familiaux veulent contrôler en même temps le device. Veuillez demander avant tout à vos membres familiaux de s’inscrire dans APP, en tant que l’administeur, vous pouvez manupuler en suivant les étapes (Les photos suivantes ne sont données qu'à...
Products, tel que, mais pas limité à : L’échangeur de chaleur endommagé suite à une mauvaise hivernisation. Comment hiverniser votre produit Moov Inverter est détaillé sur la page 16 de ce manuel ou sur le site web de Moov Pool Products. Tout autre demande de garantie résultant d’une mauvaise installation ne sera pas traitée.
Page 63
WARNING! Risk of electric shock! - A faulty electrical installation or excessively high voltage can lead to electric shock. - Installation of heat pumps should only be performed by an authorized technician. - Always disconnect the power supply before opening the heat pump for maintenance or repairs. - Do not connect the heat pump if the incoming voltage does not match the required voltage on the unit’s information plate.
Page 64
Table of Contents I. Included parts and accessories II. Safety Information III. Installation of the unit Technical Specifications V. Electrical Wiring VI. Operating Instructions VII. Initial Operation VIII. Operation and maintenance IX. Error codes & Solutions X. WiFi-Function Winterization XII. Warranty Information...
I. Included Parts and Accessories Each unit includes the following accessories: Name Qty. Instruction Manual 1 PC Safety and installation manual (this document) Drain-hose 1 PC Used to direct condensation away from the unit Drain-hose adapter 1 PC Connects the unit to the drain hose Rubber shock absorber 4 PCS Limits friction with installation location...
II. Safety Information Required Operating Conditions: 1. Power supply: 208-230V 50/60Hz. 2. Air temperature: 35°F-105°F 3. Water temperature range: 45°F-104°F in Heating Mode 45°F-82°F in Cooling Mode NOTE: Operating heat pumps at near-freezing temperatures risks damage to the heat exchanger. Heat pumps must be empty of water at freezing temperatures. See winterization guidelines for more details.
III. Installation Instructions 3.1 Installation Diagram *The above diagram may not fit your exact installation. Please contact your pool technician or Fibropool technical support for assistance. 3.2 Installation Clearance Proper clearance is mandatory to allow sufficient airflow and access for maintenance and repairs.
Page 68
3.3 Additional By-pass kits A bypass is recommended for all installations and is required for pumps larger than 1HP. 3.4 Heat pump unit size (mm) FH235-I...
Page 70
3.5 Heat pump Exploded View Parts Parts Parts Display Top frame Wire clip Front panel Bolt Terminal Side panel Top cover Pillar Pillar Ventilation Compressor Pillar Pillar Base tray Water flow switch Back frame Four-way valve Pressure gauge Evaporator Titanium heat exchanger Sensor clip Wire cover Electric box...
VI. Heat Pump Operation 6.1 Controller interface 6.2 Start up & Locking Hold the power button for 1 second to switch the heat pump on or off. This button is also used to return back to the main interface. Hold the button for 3 seconds to lock or unlock the display.
Page 75
*While in Auto mode, if the heat pump is currently heating the display will show . In cooling mode, the display will show 6.4 Operation Mode Selection From the main screen, press to switch between the following operational modes: Silent mode: Limits noise by reducing fan speed.
Page 76
6.7 Other Icons Water Inlet Water outlet Fan motor Defrosting Wi-Fi Note: On the main screen, the Water inlet temp. and Water outlet temp. will display alternately. 6.8 Manual Defrosting Hold for 3 seconds to start Manual defrosting function. Note: These heat pumps enter defrost mode automatically when necessary. Contact Fibropool technical support if you encounter frequent defrosting or need to manually enable defrost.
6.11 Parameter setting Hold for 3 seconds to enter the Parameter setting, press to select the parameter, then press to set the new data for the below parameters. Code Description Default Scope Inlet water temp. in Heating mode 27 ℃ 8~40 ℃...
Page 78
VIII. Operating Instructions 8.1 To ensure proper operation, frequently inspect water and electrical connections. Follow the guidelines below when performing maintenance or repairs: ● Always disconnect the incoming power from the breaker or a shutoff switch before opening unit. ● Unless necessary or instructed by Fibropool, most default settings do not need to be adjusted. ●...
IX. Error Codes and Troubleshooting Code Description Potential reasons Solutions Ensure that water connections are in the correct order, that the pump is Insufficient water flow operating properly, and that all necessary valves are open Water flow protection Check the wiring and reconnect water Water flow switch disconnected flow switch Water flow switch defective...
Page 80
Check wire between motherboard and Bad wire connection Communication failure controller between motherboard Defective motherboard Replace motherboard and driver module Defective Driver module Replace driver module Ensure that water connections are in the correct order, that the pump is Insufficient water flow operating properly, and that all necessary valves are open Excessively high exhaust...
Page 81
Inner piping temperature Sensor disconnected or Reconnect or replace sensor sensor failure defective DC fan motor Bad wire connection Check fan motor wiring malfunction Fan motor defective Replace fan motor *Any manipulation of the refrigerant or related components must be performed by a qualified technician.
Page 82
XI. Maintenance and Winterization • For best performance, we recommend setting the temperature and allowing your heater to run as often as possible. Clean your pool's filtration system regularly to avoid damage to the unit due to a dirty or •...
Page 83
FIBROPOOL HEAT PUMP LIMITED FACTORY WARRANTY This warranty certificate applies only to FibroPool brand electric heat pumps Fibropool Co. LLC warrants this Pool/ Spa Heat Pump, to the original owner, to be free of material and workmanship defects for a limited TEN(10) year term. Heat pumps utilizing Fibropool Titanium Heat Exchangers carry a lifetime warranty on the titanium coil tubing.
