- Page 1 November 29, 2019 Version 1.30 TLC 750 NFC NFC Module INTEGRATION MANUAL...
- Page 2 Declarations...
- Page 3 NFC Module declarations ® This module is designed exclusively for integration in -ebro- measuring instruments. This module is currently installed in the TLC750 NFC This module is designed for use in battery powered devices The basic device without any radio functionality is distributed as TLC750i...
- Page 4 NFC Module FCC Information FCC notes for a host subject to Suppliers Declaration of Conformity For a host device assembled with the certified module and subject to 47 CFR Part 15 Suppliers Declaration of Conformity of class B digital devices, the following statements have to be included in the user manual and the host device has to be labelled as noted below.
- Page 5 NFC Module FCC Information Modification of equipment (in user manual, for details see §15.21): The instruction manual of the host shall include the following statement: Changes or modifications made to this equipment not expressly approved by the party responsible for compliance may void the FCC authorization to operate this equipment.
- Page 6 NFC Module Label...
- Page 7 TLC 750 NFC Module Label Part No. Description Version FCC ID...
- Page 8 TLC 750 NFC Module Positioning...
- Page 9 TLC 750 NFC Module Positioning Position The NFC module is in the area of the label under the housing back side NFC module integrated Battery pack with charge controller NFC module pluggable...
- Page 10 TLC 750 NFC Module Positioning Position The NFC module is in the area of the label under the housing back side Charger coil Charge controller 3.7V LiPo-battery pack Antenna and circuit NFC module USB connector...
- Page 11 TLC 750 NFC Module Positioning Position The NFC module is in the area of the label under the housing back side PCB antenna with Turns: 4 Mean length approximately: 85mm Dimension: 32,1mm x 19,6mm 19,6 mm...
- Page 12 TLC 750 NFC Device Label...
- Page 13 TLC 750 NFC Device Label...
