sisel ENDA ETM2432 Manual

Read this document carefully before using this device. The guarantee will be expired by device
demages if you don't attend to the directions in the user manual. Also we don't accept any
compensations for personal injury, material damage or capital disadvantages.
ENDA ETM2432 DIGITAL TIMER
Thank you for choosing ENDA ETM2432 Digital Timer.
35x77mm sized.
Dual contact output for timing control.
External start, reset, and gate inputs.
Hours/Minutes and Minutes/Seconds indication..
Scale 0:01 .... 99:59 Minutes
0:01 .... 99:59 Hours
Increment - Decrement timing step settings.
Countdown timing.
Start/Stop control from the front panel.
8 Different warning tones.
Upper and Lower limits can be adjusted to setpoint value.
CE marked according to European Norms.
Connection Diagram
ENDA ETM2432 is intended for installation in control panels. Make sure that the device is used only for intended
purpose. The shielding must be grounded on the instrument side. During an installation, all of the cables that are
connected to the device must be free of energy. The device must be protected against inadmissible humidity,
vibrations, severe soiling. Make sure that the operation temperature is not exceeded. All input and output lines
that are not connected to the supply network must be laid out as shielded and twisted cables. These cables
should not be close to the power cables or components. The installation and electrical connections must be
carried on by a qualified staff and must be according to the relevant locally applicable regulations.
ENDA
INDUSTRIAL ELECTRONICS SN: XXXXXXXXX
ETM2432 - 230
DIGITAL TIMER
8 680407 711703
Made In Turkey
230V AC
50/60Hz
250V AC 8A RESISTIVE LOAD
1 2 3 4 5 6 7 8 9 10 11 12
Equipment is protected throughout by
DOUBLE INSULATION
Fuse
NOTE :
F 100 mA
SUPPLY
Switch
250V AC
Phase
7
184-253V AC
Neutral
or 8
10-30V DC /
8-24V AC
Fuse should
Cable size: 1,5mm²
50/60Hz be connected.
SİSEL MÜHENDİSLİK ELEKTRONİK SAN. VE TİC. A.Ş.
Şerifali Mah. Barbaros Cad. No:18 Y.Dudullu 34775
ÜMRANİYE/İSTANBUL-TURKEY
Tel : +90 216 499 46 64 Pbx. Fax : +90 216 365 74 01
url : www.enda.com.tr
OUT1 OUT2 HOUR MIN
OUT1 H M
ENDA
ENDA
DIGITAL TIMER
Order Code : ETM2432 -
1
1 - Supply Voltage
230........230V AC
LV............10-30V DC /
8-24V AC
ENDA
INDUSTRIAL ELECTRONICS
ETM2432-LV
DIGITAL TIMER
8 680407 711734
10-30V DC/8-24V AC
50/60Hz
250V AC 8A RESISTIVE LOAD
1 2 3 4 5 6 7 8
Holding screw
0.4-0.5Nm.
Note :
1) Mains supply cords shall meet the requirements
of IEC 60227 or IEC 60245.
230V AC/ LV
2) In accordance with the safety regulations, the
Supply
power supply switch shall bring the identification of
the relevant instrument and it should
accessible by the operator.
Technical Specifications
ENVIRONMENTAL CONDITIONS
Ambient/Storage
Temperature
Relative Humidity
Protection Class
Height
KEEP AWAY device from exposed to corrosive, volatile and flammable gases or
liquids and DO NOT USE the device in similar hazardous locations.
ELECTRICAL CHARACTERISTICS
Supply
Power Consumption
Wiring
START
Scale
Sensitivity
SET SET
SET SET
Time Accuracy
STOP
Indıcator
EMC
ETM232
ETM2432
Safety Requirements
OUTPUT
Out
Life Expectancy for Relay
START INPUT
Input Type
RESET INPUT
Input Type
GATE INPUT
Input Type
HOUSING
Housing Type
Dimensions
Weight
Enclosure Materials
Avoid any liquid contact when the device is switched on.
DO NOT clean the device with solvent (thinner, gasoline, acid etc.) and / or abrasive cleaning agents.
Dimensions
SN: XXXXXXXXX
OUT1 OUT2 HOUR MIN
Made In Turkey
ENDA DIGITAL TIMER
9 10 11 12
be easily
1/4
0 ... +50 °C/-25 ... +70°C (with no icing).
80% Relative humidity for temperatures up to 31°C, decreasing linearly to 50% at 40°C.
According to EN60529; Front panel: IP65 Rear panel : IP20
Max. 2000m
230V AC +%10-%20 50/60Hz ; 10-30V DC/8-24V AC 50/60Hz
Max. 7VA
2.5mm² screw-terminal
Selectable 99:59 min. or hour.
1 Second.
±%1
4 Digits, 12.5mm, 7 Segment Red LED
EN 61326-1: 2013 (Performance criterion B is satisfied for EN 61000-4-3)
EN 61010-1: 2010 (Pollution degree 2, overvoltage category II)
2 Relays: 250V AC, 8A (for resistive load), NO and NC control output.
30.000.000 Switching for no-load operation; 300.000 switching for 8A resistive load at 250VAC.
Mechanical contact (Minimum = 50ms)
Mechanical contact (Minimum = 50ms)
Mechanical contact (Minimum = 50ms)
Suitable for flush-panel mounting according to DIN 43 700.
W77xH3 xD7 mm 5 1
Approx. 198g (A fter packing )
Self extinguishing plastics
77mm
To removing the mounting clamps :
- Push the flush-mounting clamp in
START
direction 1 as shown in the figure
SET SET below.Then, pull out the clamp in
SET SET
direction 2 .
STOP
ETM232
ETM2432
Flush mounting
Flush mounting
2
clamp
Panel Cut-out
71,5mm
1
Depth
60mm 5mm
2
Panel
clamp
Rubber
Packing
Note :
1) Panel thickness should
be maximum 7mm.
2) If there is not 60mm free
space at the back side of
the device,it would be
difficult to remove it from
the panel.
ENDA TM
ETM2432-EN-03-220103
