SERVICE MANUAL
Picture tube
0.24 mm aperture grill pitch (center)
19 inches measured diagonally
90-degree defl ection
Video image area
(18.0" maximum viewing image)
Approx. 365 X 274 mm (w/h)
(14
3/8
Resolution
Horizontal: Max. 1920 dots
Vertical: Max. 1440 lines
Standard image area
Approx. 352 x 264 mm (w/h)
(13
7/8
Input signal
Video
Analog RGB (75 ohms typical)
0.700 Vp-p, Positive
Sync
H/V separate or composite sync:
TTL 2k ohms Polarity Free
Sync on Green: 0.3 Vp-p (negative)
9-978-882-01
SPECIFICATIONS
x 10
7/8
inches)
x 10
1/2
inches)
CPD-G410R
US/Canada Model
US/Canada Model
19CRV
Power Consumption
135 W
Defl ection frequency
Horizontal: 30 to 110 kHz
Vertical: 48 to 170 Hz
AC input voltage/current 100 to 240 V, 50 - 60 Hz, 2.0 - 1.0 A
Dimensions
451 x 471 x 461 mm (w/h/d)
(17
7/8
Mass
Approx. 25.5 kg (56 lb 3 oz.)
Plug and Play
DDC2B/DDC2Bi
GTF
Design and specifi cations are subject to change without notice.
TRINITRON
COLOR MONITOR
®
Self Diagnosis
Supported model
CPD-G410R
Chassis No: SCC-L42C-A
CPD-G410R
Chassis No: SCC-L42H-A
CHASSIS
x 18
5/8
x 18
1/4
inches)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TRINITRON SCC-L42C-A and is the answer not in the manual?

Questions and answers

Related Manuals for Sony TRINITRON SCC-L42C-A

Summary of Contents for Sony TRINITRON SCC-L42C-A

  • Page 1 Self Diagnosis Supported model CPD-G410R SERVICE MANUAL CPD-G410R US/Canada Model Chassis No: SCC-L42C-A CPD-G410R US/Canada Model Chassis No: SCC-L42H-A 19CRV CHASSIS SPECIFICATIONS Picture tube 0.24 mm aperture grill pitch (center) Power Consumption 135 W 19 inches measured diagonally 90-degree defl ection Defl...

  • Page 2: Table Of Contents

    CPD-G410R TABLE OF CONTENTS SECTION TITLE PAGE Power Management..........................3 Self Diagnosis Function ..........................3 Timing SpeciÞ cation..........................3 Safety Check Out Instructions ........................4 Warnings and Cautions..........................4 1. Disassembly 1-1. Cabinet Removal ..........................5 1-2. Service Position..........................5 1-3.

  • Page 3: Power Management

    CPD-G410R POWER MANAGEMENT The power saving mode complies with the VESA Display Power Management Signaling standard. Each state of power management shall be activated by the host computer terminating the appropriate sync signals. Blanking the video must precede termination of the sync signals. The elapsed time counter shall also be controlled by the host computer.

  • Page 4: Safety Check Out Instructions

    CRITICAL FOR SAFE OPERATION. REPLACE THESE COMPONENTS ET LES LISTES DE PIECES SONT D’UNE IMPORTANCE CRITIQUE WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN POUR LA SECURITE DU FONCTIONNEMENT. NE LES REMPLACER THIS MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY. CIRCUIT...

  • Page 5: Section 1: Disassembly

    CPD-G410R SECTION 1: DISASSEMBLY 1-1. CABINET REMOVAL Remove (2) Screws (+BVTP 4 x 16) Release side claw - Insert the tip of a ß athead screwdriver approximately 0.25" to unlock the claw. Release top claw - Working from the same side as the the claw in step 2, insert the tip of a ß...

  • Page 6: A & D Board Removal

    CPD-G410R 1-3. A & D BOARD REMOVAL Remove (6) screws (+BVTP 3 x 8) from the sides of the EMI shield. Slide back and remove. Gently wiggle the A board back and forth, and pull it to remove. Remove (2) screws (+BVTP 3 x 8) from the rear of the chassis base and remove.

  • Page 7: Picture Tube Removal

    CPD-G410R 1-4. PICTURE TUBE REMOVAL Place the unit face down on a cushion to avoid scratching. Remove the anode cap. Remove (4) screws (Screw (5) Tapping) from the CRT. Remove the picture tube shield. Remove the deß ection yoke. Remove the neck assembly. Remove the A board and C Block.

  • Page 8: Section 2: Safety Related Adjustments

    CPD-G410R SECTION 2: SAFETY RELATED ADJUSTMENTS When replacing parts shown in the table below, the following 2-2. HV PROTECTOR CIRCUIT CHECK operational checks must be performed as a safety precaution against X-ray emissions from the unit. Using external DC Power Supply, apply the voltage shown below between cathode of D912 and GND, and check that the RASTER Part Replaced ( disappears.

  • Page 9: Section 3: Adjustments

    CPD-G410R SECTION 3: ADJUSTMENTS Connect the communication cable of the connector located on the D board on the monitor. Run the service software and then follow the instructions Allow a 30 minute warm-up period prior to making the following adjustments: 3-1.

  • Page 10: Convergence Rough Adjustment

    CPD-G410R 13. Adjust the vertical angle of DY to make top and bottom pins equal XBV Movement YBH Movement (a = b). The horizontal angle shall not be changed (straight). Settle DY upright without leaning, and insert wedges Þ rmly so that DY shall not move.

  • Page 11: Section 4: Diagrams

    CPD-G410R SECTION 4: DIAGRAMS 4-1. CIRCUIT BOARDS LOCATION The components identiÞ ed by shading and symbol are critical for safety. Replace only with part number speciÞ ed. The symbol indicates a fast operating fuse and is displayed on the component side of the board.

  • Page 12: Diagrams Block Diagram

    CPD-G410R 4-3. DIAGRAMS BLOCK DIAGRAM (1/3) — 12 —...
  • Page 13 CPD-G410R BLOCK DIAGRAM (2/3) — 13 —...
  • Page 14 CPD-G410R BLOCK DIAGRAM (3/3) — 14 —...

  • Page 15: A Board Schematic Diagram

    CPD-G410R A BOARD SCHEMATIC DIAGRAM A BOARD IC VOLTAGE LIST IC001 IC002 IC004 volt volt volt 56.6 11.8 — 12.0 56.3 54.4 79.4 105.4 109.4 112.9 — 11.9 199.6 IC003 IC005 volt volt — IC006 volt — — IC009 volt —...
  • Page 16 CPD-G410R CONDUCTOR SIDE — — — — C BLOCK — 16 —...
  • Page 17 CPD-G410R • A BOARD WAVEFORMS 1.12 Vp-p (H) 54.5 Vp-p (H) 56.0 Vp-p (H) 0.74 Vp-p (H) 54.5 Vp-p (H) 0.73 Vp-p (H) A BOARD LOCATOR LIST DIODE COMP COND COMP COND D001 IC001 D002 IC002 D003 IC003 D004 IC004 D005 IC005 D007...

  • Page 18: D Board Schematic Diagram

    CPD-G410R D BOARD SCHEMATIC DIAGRAM D BOARD IC VOLTAGE LIST — IC401 IC603 IC610 IC703 volt volt volt volt 148.1 14.3 -13.3 -15.0 — -14.4 15.0 13.8 12.6 IC611 IC902 12.3 volt volt IC501 12.1 — IC604 12.9 — volt IC701 IC1603 15.0...
  • Page 19 CPD-G410R COMPONENT SIDE CONDUCTOR SIDE D BOARD LOCATOR LIST DIODE DIODE TRANSISTOR COMP COND COMP COND COMP COND D401 D630 B-10 Q501 D405 D631 Q502 D501 I-11 D632 Q503 D502 D633 Q504 D503 D634 Q505 D-10 D504 D635 Q506 D505 D636 Q507 D506...

  • Page 20: H1 Board Schematic Diagram

    CPD-G410R H1 BOARD SCHEMATIC DIAGRAM — — [FRONT PANEL] — — 20 —...

  • Page 21: N Board Schematic Diagram

    CPD-G410R N BOARD SCHEMATIC DIAGRAM — — — — — — — CONDUCTOR SIDE [MICRO] COMPONENT SIDE — 21 —...

  • Page 22: Board Schematic Diagram

    CPD-G410R DA BOARD SCHEMATIC DIAGRAM — — — — — — [DSP] COMPONENT SIDE CONDUCTOR SIDE — 22 —...

  • Page 23: Semiconductors

    CPD-G410R 4-4. SEMICONDUCTORS 2SC2610 2SC1623-L5L6 DTC143ESA 2SC4634LS-CB11 2SA1037AK-T146-R 2SC3941A-Q(TA) DTA114EKA-T146 HZU5.6B2TRF MTZJ-T-77-12B D1NS6 2SK2605LBSONY 2SA1175-HFE ERC81-004 D1NL40-TA2 2SK3155-01 2SC2785-HFE EGP10D UF4007G23 2SK2098-01MR-F119 DTC114TSA RGP10JPKG23 RGP02-20EL-6394 2SK2843LBS2SONY 2SC3311A-QRSTA RGP10DG23 ERB91-02 IRFU110A RL3Z-LF014-302 LETTER SIDE CATHODE CATHODE ANODE ANODE 1SS119-25 D4SB60L HSS83TD RD5.1ESB2 1SS355TE-17 RD5.6ESB2...

  • Page 24: Section 5: Exploded Views

    CPD-G410R SECTION 5: EXPLODED VIEWS Components not identiÞ ed by a part number or The component parts of an assembly are indicated by Items marked with an asterisk are not stocked since description are not stocked because they are seldom the reference numbers in the far right column of the parts they are seldom required for routine service.

  • Page 25: Chassis

    CPD-G410R NOTE: The components identiÞ ed by shading and mark are critical for safety. NOTE: Les composants identiÞ es per un trame et une marque sont critiques pour Replace only with part number speciÞ ed. la securite. Ne les remplacer que par une piece portant le numero speciÞ e. 5-2.

  • Page 26: Packing Materials

    CPD-G410R NOTE: The components identiÞ ed by shading and mark are critical for safety. NOTE: Les composants identiÞ es per un trame et une marque sont critiques pour Replace only with part number speciÞ ed. la securite. Ne les remplacer que par une piece portant le numero speciÞ e. 5-3.

  • Page 27: Section 6: Electrical Parts List

    CPD-G410R SECTION 6: ELECTRICAL PARTS LIST H1 A NOTE: The components identiÞ ed by shading The components in this manual identiÞ ed by the following RESISTORS mark are critical for safety. Replace only symbol: indicate parts that have been carefully factory- •...
  • Page 28 CPD-G410R REF.NO. PART NO. DESCRIPTION VALUES REF.NO. PART NO. DESCRIPTION VALUES C036 1-163-243-11 CERAMIC CHIP 47pF CONNECTOR C037 1-164-004-11 CERAMIC CHIP 0.1µF CN303 1-695-915-11 TAB (CONTACT) C038 1-163-017-00 CERAMIC CHIP .0047µF 10% CN311 1-778-671-11 CONNECTOR, BOARD TO BOARD 10P C039 1-115-339-11 CERAMIC CHIP 0.1µF...
  • Page 29 CPD-G410R NOTE: Les composants identiÞ es per un trame et une NOTE: The components identiÞ ed by shading marque sont critiques pour la securite. Ne les mark are critical for safety. Replace only remplacer que par une piece portant le numero speciÞ e. with part number speciÞ...
  • Page 30 CPD-G410R NOTE: Les composants identiÞ es per un trame et une NOTE: The components identiÞ ed by shading marque sont critiques pour la securite. Ne les mark are critical for safety. Replace only remplacer que par une piece portant le numero speciÞ e. with part number speciÞ...
  • Page 31 CPD-G410R NOTE: Les composants identiÞ es per un trame et une NOTE: The components identiÞ ed by shading marque sont critiques pour la securite. Ne les mark are critical for safety. Replace only remplacer que par une piece portant le numero speciÞ e. with part number speciÞ...
  • Page 32 CPD-G410R REF.NO. PART NO. DESCRIPTION VALUES REF.NO. PART NO. DESCRIPTION VALUES C738 1-136-169-00 FILM 0.22µF DIODE C761 1-163-021-91 CERAMIC CHIP 0.01µF D401 8-719-979-58 DIODE EGP10GPKG23 C901 1-163-809-11 CERAMIC CHIP 0.047µF 10% D405 8-719-109-85 DIODE RD5.1ES-T1B2 C902 1-163-009-91 CERAMIC CHIP 0.001µF 10% D501 8-719-110-47 DIODE HZS182-TE...
  • Page 33 CPD-G410R NOTE: Les composants identiÞ es per un trame et une NOTE: The components identiÞ ed by shading marque sont critiques pour la securite. Ne les mark are critical for safety. Replace only remplacer que par une piece portant le numero speciÞ e. with part number speciÞ...
  • Page 34 TRANSISTOR 2PD602AR-115 R502 1-216-025-11 RES-CHIP 1/10W Q503 8-729-049-85 TRANSISTOR 2PB710AR-115 R503 1-216-033-00 RES-CHIP 1/10W Q504 8-729-043-53 TRANSISTOR 2SK2231 Q505 8-729-056-66 TRANSISTOR 2SC5682-SONY-CA R504 1-216-073-91 RES-CHIP 1/10W R505 1-216-081-00 RES-CHIP 1/10W Q506 8-729-043-63 TRANSISTOR IRFI9634G-LF35 R506 1-249-393-11 CARBON 1/4W Q507 8-729-120-28...
  • Page 35 CPD-G410R REF.NO. PART NO. DESCRIPTION VALUES REF.NO. PART NO. DESCRIPTION VALUES R627 1-219-513-11 CARBON 4.7M 1/2W R553 1-249-437-11 CARBON 1/4W R555 1-249-437-11 CARBON 1/4W R628 1-247-897-11 CARBON 560K 1/4W R557 1-249-437-11 CARBON 1/4W R629 1-216-121-11 RES-CHIP 1/10W R559 1-249-437-11 CARBON 1/4W R630 1-215-405-00...
  • Page 36 CPD-G410R REF.NO. PART NO. DESCRIPTION VALUES REF.NO. PART NO. DESCRIPTION VALUES R705 1-208-840-11 METAL CHIP 270K 0.50% 1/10W R906 1-249-429-11 CARBON 1/4W R706 1-215-887-00 METAL OXIDE R908 1-249-429-11 CARBON 1/4W R707 1-249-440-11 CARBON 1/4W R909 1-219-727-11 METAL R709 1-216-065-91 RES-CHIP 4.7K 1/10W R910...
  • Page 37 CPD-G410R D DA A component identiÞ ed by this symbol indicates that it NOTE: The components identiÞ ed by shading has been carefully factory-selected to satisfy regulations mark are critical for safety. Replace only regarding X-ray radiation. Should replacement be required, with part number speciÞ...
  • Page 38 CPD-G410R DA N REF.NO. PART NO. DESCRIPTION VALUES REF.NO. PART NO. DESCRIPTION VALUES RESISTOR R1101 1-216-025-11 RES-CHIP 1/10W R1102 1-216-057-00 RES-CHIP 2.2K 1/10W R1103 1-216-025-11 RES-CHIP 1/10W A-1391-154-A N BOARD, MOUNTED R1106 1-208-822-11 METAL CHIP 0.50% 1/10W R1108 1-216-067-00 RES-CHIP 5.6K 1/10W CAPACITOR...
  • Page 39 RES, CHIP NETWORK 100 RB1007 1-233-576-11 RES, CHIP NETWORK 100 RB1009 1-233-576-11 RES, CHIP NETWORK 100 CRYSTAL X1001 1-795-044-21 VIBRATOR, CRYSTAL SONY CORPORATION English 2001HJ74WEB-1 Sony Technology Center Printed in the U.S.A. Technical Services © 2001.8 9-978-882-01 Service Promotion Department — 39 —...
  • Page 40 D BOARD SCHEMATIC DIAGRAM — — — — — — — — —...
  • Page 41 CPD-G410R D BOARD IC VOLTAGE LIST IC401 IC603 IC610 IC703 volt volt volt volt 148.1 14.3 -13.3 -15.0 -14.4 15.0 IC611 IC902 13.8 12.6 12.3 volt volt IC501 12.1 IC604 12.9 IC701 IC1603 volt 15.0 volt volt 12.0 IC605 volt -15.0 -14.8 11.6...
  • Page 42 — — — — — — — — 18...
  • Page 43 D BOARD WAVEFORMS 0.71 Vp-p (H) 11.3 Vp-p (H) 59.5 Vp-p (V) 1.7 Vp-p (V) 180 Vp-p (H) 640 Vp-p (H) — 18 —...
  • Page 44 COMPONENT SIDE...
  • Page 45 CPD-G410R CONDUCTOR SIDE...
  • Page 46 D BOARD LOCATOR LIST DIODE DIODE TRANSISTOR COMP COND COMP COND COMP COND D401 D630 B-10 Q501 D405 D631 Q502 D501 I-11 D632 Q503 D502 D633 Q504 D503 D634 Q505 D-10 D504 D635 Q506 D505 D636 Q507 D-10 D506 D639 Q510 D507 D701...
  • Page 47 4-084-759-11 (1) Trinitron Color â Computer Display Operating Instructions Mode d’emploi Manual de instrucciones CPD-G410R © 2001 Sony Corporation...

  • Page 48: Owner's Record

    Metrology de décembre 1990 (MPR II) en ce qui concerne les Sony Customer Information Center fréquences très basses (VLF) et extremement basses (ELF). 1 Sony Drive, Mail Drop #T1-11, Park Ridge, NJ 07656 INFORMACIÓN Este producto cumple las normas del Consejo Nacional Sueco Declaration of Conformity para Metrología (MPR) emitidas en diciembre de 1990 (MPR II)
  • Page 49 Table of Contents • Trinitron is a registered trademark of Sony Corporation. • Macintosh is a trademark licensed to Apple Computer, Inc., registered in Setup ........3 the U.S.A.

  • Page 50: Navigating The Menu

    Adjustments Navigating the menu Adjusting the brightness and contrast Brightness and contrast adjustments are made using a separate Press the MENU button to display the main menu. BRIGHT/CONTRAST menu. These adjustments are effective for all input signals. EX I T Move the control button M ( )/m ( ) to display the BRIGHT/CONTRAST menu.
  • Page 51 On-Screen menu adjustments Main menu icons and adjustment Sub menu icons and adjustment items items Horizontal position Horizontal size Adjusting the size or centering of Vertical position the picture Vertical size Auto Size Center Rotating the picture Expanding or contracting the picture sides Shifting the picture sides to the left or right Adjusting the shape of the picture Adjusting the picture width at the top of the screen...

  • Page 52: Troubleshooting

    x Letters and lines show red or blue shadows at the Troubleshooting edges • Adjust the convergence. x No picture x A hum is heard right after the power is turned on If the ! (power) indicator is not lit •...

  • Page 53: Specifications

    If the ! (power) indicator is still flashing, there is a potential monitor failure. Count the number of seconds between orange flashes of the ! (power) indicator and inform your authorized Sony dealer of the monitor’s condition. Be sure to note the model name and serial number of your monitor.
  • Page 54 Preset and user modes Precautions When the monitor receives an input signal, it automatically matches the signal to one of the factory preset modes stored in the monitor’s memory “Preset mode timing table” on to provide a high quality picture (see page i ).
  • Page 55 â • Trinitron est une marque commerciale déposée de Sony Corporation. Table des Matières • Macintosh est une marque commerciale sous licence d’Apple Computer, Inc., Configuration ....... 3 déposée aux Etats-Unis et dans d’autres pays.

  • Page 56: Navigation Dans Le Menu

    Réglages Navigation dans le menu Réglage de la luminosité et du contraste Appuyez sur la touche MENU pour afficher le menu Vous pouvez modifier la luminosité et le contraste à l’aide du menu principal. LUMIN/CONTR. Ces réglages s’appliquent à tous les signaux SORT I R d’entrée.
  • Page 57 Réglages du menu d’écran Icônes du menu principal et éléments Icônes du sous-menu et éléments de réglage de réglage Position horizontale Taille horizontale Réglage de la taille ou du centrage Position verticale de l’image Taille verticale Centrage de taille automatique Rotation de l’image Étirement ou contraction des côtés de l’image Déplacement des bords de l’image vers la droite ou la gauche...

  • Page 58: Dépannage

    x Les touches du moniteur ne fonctionnent pas Dépannage apparaît à l’écran) • Si la fonction de verrouillage des commandes est réglée sur ACTIF, x Aucune image réglez-la sur INACTIF. x Les bords des lettres et des lignes sont soulignés d’une Si l’indicateur ! (alimentation) est éteint ombre rouge ou bleue •...

  • Page 59: Si Des Lignes Fines Apparaissent À L'écran (Fils D'amortissement)

    Comptez le nombre de secondes entre les clignotements oranges de l’indicateur ! (alimentation) et informez votre revendeur Sony agréé de l’état du moniteur. Notez soigneusement le modèle et le numéro de série du moniteur. Notez également la marque et le modèle de l’ordinateur et de la carte graphique.
  • Page 60 Modes préréglés et personnalisés Précautions Lorque le moniteur reçoit un signal d’entrée, il compare automatiquement le signal à l’un des modes prédéfinis en usine mémorisés afin de fournir une (voir le tableau de modes prédéfinis (Preset mode image de haute qualité timing table) page i).
  • Page 61 â • Trinitron es una marca comercial registrada de Sony Corporation. Índice • Macintosh es una marca comercial de Apple Computer, Inc., registrada en Configuración ......3 EE.UU.

  • Page 62: Navegación Por El Menú

    Ajustes Navegación por el menú Ajuste del brillo y el contraste El ajuste del brillo y el contraste se efectúa mediante un menú Pulse el botón MENU para visualizar el menú principal. BRILLO/CONTRASTE separado. Estos ajustes son adecuados para todo tipo de señales de entrada. S A L I R Mueva el botón de control ) para visualizar el...
  • Page 63 Ajustes de menús en pantalla Iconos del menú principal y Iconos del submenú y elementos de ajuste elementos de ajuste Posición horizontal Tamaño horizontal Ajuste del tamaño o centrado de la Posición vertical imagen Tamaño vertical Centrado de tamaño automático Giro de la imagen Expansión o contracción de los lados de la imagen Desplazamiento de los lados de la imagen a la izquierda o la derecha...

  • Page 64: Solución De Problemas

    x El blanco no parece blanco Solución de problemas • Ajuste la temperatura del color. x Los botones del monitor no funcionan ( aparece en x No aparece la imagen pantalla) Si el indicador ! (alimentación) no se ilumina • Si el bloqueo de los controles está ajustado en SI, ajústelo en NO. •...

  • Page 65: Función De Autodiagnóstico

    Si las barras de color no aparecen, significa que existe un fallo potencial del monitor. Informe a un proveedor Sony autorizado sobre el estado del monitor. x Si el indicador ! (alimentación) parpadea en naranja Apague (OFF) el monitor y vuelva a encenderlo (ON).

  • Page 66: Instalación

    Modos predefinidos y de usuario Precauciones Cuando el monitor recibe una señal de entrada, hace coincidir automáticamente la señal con uno de los modos predefinidos en fábrica almacenados en la (consulte la memoria del monitor para mostrar una imagen de alta calidad “Tabla de temporización de modo predefinido (Preset mode timing table)”...

  • Page 67: Preset Mode Timing Table

    Appendix Preset mode timing table No. Resolution Horizontal Vertical Graphics (dots × lines) Frequency Frequency Mode 640 × 480 31.5 kHz 60 Hz VGA-G 640 × 480 37.5 kHz 75 Hz EVGA 640 × 480 43.3 kHz 85 Hz VESA 720 ×...

  • Page 68: Tco'99 Eco-Document

    Below you will find a brief summary of the environmental TCO’99 Eco-document requirements met by this product. The complete environmental criteria document may be ordered from: TCO Development SE-114 94 Stockholm, Sweden Fax: +46 8 782 92 07 Email (Internet): development@tco.se Current information regarding TCO’99 approved and labelled products may also be obtained via the Internet, using the address: http://www.tco-info.com/...
  • Page 70 Sony Corporation Printed in USA...
  • Page 71 PRINTING THE SERVICE MANUAL The PDF of this service manual is not designed to be printed from cover to cover. The pages vary in size, and must therefore be printed in sections based on page dimensions. NON-SCHEMATIC PAGES Data that does NOT INCLUDE schematic diagrams are formatted to 8.5 x 11 inches and can be printed on standard letter-size and/or A4-sized paper. SCHEMATIC DIAGRAMS The schematic diagram pages are provided in two ways, full size and tiled.
  • Page 72 ON-SCREEN SEARCH OPTION All of the text within the service manual PDF is content searchable. This means that you can enter any text, word, phrase or reference number that appears in the manual, and the PDF software will search, fi nd and move the cursor to the location where you requested text fi rst appears. This feature can be particularly useful in locating components on a specifi...
  • Page 73 HISTORY INFORMATION FOR THE FOLLOWING MANUAL: CPD-G410R SERVICE MANUAL CPD-G410R US/Canada Model Chassis No: SCC-L42C-A CPD-G410R US/Canada Model Chassis No: SCC-L42H-A 19CRV CHASSIS ORIGINAL MANUAL ISSUE DATE: 8/2001 ALL REVISIONS AND UPDATES TO THE ORIGINAL MANUAL ARE APPENDED TO THE END OF THE PDF FILE. REVISION DATE REVISION TYPE SUBJECT...
