LCD Screen
Instruction Manual
Thank you for purchasing the LCD Screen (for PS one
product, carefully read this manual and retain it for future reference.
This LCD Screen is exclusively for use with PS one
symbol marked on the console bottom.
SCPH-152
© 2002 Sony Computer Entertainment Inc.
All rights reserved.
(for PS one
B
®
). Before using this
®
consoles that have the
®
3-072-606-32(1)
)
Advertisement
Table of Contents
Related Manuals for Sony SCPH-152 b
Summary of Contents for Sony SCPH-152 b
-
Page 1: Lcd Screen
This LCD Screen is exclusively for use with PS one consoles that have the ® symbol marked on the console bottom. SCPH-152 © 2002 Sony Computer Entertainment Inc. All rights reserved. 3-072-606-32(1) -
Page 2: Warning
WARNING Read before operating the LCD To prevent fire or shock hazard, Screen (for PS one ® do not expose the unit to rain or moisture. A few people may experience epileptic seizures when viewing To avoid electrical shock, do not flashing lights or patterns in our daily disassemble. -
Page 3: Table Of Contents
Table of contents WARNING Precautions Checking the package contents Part names Connecting the LCD Screen to the PS one console ® Using the LCD Screen Adjusting the brightness of the screen Adjusting the volume Using headphones with the LCD Screen Connecting the PS one console to a TV set ®... -
Page 4: Precautions
Precautions Safety This product has been designed with the highest concern for safety. However, any electrical device, if used improperly, has the potential for causing fire, electrical shock or personal injury. To ensure accident-free operation, follow these guidelines: • Observe all warnings, precautions and instructions. •... - Page 5 • Do not put heavy objects on the LCD Screen or AC adaptor. • Do not throw or drop the LCD Screen or AC adaptor, or subject either item to strong physical shock. • Do not shake the LCD Screen while in use, or subject it to vibration. Be especially careful when using in a car.
- Page 6 Precautions (continued) Static image caution When connected to a TV, static, non-moving images, such as menus, configuration displays or paused images, may leave a faint image permanently on the TV screen if left on for extended periods of time. Projection TVs are more susceptible to this than other types of displays.
- Page 7 Closing the LCD Screen When closing the LCD Screen, make sure that there is nothing between the PS one ® console and the LCD Screen. Also, close the disc cover of the console before closing the LCD Screen. If you close both at the same time, damage to the screen may result. Transporting the LCD Screen Before carrying the LCD Screen, make sure you disconnect it from any cables.
-
Page 8: Checking The Package Contents
Checking the package contents Check that you have the following items: • LCD Screen (for PS one ) (1) ® • AC adaptor (1) • Instruction manual (1) If any items are missing, please contact the appropriate PlayStation ® customer service helpline which can be found: - on the customer registration card;... -
Page 9: Part Names
Part names LCD Screen (for PS one ® Front 8 8 (brightness) –/+ buttons Power connector Screen 2 (volume) –/+ buttons Stereo speakers AV MULTI connector... - Page 10 Part names (continued) Rear AV IN jack Mounting screw i (headphone) jack AV MULTI OUT connector Mounting screw ! DC IN 7.5V connector...
- Page 11 AC adaptor DC 7.5 V connector...
-
Page 12: Connecting The Lcd Screen To The Ps One ® Console
Connecting the LCD Screen to the PS one console ® b Warning For safety reasons, do not connect the AC adaptor to the LCD Screen (for PS one ® until you have finished connecting the LCD Screen to the PS one console. - Page 13 Insert the DC 7.5V connector of the supplied AC adaptor into the ! DC IN 7.5V connector on the LCD Screen rear, and then insert the AC adaptor into an electrical outlet. ! DC IN 7.5V connector DC 7.5V connector AC adaptor b Warning Use the supplied SCPH-122B AC adaptor only.
-
Page 14: Using The Lcd Screen
Using the LCD Screen You can play games on the PS one console using the LCD Screen (for ® PS one ® The LCD Screen automatically turns on when you turn on the PS one ® console. For instructions on operating the console, refer to the PS one ®... -
Page 15: Using Headphones With The Lcd Screen
Using headphones with the LCD Screen You can use headphones (sold separately) with the LCD Screen (for PS one ® Connect the headphones to the i (headphone) jack on the LCD Screen rear. If necessary adjust the volume by pressing the 2 (volume) –/+ buttons. -
Page 16: Connecting The Ps One ® Console To A Tv Set
Connecting the PS one console to a TV set ® You can play games on the PS one console using a TV screen even when ® an LCD Screen (for PS one ) is connected to the console. ® Use the AV MULTI OUT connector on the LCD Screen rear to connect the console to a TV set using the RFU Adaptor supplied with the PS one ®... -
Page 17: Connecting Video Equipment To The Lcd Screen
Connecting video equipment to the LCD Screen You can use the LCD Screen (for PS one ) to view video from camcorders ® and other devices. Connect the device to the PS one console with an AV ® cable (sold separately) through the AV IN jack on the LCD Screen rear. Choose an AV cable that matches the AV output jacks of the device, and connect it as shown in the diagram below: To AV output jack (mini-jack) of... -
Page 18: Troubleshooting
Troubleshooting Please refer to this section if you experience difficulty in operating the LCD Screen (for PS one ® 1 If you experience any of the following difficulties, use this troubleshooting guide to help remedy the problem before requesting repair. Refer also to the troubleshooting section of the PS one console instruction manual. -
Page 19: Specifications
Specifications General Inputs/outputs Power requirements Inputs AC adaptor: 7.5 V DC AV IN jack (mini-jack) (220-240 V AC, 50/60 Hz) ! DC IN 7.5V connector Power consumption Outputs 6.8 W (Not including power used by AV MULTI OUT connector the PS one console.) ®... -
Page 20: Guarantee
IMPORTANT Product and neither SCEE nor any other 1. If you need to claim under this Sony entity, or their suppliers or Guarantee, please call your local authorised service facilities, will be liable Customer Service Helpline (listed on the... - Page 24 “ ”, “PlayStation” and “PS one” are registered trademarks of Sony Computer Entertainment Inc. “SONY” and “ ” are registered trademarks of Sony Corporation. www.playstation.com Printed in Korea...
