7.0T Treadmill
7.0T_770884_OM_20250204
Online Support
If you require assistance or are
experiencing issues with your
Spirit Machine, please contact
customer care for additional help.
1-800-258-8511
service@spiritfitness.com
Warranty Registration
Scan to quickly and easily
register your new Spirit
Fitness machine.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SPIRIT 7.0T and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Dyaco SPIRIT 7.0T

  • Page 1 Online Support If you require assistance or are experiencing issues with your Spirit Machine, please contact customer care for additional help. 1-800-258-8511 service@spiritfitness.com Warranty Registration Scan to quickly and easily register your new Spirit Fitness machine. 7.0T Treadmill 7.0T_770884_OM_20250204...
  • Page 3: Table Of Contents

    Table of Contents Product Registration ............2 Exploded View ..............49 Warning / Safety Instructions Parts List ................50 Product Labels ..............3 Warranty................53 Safety Instructions .............4 Electrical Safety ..............6 Grounding Instructions ............. 7 Important Operation Instructions ....... 8 Application Specification ..........9 Operating Principle ............
  • Page 4: Product Registration

    PRODUCT REGISTRATION Thank you for your recent purchase of the 7.0T. Spirit by Dyaco WARRANTY REGISTRATION provides simple, reliable products that offer the most relevant feedback to caregivers and users to achieve best-in-class outcomes and empower individuals to build confidence in rebuilding and maintaining healthy lifestyles and keep in touch with their communities.
  • Page 5: Product Labels

    PRODUCT LABELS SERIAL NUMBER STICKER SERIAL NUMBER This sticker will be found on the back of the motor cover. Please record the number below the barcode for the purpose of registering your Treadmill’s warranty. xxxxxxxxxxxxxxxxx (870) 935-1107 PROPOSITION 65 WARNING This sticker will be found on the back of the motor cover.
  • Page 6: Safety Instructions

    3. To avoid risk of electric shock, this equipment must only be connected to a supply main with protective earth. 15. Do not use any after market parts on this 7.0T, other than those recommended by Dyaco. 4. Use this 7.0T only for it’s intended use as described in this manual.
  • Page 7 SAFETY INSTRUCTIONS 18. Hold the handlebar for support when getting on or off the 7.0T. Please ensure that you review and adhere to the user weight restrictions and power requirements of your 19. To avoid injury please observe all minimum and maximum new machine.
  • Page 8: Electrical Safety

    ƒ The 7.0T is not protected against the ingress of water or particulate matter. ƒ The 7.0T is not suitable for use in an oxygen rich environment. ƒ If not stated otherwise Spirit by Dyaco 7.0T Treadmills are designed for operation in normal climatic surroundings (IEC 60601-1): ƒ...
  • Page 9: Grounding Instructions

    GROUNDING INSTRUCTIONS This product must be grounded. In the unlikely event that the 7.0T’s electrical system should malfunction or breakdown grounding provides a path of the least resistance for electric current, reducing the risk of electric shock. This product is equipped with a cord having an equipment-grounding plug.
  • Page 10: Important Operation Instructions

    OPERATION INSTRUCTIONS WARNING! ƒ Never use the 7.0T during an electrical storm. Surges may occur in your facility power supply that could damage the 7.0T’s components. ƒ All users should have medical clearance before starting any rigorous exercise program. ƒ Start the user at a safe exercise level. Do not allow the user to be over exerted.
  • Page 11: Application Specification

    APPLICATION SPECIFICATION MEDICAL PURPOSES INTENDED CONDITIONS OF USE ƒ Patient warm-up before a physical therapy session. ƒ Environment including hygienic requirements ƒ Have the patient walk to improve ambulation and range ƒ General: intended for indoors use. This product is not designed of motion after knee/hip/ankle surgery or neurological for use outdoors, near a pool or spa, or in any other high conditions.
  • Page 12: Operating Principle

    OPERATING PRINCIPLE The operator will start the 7.0T and use the speed and incline keys to control motors. When the speed key is pressed, a signal will be sent to the AC motor inverter to request a change. The inverter will then send the appropriate amount of power the AC drive motor to reach the requested speed.
  • Page 13: Operating The 7.0T

    OPERATING THE 7.0T The 7.0T is intended to be used in aiding in the physical rehabilitation process for patients with orthopedic and neurological problems. Also used in sports medicine, wellness and general conditioning programs. TYPICAL APPLICATIONS FOR THIS TYPE OF PRODUCT ARE ƒ...
  • Page 14: Parts Included

    PARTS INCLUDED STEP1 Tools. #58- Ø10 × 2T (6PCS) #59-3/8" × 25 × 2T(6PCS) #104-3/8" × 3-3/4" (6PCS) STEP2 #113-Phillips screw driver(1PCS) #153-3/8" × 3/4"(6PCS) #58- Ø10 × 2T(6PCS) #59-3/8" × 25 × 2T(6PCS) #108-M8 × 12L (6PCS) #73-M5 × 12L(4PCS) STEP3 #137-5mm Allen wrench(1PCS) #110-M5 ×...
  • Page 15: Parts Of Your Unit

    PARTS OF YOUR TREADMILL A. Hand grips B. Electronic console C. Safety Key D. Adjustable handrails E. Handrail horizontal adjustment F. Handrail vertical adjustment G. Handrail lift bar H. Rear step I. Rear incline J. Front incline...
  • Page 16: Pre-Assembly

    PRE-ASSEMBLY 1. Cut the straps, then lift the box over the unit and unpack. 2. Carefully remove all parts from the carton and inspect for any damage or missing parts. If parts are damaged or missing, contact your dealer immediately. 3.
  • Page 17 ASSEMBLY - STEP ONE The right side upright tube (19) has the computer cables pre-installed. Lift the tube off the walking surface and attach it to the base frame. You need to gently pull on the computer cables as you align the upright tube into the bracket on the base frame, taking the slack out so the cable does not get pinched between the tube and the base frame.
  • Page 18 ASSEMBLY - STEP TWO Install the two mounting brackets (3 & 4) with the six M8 x 12mm screws (108). Refer to the important instructions on the following page for this step. Mount the console frame (5) to the upright tubes (18 &...
  • Page 19 ASSEMBLY - STEP THREE Plug all the connectors in back of the console. Mount the console (36) to the console frame (5) with two M5 x 30mm screws (112) in the top holes and two M5 x 10mm screws (110) in the bottom holes in the back side of the console frame.
  • Page 20 ASSEMBLY - STEP FOUR Install the eight 3/8” x 3/4” bolts (153) and 3/8” flat washers (59) into the holes on the underside of the frame. Only thread them into the holes two or three turns so the slots in the handrail brackets can slide onto the bolts easily.
  • Page 21: Setting Up Your Treadmill

    SETTING UP YOUR TREADMILL Plugging in Handlebar Adjustments The 7.0T A.C. mains input connector is located in the front of the 7.0T. The input module has an input connector for the line cord, a power switch and a 20 amp circuit breaker. Turn the power switch to off when the 7.0T is not in use.
  • Page 22: Quick Start

    QUICK START 1. This is the quickest way to start an exercise session. After the console powers up you just press the Start key to begin; this will initiate the Quick Start mode. In Quick Start the speed will be set to zero until the user adjusts the speed.
  • Page 23 CONSOLE SCREEN - OVERVIEW...
  • Page 24: Console Operation

    POWER ON & CONSOLE OPERATION Set up When initially powered on the console will perform an internal self-test. During this time all the lights will turn on for a short time. The message window will display a software The set up key function will allow you to enter patient data and version (i.e.
  • Page 25: Basic Information

    BASIC INFORMATION Below the message window is a heart icon and a bar graph. Wearing The dot matrix display is used for displaying graphic feedback and has an optional heart rate chest belt transmitter will start the Heart Icon three basic displays for most programs. When you begin a program, blinking (this may take a few seconds).
  • Page 26: Features

    FEATURES Forward Incline This key sets the belt direction to forward. Forward is the Press this key to return to front incline function if decline function default direction setting when the 7.0T is powered on and is active. any time the console is in the idle mode. If the belt is already Decline set in the reverse direction, it will change the direction of the belt to forward.
  • Page 27 FEATURES Deck-lift program This program allows you to raise the entire deck parallel to the floor. In this mode the deck, rear step and handrails can be used for step-up, step-down, stretching and PNF/PTA exercises. Lifting the deck while a patient walks allows the therapist to assist the patient by moving their legs without having to bend over too far.
  • Page 28: Program Operation

    PROGRAMS SETUP Selecting and Customizing Programs • During the manual program you will be able to scroll through the data in the message window by pressing the display key. You may also switch between the speed, incline or track displays by When a program is selected you have the option of pressing the display key adjacent to the dot matrix display.
  • Page 29: Preset Programs

    PRESET PROGRAMS The 7.0T has two preset exercise programs that have been designed for a variety of goals. The initial built-in level of difficulty for each program is set to a relatively easy level. You may adjust the level of difficulty (max speed) for each program before beginning.
  • Page 30 PROGRAMS PRESET - CONTINUED PRESET PROGRAMS SPEED AND INCLINE SETTINGS The preset program speed and incline levels are shown in the chart below. The Speed numbers shown in the chart indicate a percentage of the top speed of the program. Prog Warm Up Cooldown...
  • Page 31 DESIGNING AND SAVING A NEW PROGRAM • Press the facility key. The message window will show a wel- • The next segment will show the same level as the previously come message; if you had previously saved a program, the adjusted segment.
  • Page 32 VO2 TEST 6:15 6.0mph 57.7 The Vo2 test is based on the Gerkin protocol, also known 6:30 6.0mph 58.8 as the fireman’s protocol, and is a sub-max Vo2 (volume 6:45 6.0mph 60.2 of oxygen) test. The test will increase speed and elevation alternately until 85% of Max heart rate is attained.
  • Page 33 VO2 - CONTINUED Before the test After the test • Make sure you are in good health; check with your physician • Cool down for about one to three minutes. before performing any exercise if you are over the age of 35 or •...
  • Page 34 VO2 TEST - CONTINUED...
  • Page 35 SYMMETRY The symmetry program provides basic gait data calculations will use the patient information from the set up function (set information and a feedback graph. The program up key at top left of console). will measure the left and right step length and •...
  • Page 36: Data Transfer Software Instructions

    Use a USB cable (type a to type b, illustrated to the right) to connect the product and the computer. Step 1. Download the software from the link (http://www.dyaco. com/software) and connect the console of the product to the computer via USB cable. Click "Install" when you see the pop-up...
  • Page 37 DATA TRANSFER SOFTWARE INSTRUCTIONS - CONTINUED Step 2. Click “Connect” or “Change” to select the connecting port (left figure). After clicking the “Change”, or connecting to the wrong port, the COM port selection window pops up (right figure). Select the correct COM port and click “Connect”. Selecting COM port Pop-Up COM Port Selection Window...
  • Page 38 DATA TRANSFER SOFTWARE INSTRUCTIONS - CONTINUED Step 3. Recording complete After the status shows “Connected” and the product model name to the right, choose the file path and create the file name for saving the data. Click the “Record” button to start collecting data.
  • Page 39: Using A Heart Rate Transmitter

    USING A HEART RATE TRANSMITTER Note: The chest strap transmitter is not a standard part, but is you of proper operation. If you wish, you may wear the trans- a separate purchase. Most transmitters that operate at 5kHz mitter over a shirt. To do so, moisten the areas of the shirt frequency will also work.
  • Page 40 CHEST STRAP WARNING* (NOT INCLUDED) Erratic Operation Caution! Do not use this 7.0T for Heart Rate Control unless a steady, solid Actual Heart Rate value is being displayed. High, wild, random numbers being displayed indicate a problem.. Areas to look for interference which may cause erratic heart rate: 1.
  • Page 41: Heart Rate Program Operation

    HEART RATE PROGRAM OPERATION To start the HR program follow the instructions below or • When the program ends you may press Start to begin the same just press the HR key then the Enter button and follow the program again or Stop to exit the program or you can save directions in the message window.
  • Page 42: Machine Care

    MACHINE CARE Post-Workout Machine Care Sanitizing Your Spirit Fitness Equipment Wipe down all areas in the sweat path with a damp cloth • Unupholstered high-contact surfaces (hard plastics) can be after each workout. If a squeak, thump, clicking or rough sanitized using a 75% isopropyl alcohol solution and a clean, dry feeling develops the main cause is most likely one of two cloth.  Spray surfaces to be sanitized, and use the dry cloth to...
  • Page 43 MACHINE CARE Belt and deck Tighten the rear roller bolts only enough to prevent slippage at the Your 7.0T uses a very high-efficient low-friction deck and front roller. Turn both tread-belt tension adjustment bolts with belt. Performance is maximized when the bed is kept as a 10mm allen wrench in increments of 1/4 to 1/2 turn each and clean as possible.
  • Page 44 MACHINE CARE - CONTINUED Turn the bolt clockwise to move the belt to the right. Turn Maintenance menu in console software the bolt only a 1/4 turn and wait a few minutes for the belt The console has built in maintenance/diagnostic software. The to adjust itself.
  • Page 45 MACHINE CARE - CONTINUED Maintenance Mode Incline Press and hold the start, stop and enter key at the same time, • MW scrolls: “Use incline keys for front use speed keys for until the display shows “Maintenance menu” press the enter key. rear”...
  • Page 46 MACHINE CARE - CONTINUED Calibration MW: START LEFT SIDE When Start is pressed the MW shows: AD _ _ _ TGT 65 Speaker will beep slowly when magnet distance is too far, quickly when near and steady when correct. Press enter to continue MW: START RIGHT SIDE When Start is pressed the MW shows: AD _ _ _ TGT 65 Speaker will beep slowly when magnet distance is too far, quickly when near and steady when correct.
  • Page 47 MACHINE CARE - CONTINUED Factory and Acceleration Settings • Enter the Factory settings; press Start and Speed Fast keys while console is in power up reset. User presses enter UNITS: ENGLISH The default setting is English. User can press any up/down arrows to change to Metric. User presses enter. ADJUST MIN SPEED THEN PRESS ENTER Default value is 0.1 mph and can be adjusted up to 0.5mph.
  • Page 48: Troubleshooting

    ERROR MESSAGE & TROUBLESHOOTING Error Codes E9 Over I Speed E18 IGBT O-Heat Bad Drive ERR Incline Err E1 Over Current Check Brake Bad Drive Fan E30 CPU Error (Shows in Grade window) Deck Lube Deck Lube Dirty Heat Sink Electronic circuit fault ER2 Decline Err Bad Drive or Motor...
  • Page 49: Specifications

    SPECIFICATIONS 120 volts, 60 Hz, dedicated 20-amp circuit (NEMA 5-20P power plug /receptacle type ) CERTIFICATIONS CAN/CSA -C22.2 No. 60601-1:14 , ANS/AAMI ES60601-1:2005+A2 (R2012) +A1, IEC 60601-1-2:2014, EN 60601-1-2:2015, IEC 60601-1:2005+A1:2012, EN 60601-1:2006+A1:2013+A12:2014 EN ISO 20957:2013, ISO 14971; 2019...
  • Page 50 SPECIFICATIONS - CONTINUED • Note • If the device is interfered by power or signal cable, im- age quality may be reduced or abnormally displayed. Such kind of interference images could be easily identified and differentiated from the physiological characteristics of patient and longer clinical time consumed but wouldn’t have any diagnostic accuracy issue.
  • Page 51: Exploded View

    EXPLODED VIEW DIAGRAM...
  • Page 52: Parts List

    PARTS LIST Main Frame Square End Cap Incline Bracket Handpulse End Cap Console Mast Locking Assembly ( L ) Stable Wheel Spacer Console Mast Locking Assembly ( R ) Ø10 × Ø25 × 0.8T_Nylon Washer Console Support Motor Cover Anchor(D) Running Deck Stabilizer Assembly(A) Rear Adjustment Base (R) Running Deck Stabilizer Assembly(B)
  • Page 53 PARTS LIST Phillips Head Screw Driver Ø54 × 25m/m_Transportation Wheel Ø3.5 × 12L_Sheet Metal Screw Rubber Foot Ø5 × 1.5T_Spring Washer Ø37mm × 3/8"_Adjustment Foot Pad Ø5 × 0.6T_Star Washer Ø55 × 3/8"_Adjustment Foot Pad M8 × P1.25 × 35L_Flat Head Countersink Bolt Slider Sleeve Ø3 ×...
  • Page 54 PARTS LIST U-Joint, Step Sensor Breaker U-Joint Mounting Plate Grounding Brush Ø20 × M6 × 20L_Step Magnet Holde Brush Holder Plunger, Step Sensor M3 × 10L_Phillips Head Screw Linear Bushing M3 × 2.5T_Luck Nut Rotate Axle Spacer Ferrite Core(29m/m) Cover, Step Sensor Assembly Ferrite Core(21.4m/m) Ø13.5 ×...
  • Page 55: Warranty

    WARRANTY - COMMERCIAL Effective October 23, 2024- 7.0T Treadmill LIMITED WARRANTY Spirit Fitness warrants all its Treadmill parts for a period of time listed below from the date of retail sale, as determined by sale receipt, or in the absence of a sales receipt eighteen (18) months from the original factory shipping date. Spirit Fitness’ responsibilities include providing new or remanufactured parts, at Spirit Fitness’...
  • Page 56 WARRANTY - CONTINUED What is not covered? EXCLUSIONS This warranty does not cover the following: 1. CONSEQUENTIAL, COLLATERAL, OR INCIDENTAL DAMAGES SUCH AS PROPERTY DAMAGE AND INCIDENTAL EXPENSES RESULTING FROM ANY BREACH OF THIS WRITTEN OR ANY IMPLIED WARRANTY. Note: Some states do not allow the exclusion or limitation of incidental or consequential damages, so this limitation or exclusion may not apply to you.
  • Page 57 WARRANTY - CONTINUED Responsibilities of the Owner SERVICE Keep your bill of sale. Twelve (12) months from the date on the bill of sale or eighteen (18) months from the date of factory shipping as determined by the serial number establishes the labor warranty period should service be required. If service is performed, it is in your best interest to obtain and keep all receipts.
  • Page 60 3000 Nestle Road Jonesboro, AR 72401 | Phone: 800-258-8511 | Fax: 870-935-7611 www.spiritfitness.com ©2024 All Rights Reserved. 7.0T Owner’s Manual...
