- Page 1 INSTRUCTION MANUAL Kitchen Island Cart SKY8094 + SKY8095 + SKY8096 + SKY8097 + SKY8098 Ver. 1...
- Page 2 As shoppers, we’re always trying to find the perfect balance between quality & value. At BCP, we believe we’ve achieved that. Our diverse catalog of everyday essentials is tailored especially to our customers & guaranteed to hit that sweet spot of high quality & low price.
-
Page 3: Tools Required
44 LBS 11 LBS 33 LBS 33 LBS 2 PERSON UP TO 90 MIN. TOP BOARD DRAWER SHELF (EACH) BOTTOM BOARD ASSEMBLY ASSEMBLY CAPACITY CAPACITY CAPACITY CAPACITY TOOLS REQUIRED FLAT HEAD ALLEN WRENCH SMALL WRENCH POWER DRILL SCREWDRIVER (PROVIDED) (PROVIDED) (OPTIONAL) NOTICE Please retain these instructions for future reference. - Page 4 HARDWARE M6 x 35mm 15 x 9.5mm 8 x 30mm 4 x 35mm CAM BOLT CAM LOCK DOWEL SCREW 12 PCS 12 PCS 28 PCS 4 PCS HANDLE M4 x 16mm HINGE 3 x 12mm SCREW SCREW 2 PCS 4 PCS 2 PCS 22 PCS METAL PLATE...
- Page 5 PARTS ISLAND TOP ISLAND LEFT SIDE ISLAND RIGHT SIDE 1 PC 1 PC 1 PC TOP BACK SUPPORT POWER STRIP MOUNT CENTER BACK SUPPORT 1 PC 1 PC 1 PC BACK PANEL LOWER BACK CABINET TOP PANEL SUPPORT 1 PC 1 PC 1 PC CABINET BOTTOM...
- Page 6 PARTS TRAY FRONT TRAY SUPPORT TRAY LEFT SIDE 1 PC 1 PC 1 PC DRAWER FRONT DRAWER LEFT SIDE TRAY RIGHT SIDE 1 PC 1 PC 1 PC DRAWER BACK DRAWER BOTTOM DRAWER RIGHT SIDE 1 PC 1 PC 1 PC...
- Page 7 PRODUCT ASSEMBLY On one part N drawer runner, locate and press down on the release latch, then separate the guide section from the rail section. Repeat on a second runner, then set the four sections aside. RELEASE LATCH RAIL GUIDE...
- Page 8 PRODUCT ASSEMBLY Locate one part O drawer runner and attach it to the part 2 island left side with two part H screws. Slide the rail section left or right to reveal the fastener holes if necessary. Attach the guide section of the one part N drawer runner to the part 2 island left side with two part H screws.
- Page 9 PRODUCT ASSEMBLY Locate one part O drawer runner and attach it to the part 3 island right side with two part H screws. Slide the rail section left or right to reveal the fastener holes if necessary. Attach the guide section of the one part N drawer runner to the part 3 island right side with two part H screws.
- Page 10 PRODUCT ASSEMBLY Insert the part T power strip into the receiver hole on the part 5 power strip mount, then secure with two part H screws. Insert one part B cam lock and one part C dowel into the part 4 top back support, then attach it to the part 2 island left side assembly, turn the cam locks to secure.
- Page 11 PRODUCT ASSEMBLY Insert one part C dowel each into the part 6 center back support, part 8 lower back support, and part 11 lower front support, three dowels total. Attach the support panels to the part 2 island left side assembly with three part M screws, one screw per support.
- Page 12 PRODUCT ASSEMBLY Slide the part 7 back panel into the grooves between the part 6 and 8 back supports. Slide the part 10 bottom panel into the grooves between the part 8 lower back support and part 11 front support. Insert one part B cam lock and one part C dowel into the part 4 top back support.
- Page 13 PRODUCT ASSEMBLY Insert two part C dowels into the part 5 power strip mount. Insert two part B cam locks and two part C dowels into the part 9 cabinet top panel. Attach the part 3 island right side assembly to the part 4 Attach the part 3 island right side assembly to the part 4 top back panel, part 6 center back support, part 8 lower top back panel, part 6 center back support, part 8 lower...
- Page 14 PRODUCT ASSEMBLY Insert four part A cam bolts into the part 1 island top. Insert two part B cam locks and two part C dowels each into the part 2 island left side and part 3 island right side, four locks and dowels total. Attach the part 1 island top, then turn the camlocks to secure.
- Page 15 PRODUCT ASSEMBLY Use the included wrench to attach one part P locking caster and one part Q caster to the bottom of the part 2 island left side. Repeat to attach one part P locking caster and one part Q caster to the bottom of the of the part 3 island right side.
- Page 16 PRODUCT ASSEMBLY Attach the part 12 cabinet door to the part 3 island right side by securing the part G hinges with four part H screws, two screws per hinge. Locate the two rail sections of part N drawer runners (see step 1) then attach one each to the part 15 tray left side and part 16 tray right side with four part H screws, two screws per side.
- Page 17 PRODUCT ASSEMBLY Insert two part C dowels each into the part 15 and 16 tray sides, then attach them to the part 14 tray support with four part D screws. Insert two part B cam locks and two part C dowels into the part 14 tray bottom, then attach the part 13 tray front.
- Page 18 PRODUCT ASSEMBLY Slide the tray assembly into its designated space along the guide sections of the part N drawer runners. Attach one part E handle to the part 17 drawer front with two part F screws. Attach the part 19 drawer right side to the part 17 drawer front and part 20 drawer back with four part L screws.
- Page 19 PRODUCT ASSEMBLY Slide the drawer assembly into its designated space, then insert two part U screws on the part 18 and 19 drawer sides to secure the part O drawer runners. Attach three part R side hooks to the part 3 island right side with six part S screws, two screws per hook.
-
Page 20: Help Center
HELP CENTER Question about your product? We're here to help. Visit us at: help.bestchoiceproducts.com CHAT Chat Support Product Inquiry Orders FAQ Product Assembly Returns & Refunds PRODUCT WARRANTY INFORMATION All items can be returned for any reason within 60 days of the receipt and will receive a full refund as long as the item is returned in its original product packaging and all accessories from its original shipment are included.
