- Page 1 INSTRUCTION MANUAL Utility Kitchen Cart with Storage SKY3992 Ver. 2...
- Page 2 Thank you for choosing us! Since 2002, Best Choice Products has been bringing customers high-quality products at the absolute lowest price. With everything ranging from instruments and toys to furniture and outdoor, we’ve got your everyday living essentials covered. We’re centered around a customer-first philosophy –...
-
Page 3: Tools Required
NOTICE Please retain these instructions for future reference. • Please do not exceed the weight limitations of this item. • Do not stand on or use any part of this item as a step ladder. • Firmly secure all bolts, screws and knobs before use. •... - Page 4 PARTS TABLETOP LEFT SIDE CENTER RIGHT SIDE 1 PC 1 PC 1 PC 1 PC BOTTOM DRAWER SUPPORT MIDDLE DIVIDER SHELF 2 PCS 2 PCS 1 PC 2 PCS BACK DRAWER BOTTOM FRONT PANEL LEFT PANEL 2 PCS 2 PCS 2 PCS 2 PCS LEFT DOOR...
-
Page 5: Product Assembly
PRODUCT ASSEMBLY Attach a F1 railing from a part F slider set to the part 2 left side with two part D screws. Attach two F1 railings from the slider Attach a F1 railing from a slider set to the sets to the part 3 center piece with part 4 right side with two part D screws. - Page 6 PRODUCT ASSEMBLY Attach a part 6 drawer support to the part 2 left side and part 3 center piece with four part A cam bolts and four part B cam locks. Attach a part 7 middle divider with four part A cam bolts and four part B cam locks.
- Page 7 PRODUCT ASSEMBLY Attach two part P magnets to the drawer supports with four part Q screws. Attach the part 5 bottom piece with six part I screws and six part C dowels. Pg. 7...
- Page 8 PRODUCT ASSEMBLY Attach four part J casters with sixteen part K screws, four screws per caster. Stand the cart upright and slide in two part 9 back pieces. Pg. 8...
- Page 9 PRODUCT ASSEMBLY Attach the part 1 tabletop with six part A cam bolts, six part C dowels, and six part B cam locks. Turn the cam locks to secure the tabletop. Attach a part G handle to a part 15 left door with two part H screws.
- Page 10 PRODUCT ASSEMBLY Attach a part 15 left door and part 16 right door Attach eight part M hinges with eight part D screws, two screws per hinge. to left/right doors with Repeat to attach the other set of doors. sixteen part D screws, two screws per hinge.
- Page 11 PRODUCT ASSEMBLY Attach a part 12 left panel and part 13 right panel to a part 14 back panel with four part E screws. Slide in a part 10 drawer bottom. Attach two F2 railings from a part F slider set to Attach a part G handle to the part 11 front panel the drawer with four part D screws.
-
Page 12: Product Warranty Information
ENJOY YOUR PRODUCT! Insert the drawers by lining up the railings on the slider sets. PRODUCT WARRANTY INFORMATION All items can be returned for any reason within 60 days of the receipt and will receive a full refund as long as the item is returned in its original product packaging and all accessories from its original shipment are included.
