- Page 1 INSTRUCTION MANUAL Dual Wheel Wheelbarrow SKY2705 + SKY7886 + SKY7887 + SKY7888 + SKY7889 + SKY7890 SKY7891 + SKY7892 + SKY7893 + SKY7894 + SKY7895 Ver. 3...
-
Page 2: Tools Required
NOTICE • Please do not exceed the weight limitations of this item. • Use a hand or foot pump to inflate tires to a 330 LBS 1 PERSON UP TO 30 MIN. maximum of 25 PSI. ASSEMBLY ASSEMBLY CAPACITY • Do not sit or ride in this wheelbarrow. -
Page 3: Back Frame
PARTS BACK FRAME FRONT FRAME CENTER SUPPORT 2 PCS 1 PC 1 PC HANDLE AXLE TRAY 1 PC 1 PC 1 PC PLASTIC SPACER WHEEL 2 PCS 2 PCS... -
Page 4: Product Assembly
PRODUCT ASSEMBLY Please retain these instructions for future reference. Attach the two part A back frames to the part B front frame with two part 2 bolts, two part 3 washers, two part 4 spring washers, and two part 5 nuts. - Page 5 PRODUCT ASSEMBLY Attach part C center support with two part 2 bolts, two part 3 washers, two part 4 spring washers, and two part 5 nuts. Insert part D handle.
- Page 6 PRODUCT ASSEMBLY Attach the part F tray to the part B front frame with two part 2 bolts, two part 3 washers, two part 4 spring washers, and two part 5 nuts. Place two part G plastic spacers between the tray and handle. Attach the tray to the handle with two part 1 bolts, two part 3 washers, two part 4 spring washers, and two part 5 nuts.
- Page 7 PRODUCT ASSEMBLY Slide the part E axle through the front frame. Slide a part H wheel onto the axle and secure it with a part 6 axle washer and part 7 cotter pin. Repeat to attach the other wheel. Use the air pump to inflate the wheels to a maximum of 25 PSI. Use pliers to bend the pin and lock the wheel in place.
-
Page 8: Help Center
HELP CENTER Question about your product? We're here to help. Visit us at: help.bestchoiceproducts.com CHAT Chat Support Product Inquiry Orders FAQ Product Assembly Returns & Refunds PRODUCT WARRANTY INFORMATION All items can be returned for any reason within 60 days of the receipt and will receive a full refund as long as the item is returned in its original product packaging and all accessories from its original shipment are included.
