- Page 1 INSTRUCTION MANUAL Mobile Kitchen Island Cart SKY3993 Ver. 2...
- Page 2 As shoppers, we’re always trying to find the perfect balance between quality & value. At BCP, we believe we’ve achieved that. Our diverse catalog of everyday essentials is tailored especially to our customers & guaranteed to hit that sweet spot of high quality & low price.
-
Page 3: Tools Required
NOTICE Please retain these instructions for future reference. • Please do not exceed the weight limitations of this item. • Do not stand on or use any part of this item as a step ladder. • Firmly secure all bolts, screws, and knobs before use. •... -
Page 4: Bottom Panel
HARDWARE OUTER INNER OUTER INNER RAILING (L) RAILING (R) RAILING (R) RAILING (L) 1 PC 1 PC 1 PC 1 PC PARTS TABLETOP LEFT SIDE RIGHT SIDE 1 PC 1 PC 1 PC DIVIDER BOTTOM PANEL SHELF I 1 PC 1 PC 1 PC SLOTTED SHELF... - Page 5 PARTS FRONT SUPPORT LEFT ARM RIGHT ARM 1 PC 1 PC 1 PC TOWEL RACK DOOR DRAWER FRONT 1 PC 1 PC 1 PC DRAWER LEFT DRAWER RIGHT DRAWER BACK 1 PC 1 PC 1 PC DRAWER BOTTOM BACK PANEL 1 PC 1 PC...
-
Page 6: Product Assembly
TIGHTENING CAMLOCKS Screw cam bolt Insert cam bolt and cam lock into Screw cam lock in completely. designated holes. clockwise to secure cam bolt. PRODUCT ASSEMBLY Screw six part A cam bolts into the part 1 tabletop. Screw a cam bolt into the part 10 front support. - Page 7 PRODUCT ASSEMBLY PRODUCT ASSEMBLY Screw two part A cam bolts into the part 4 divider. Attach part S outer railing (right) with two part M screws. USE THESE HOLES Place the part 13 towel rack between the part 11 and 12 arms. Attach the arms to the part 2 left side with two part C dowels, two part D bolts, and two part E anchor nuts.
- Page 8 PRODUCT ASSEMBLY Flip the part 2 left side over. Screw two part A cam bolts into the left side. Attach part Q outer railing (left) with two part M screws. USE THESE HOLES Attach the part 16 and part 17 drawer sides to part 18 drawer back with four part L screws. Slide in part 19 drawer bottom.
- Page 9 PRODUCT ASSEMBLY Screw four part A cam bolts into part 15 drawer front. Attach the drawer front with four part B cam locks. Attach a part H handle with two part G screws. Attach part R and part T inner railings with four part M screws.
- Page 10 PRODUCT ASSEMBLY Attach part 9 back support and part 10 front support with three part B cam locks. Attach part 5 bottom panel with two part C dowels and two part K screws. Attach part 6 shelf with two part D bolts and two part E anchor nuts. Attach part 7 slotted shelf with two part C dowels.
- Page 11 PRODUCT ASSEMBLY Attach part 2 left side with two part B cam locks, four part C dowels, five part D bolts, and five part E anchor nuts.
- Page 12 PRODUCT ASSEMBLY Attach part 3 right side with two part C dowels, three part D bolts, and three part E anchor nuts. Slide in the part 20 back panel.
- Page 13 PRODUCT ASSEMBLY Attach the part 1 tabletop with six part C dowels and six part B cam locks.
- Page 14 PRODUCT ASSEMBLY Screw in two part I locking casters and two part J casters. NOTE: If necessary, carefully flip cart over to install casters. Attach part F magnetic catch with two part M screws. Attach part H handle to part 14 door with two part G screws.
- Page 15 PRODUCT ASSEMBLY Insert four part P shelf pegs. Angle the part 8 shelf onto the pegs. Insert the drawer by lining up the railings.
-
Page 16: Help Center
HELP CENTER Question about your product? We're here to help. Visit us at: help.bestchoiceproducts.com CHAT Chat Support Product Inquiry Orders FAQ Product Assembly Returns & Refunds PRODUCT WARRANTY INFORMATION All items can be returned for any reason within 60 days of the receipt and will receive a full refund as long as the item is returned in its original product packaging and all accessories from its original shipment are included.
