- Page 1 INSTRUCTION MANUAL Steel Garden Wagon with Handle SKY2567 Ver. 2...
- Page 2 Thank you for choosing us! Since 2002, Best Choice Products has been bringing customers high-quality products at the absolute lowest price. With everything ranging from instruments and toys to furniture and outdoor, we’ve got your everyday living essentials covered. We’re centered around a customer-first philosophy –...
- Page 3 NOTICE Please retain these instructions for future reference. • Please do not exceed the weight limitations of this item. • Use a hand or foot pump to inflate tires to a maximum of 25 PSI. • Do not sit or ride in this wagon. •...
- Page 4 PARTS BOTTOM FRAME REAR AXLE FRAME REAR STRUT 1 PC 2 PCS 1 PC YOKE HANDLE WHEEL 1 PC 1 PC 4 PCS FRONT PANEL REAR PANEL SIDE PANEL 1 PC 1 PC 2 PCS FRONT AXLE CENTER BRACE FRONT AXLE 1 PC 1 PC Pg.
- Page 5 PRODUCT ASSEMBLY Please retain these instructions for future reference. Attach part C rear struts to both ends of part B rear axle frame. Use a part 3 bolt, part 5 nut, and part 9 flat washer to attach part D yoke, part J front axle, and part L front axle brace together.
- Page 6 PRODUCT ASSEMBLY Attach part G front panel, part I side panels, and part H rear panel to part A bottom frame using two part 1 B pins for each panel. Attach the completed item from step 1 to part A bottom frame using six part 3 bolts, six part 5 nuts, and six part 9 washers.
- Page 7 PRODUCT ASSEMBLY Attach part 8 handle coupler and part E handle to part D yoke using a part 4 bolt, part 5 nut, and part 9 washer. NOTE: Firmly tighten the hardware at the end of this step Insert four part F wheels into part J front axle and part B rear axle frame using a part 2 washer and part 6 nut for each wheel.
- Page 8 ASSEMBLY IS COMPLETE! PRODUCT WARRANTY INFORMATION All items can be returned for any reason within 60 days of the receipt and will receive a full refund as long as the item is returned in its original product packaging and all accessories from its original shipment are included. All returned items will receive a full refund back to the original payment method.
