A high-level signal can be run from the source unit’s speaker outputs to the stereo RCA input on the end panel of the amplifi er using the KICKER KISL as shown (make sure you set the KPA amplifi...
Page 3
KICKER KISL (optional) to amplifi er core conductor source unit high-level speaker outputs – to amplifi er shield from source unit high- level speaker outputs Install a fuse within 18” (45cm) of the battery and in-line with the power cable connected to your amplifi er. If you ever need to remove the amplifi...
Input Level: The RCA inputs on KICKER KPA amplifi ers are capable of receiving either Hi or Low-level signals from your source unit. If the only output available from your source unit is a Hi-Level signal, simply press in the Input Level switch on the amplifi...
There are Power (PWR) & Protection (PRT) LEDs on the side panel of your Kicker KPA series amplifi er. Depending on the state of the amplifi er and the vehicle’s charging system, the LEDs will glow either green or red. When the green LED is lit, this indicates the amplifi...
Page 8
ALTO, BAJO o APAGADO; 100Hz fi jo a 12dB/Octava Reforzador de bajos KickEQ™ 0 o +9dB seleccionable a 40Hz Nota: Para obtener el mejor rendimiento de sus nuevos amplifi cadores KICKER, le recomendamos que use accesorios y cableado KICKER auténticos. AMPLIFICADOR INSTALACIÓN Montaje: Escoja un lugar estructuralmente sólido para montar el amplifi...
Page 9
RCA del panel de extremo del amplifi cador o simplifi car la instalación mediante un KISL KICKER como se muestra a continuación.
Page 10
SUBWOOFER RENDIMIENTO Modelo: CDF12 Woofer [in, cm] 12, 30 Manejo de potencia maximo [vatios] Manejo de potencia recomendado [Vatios RMS] 75–150 Impedancia nominal [Ω] Respuesta de frecuencia [Hz] 27–500 Sensibilidad [1V, 1 m] 92.3dB Profundidad del gabinete [pul., cm.] 14 3/16, 36 Altura del gabinete [pul., cm.] 7 7/8, 19.5 Ancho del gabinete [pul., cm.]...
Page 11
FUNCIONAMIENTO EN PUENTE (MONOFÓNICO) impedancia mínima de 4 ohmios en puente 2022 KKPDF212 Rev C.indd 11 2022 KKPDF212 Rev C.indd 11 6/9/2022 4:27:21 PM 6/9/2022 4:27:21 PM...
6V de las salidas de altavoz de alto nivel cuando la unidad fuente se ha encendido. Nivel de Entrada: Las entradas RCA de los amplifi cadores KPA de KICKER aceptan señales de bajo nivel o alto nivel procedentes de la unidad fuente. Si la única salida disponible de la unidad fuente es una señal de alto nivel, oprima y deje adentro el selector de nivel de entrada del amplifi...
Page 13
Si tiene más preguntas sobre la instalación de su nuevo producto KICKER, vaya al distribuidor autorizado de KICKER donde lo compró. Si necesita más consejos sobre la instalación, haga clic en la lengüeta SUPPORT (apoyo) de la página Web de KICKER, www.kicker.com.
Page 14
Auswählbar: HI, LO oder OFF; 100 Hz @ 12 dB/Oktave KickEQ™ Bassverstärker Wählbar 0 oder +9dB @ 40Hz Hinweis: Um das Maximum aus Ihrem neuen KICKER-Verstärker herauszuholen, sollten Sie echtes KICKER- Zubehör und KICKER-Kabel verwenden. VERSTÄRKER INSTALLATION Befestigung: Wählen Sie für die Installation des KICKER-Verstärkers eine strukturell stabile Stelle. Vergewissern Sie sich, dass sich hinter der Einschraubposition der Schrauben nichts befi...
Page 15
Hochpegel-Lautsprecherausgängen am Autoradio und verbinden Sie das Kabel mit den RCA-Eingängen an der Endplatte des Verstärkers, oder Vereinfachung der Installation, indem Sie ein KICKER KISL wie unten gezeigt. Alternativ können Sie Ihre Quelle Einheit Cinch-Ausgänge zum KPA Verstärker Cinch-Eingänge anschließen.
Wenn der Verstärker nicht zu funktionieren scheint, sollten Sie zuerst offensichtliche Faktoren prüfen, wie durchgebrannte Sicherungen, schlechte oder fehlerhafte Verkabelung, inkorrekte Einstellung des Crossover-Schalters und der Verstärkungsregler etc. Am seitlichen Einschaltfeld des Kicker KPA-Verstärkers befi nden sich eine Netz-LED (PWR) und eine Schutz-LED (PRT). Abhängig vom Einschaltzustand des Verstärkers und des Ladesystems des Fahrzeugs leuchten die LED-Anzeigen grün oder rot.
Page 19
Verringerte Basswiedergabe? Wechseln Sie einen Lautsprecheranschluss an den Stereo-/Subwooferkanälen von Positiv zu Negativ; wenn der Bass nun besser klingt, war der Lautsprecher phasenverschoben. Störung durch Erdung? KICKER-Verstärker sind mit den Autoradios aller Hersteller kompatibel. Manche Autoradios erfordern eventuell weitere Erdung, um Störungen am Audiosignal zu verhindern.
Page 20
12 dB/octave Amplifi cation de basses fréquences KickEQ™ Sélectionnable 0 ou +9 dB à 40 Hz Remarque : Pour optimiser les performances de votre nouvel amplifi cateur KICKER, il est conseillé d’utiliser des accessoires et des câbles KICKER d’origine. AMPLIFICATEUR INSTALLATION Montage: Choisissez un emplacement de structure saine pour monter votre amplifi...
Page 21
fi l aux entrées RCA sur le panneau d’extrémité de l’amplifi cateur, ou de simplifi er l’installation avec une KISL KICKER, comme indiqué ci-dessous. Alternativement, vous pouvez connecter les sorties de votre unité source RCA aux entrées de l’amplifi cateur KPA RCA. Réglez le commutateur de niveau d’entrée sur le panneau d’extrémité...
Se présentent également des DEL d’alimentation (PWR) et de protection (PRT) sur le panneau d’alimentation latéral de votre amplifi cateur KICKER de série CX. Selon l’état de l’amplifi cateur et le système de charge du véhicule, les DEL clignotent en vert ou rouge. Lorsque la DEL vert est allumée, cela indique que l’amplifi cateur est en marche et qu’il n’y a pas de problème.
Page 25
L’amélioration des graves indique que le haut-parleur était déphasé. Bruit de fond ? Les amplifi cateurs KICKER ont été étudiés pour être entièrement compatibles avec les unités de tête de tous les fabricants. Certaines unités de tête peuvent exiger une mise à la masse supplémentaire pour éviter toute interférence avec le signal audio.
Sea precavido cuando controle el volumen. La frase “combustible para vivir la vida Livin’ Loud™ a todo volumen” se refi ere al entusiasmo por la vida que la marca KICKER de estéreos de automóvil representa y a la recomendación a nuestros clientes de que vivan lo mejor posible (“a todo volumen”) en todo sentido.
