  • Page 1 Idea Opera ® Aluminium coated cars INSTALLATION AND COMMISSIONING INSTRUCTIONS...

  • Page 2: Table Of Contents

    LIFTINGITALIA S.r.l. Via Cadu� del Lavoro, 16 - 43058 Bogolese, Sorbolo (PR) - Italy Phone +39 0521.695311 - Fax +39 0521.695313 20230626 PURPOSE OF THE MANUAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 PERSONAL SECURITY AND RISK RECOGNITION .

  • Page 3: Purpose Of The Manual

    LIFTINGITALIA S.r.l. Via Cadu� del Lavoro, 16 - 43058 Bogolese, Sorbolo (PR) - Italy Phone +39 0521.695311 - Fax +39 0521.695313 SCOPO DEL MANUALE PURPOSE OF THE MANUAL The purpose of this manual is to provide correct informati on on the installati on of the product, in order to contribute to personal safety and to the proper functi oning of the system.

  • Page 4: Manual Reading Guide

    IDEA / OPERA Car - Aluminium coated cars INSTALLATION AND COMMISSIONING INSTRUCTIONS GUIDA ALLA LETTURA DEL MANUALE MANUAL READING GUIDE WARNING SIGN GENERAL DANGER ELECTRICITY DANGER DANGER FLAMMABLE MATERIAL DANGER OF FALL BY A LEVEL DANGER SUSPENDED LOADS DANGER OF CRUSHING PROHIBITION SIGN PROHIBITED TO WALK ON OR STOP GENERIC PROHIBITION...

  • Page 5: General Dispositions And Installation Site Menagement

    Should any anomalies or damage be found, please dispatch them in writi ng on the transport document to the transport company, giving writt en noti ce to LIFTINGITALIA S.r.l. NOTE: In this manual, we will talk about "SHAFT" meaning for it the base slab, the slab of landing and the verti cal wall that connects its slabs.

  • Page 6: Installation Site - Components Positioning

    LIFTINGITALIA S.r.l. Via Cadu� del Lavoro, 16 - 43058 Bogolese, Sorbolo (PR) - Italy Phone +39 0521.695311 - Fax +39 0521.695313 1 .2 . POSIZIONAMENTO DEL MATERIALE IN CANTIERE INSTALLATION SITE - COMPONENTS POSITIONING NOTICE COMPONENTS POSITIONING: It is important to position the material correctly on the installation site since once the scaffolding has been assembled it could become difficult to move some components, with the risk of injury and damage to the materials.

  • Page 7: Product Description

    IDEA / OPERA Car - Aluminium coated cars INSTALLATION AND COMMISSIONING INSTRUCTIONS PRODUCT DESCRIPTION DESCRIZIONE PRODOTTO 2 .1 . DESCRIZIONE GENERALE E TERMINOLOGIA GENERAL DESCRIPTION AND TERMINOLOGY view from outside the cabin view from inside the car Ceiling IDEA CAR OPERA CAR C.O.P.

  • Page 8: Components Identification

    IDEA / OPERA Car - Aluminium coated cars INSTALLATION AND COMMISSIONING INSTRUCTIONS 2 .2 . COMPONENTS IDENTIFICATION RICONOSCIMENTO DEI COMPONENTI WALLS FRONT ANGLES C.O.P. CEILING BARRIER BASEMENT IM.TEC.062.EN_rev.2.1 (30) All rights reserved - June 2023...

  • Page 9: Tools And Materials Required For Installation

    LIFTINGITALIA S.r.l. Via Cadu� del Lavoro, 16 - 43058 Bogolese, Sorbolo (PR) - Italy Phone +39 0521.695311 - Fax +39 0521.695313 TOOLS AND MATERIALS REQUIRED FOR INSTALLATION ATTREZZATURE E MATERIALI NECESSARI PER IL MONTAGGIO INFORMATION Tape measure Spirit level Hoist...

  • Page 10: Box Content - Screws Kit

    IDEA / OPERA Car - Aluminium coated cars INSTALLATION AND COMMISSIONING INSTRUCTIONS BOX CONTENT - SCREWS KIT CONTENUTO DELL’IMBALLO - KIT VITERIA INFORMAZIONI NOTE: Each “KIT” box with its identification code represents the packaging unit, i.e. how many pieces per type are contained in each package..
  • Page 11 LIFTINGITALIA S.r.l. Via Cadu� del Lavoro, 16 - 43058 Bogolese, Sorbolo (PR) - Italy Phone +39 0521.695311 - Fax +39 0521.695313 KIT D003 .23 .0001 KIT C002 .23 .0023 M8X20 M5X10 TCEI M6X20 M8X10 M6X16 Ø8 KIT C002 .23 .0009 - C002 .23 .0015 Ø10...

  • Page 12: Basement Assembly

    LIFTINGITALIA S.r.l. Via Cadu� del Lavoro, 16 - 43058 Bogolese, Sorbolo (PR) - Italy Phone +39 0521.695311 - Fax +39 0521.695313 BASEMENT ASSEMBLY MONTAGGIO DEL BASAMENTO NOTICE The car BASEMENT must be completely installed, before proceeding with the car assembly.

  • Page 13: Car Assembly

    IDEA / OPERA Car - Aluminium coated cars INSTALLATION AND COMMISSIONING INSTRUCTIONS CAR ASSEMBLY MONTAGGIO DELLA CABINA NOTICE Before proceeding with the car assembly, make sure the BASEMENT is perfectly leveled. PREPARAZIONE DEI MONTANTI 6 .1 . UPRIGHT PREPARATION a. Install the slide on the upright using the pre-arranged bracket KIT C002 .23 .0002 M6x16 M6x16...
  • Page 14 LIFTINGITALIA S.r.l. Via Cadu� del Lavoro, 16 - 43058 Bogolese, Sorbolo (PR) - Italy Phone +39 0521.695311 - Fax +39 0521.695313 a. Install the barrier on the pre-arranged upright KIT C002 .23 .0008 M4x16 IM.TEC.062.EN_rev.2.1 (30) www.li� ingitalia.com - info@li� ingitalia.com...

  • Page 15: Uprights Fixing To The Basement

    IDEA / OPERA Car - Aluminium coated cars INSTALLATION AND COMMISSIONING INSTRUCTIONS . Follow the assembly drawing to install the FRONTS, the WALLS, and the ANGLES. INFORMATION This manual applies to a single entrance car. To check the installation steps, please consult the project drawings enclosed with the scope of the supply.

  • Page 16: Wall Fixing

    LIFTINGITALIA S.r.l. Via Cadu� del Lavoro, 16 - 43058 Bogolese, Sorbolo (PR) - Italy Phone +39 0521.695311 - Fax +39 0521.695313 FISSAGGIO DELLE PARETI WALL FIXING 6 .3 . a. to UPRIGHTS a. to ANGLES KIT C002 .23 .0010 M6x16 It is possible to preassembly the front uprights and the angles onto the walls, especially in case of limited shaft dimensions.

  • Page 17: Ceiling - Mounting

    IDEA / OPERA Car - Aluminium coated cars INSTALLATION AND COMMISSIONING INSTRUCTIONS • Install the front CROSSBEAM (KIT KIT C002 .23 .0010 C002.23.0010). M6x16 6 .4 . INSTALLAZIONE CIELO CEILING - MOUNTING • Position the CEILING. INFORMATION Remove the central panel from the ceiling before the installation. IM.TEC.062.EN_rev.2.1 (30) All rights reserved...
  • Page 18 IDEA / OPERA Car - Aluminium coated cars INSTALLATION AND COMMISSIONING INSTRUCTIONS 6 .5 . ACCESSO AL VANO IN CASO DI CONTROCIELO ACCESS TO THE SHAFT IN THE PRESENCE OF SUSPENDED CEILING INFORMATION The counter ceiling is supplied pre-installed and pre-wired. •...
  • Page 19 LIFTINGITALIA S.r.l. Via Cadu� del Lavoro, 16 - 43058 Bogolese, Sorbolo (PR) - Italy Phone +39 0521.695311 - Fax +39 0521.695313 • Fix the ceiling onto the walls. KIT C002 .23 .0010 12 x M6x16 INFORMATION It is possible to preassembly the cage nuts in the wall holes.
  • Page 20 IDEA / OPERA Car - Aluminium coated cars INSTALLATION AND COMMISSIONING INSTRUCTIONS • Fix the walls to the basement. KIT C002 .23 .0010 12 x M6x16 INFORMATION It is possible to preassembly the cage nuts in the wall holes. It is possible to pre-assemble the cage nuts on the slots of the walls.
  • Page 21 LIFTINGITALIA S.r.l. Via Cadu� del Lavoro, 16 - 43058 Bogolese, Sorbolo (PR) - Italy Phone +39 0521.695311 - Fax +39 0521.695313 • Fix the cover to the crossbeam. KIT C002 .23 .0012 M4x16 M4x16 The cover is not foreseen in case of automatic doors.
  • Page 22 IDEA / OPERA Car - Aluminium coated cars INSTALLATION AND COMMISSIONING INSTRUCTIONS • Fix the protection panel on the access sides. KIT C002 .23 .0007 M5x16 • Fix the vertical protection on the slide side. KIT C002 .23 .0002 M4x16 IM.TEC.062.EN_rev.2.1 (30) All rights reserved...
  • Page 23 LIFTINGITALIA S.r.l. Via Cadu� del Lavoro, 16 - 43058 Bogolese, Sorbolo (PR) - Italy Phone +39 0521.695311 - Fax +39 0521.695313 • Remove the protection panel from the lamps on the COP side (if foreseen); • Install the plate with the pre-installed components onto the panel;...

  • Page 24: Access To The Shaft In The Presence Of Suspended Ceiling

    IDEA / OPERA Car - Aluminium coated cars INSTALLATION AND COMMISSIONING INSTRUCTIONS • Install the C.O.P. contact. KIT C002 .23 .0004 M4x40 M5x10 INFORMATION For safety contacts connection, consult the electrical scheme. • Fix the C.O.P. in the car. KIT C002 .23 .0014 INFORMATION Pay attention when handling the C.O.P.

  • Page 25: Handrail - Installation

    LIFTINGITALIA S.r.l. Via Cadu� del Lavoro, 16 - 43058 Bogolese, Sorbolo (PR) - Italy Phone +39 0521.695311 - Fax +39 0521.695313 6 .6 . INSTALLAZIONE DEL CORRIMANO HANDRAIL - INSTALLATION ALUMINUM HANDRAIL - INSTALLATION • Fix the inserts to the wall using the supplied screws C .

  • Page 26: Handrail - Installation

    IDEA / OPERA Car - Aluminium coated cars INSTALLATION AND COMMISSIONING INSTRUCTIONS • Adjust the car holding brackets (already fitted – see the manual) and fix them inside the slots on the car ceiling. KIT F350 .23 .0005 RIVELOX Ø10 Ø10 IM.TEC.062.EN_rev.2.1 (30)
  • Page 27 LIFTINGITALIA S.r.l. Via Cadu� del Lavoro, 16 - 43058 Bogolese, Sorbolo (PR) - Italy Phone +39 0521.695311 - Fax +39 0521.695313 CAR DOOR DRIVE SPECIAL FIXING FISSAGGIO OPERATORI SPECIALI FERMATOR - 40/10 DC 24 V - CAR DOOR DRIVE M8x20 Ø8...
  • Page 28 LIFTINGITALIA S.r.l. Via Cadu� del Lavoro, 16 - 43058 Bogolese, Sorbolo (PR) - Italy Phone +39 0521.695311 - Fax +39 0521.695313 WITTUR HYDRA 3000 CAR DOOR DRIVE WITTUR MDS1 CAR DOOR DRIVE IM.TEC.062.EN_rev.2.1 (30) www.li� ingitalia.com - info@li� ingitalia.com - June 2023...
  • Page 29 LIFTINGITALIA S.r.l. Via Cadu� del Lavoro, 16 - 43058 Bogolese, Sorbolo (PR) - Italy Phone +39 0521.695311 - Fax +39 0521.695313 IM.TEC.062.EN_rev.2.1 (30) www.li� ingitalia.com - info@li� ingitalia.com - June 2023...

  • Page 30: Technical Support
