Navigate measurements
Delete selected
measurement
Each time the red record 'Take measurement' button is pressed, the leak noise acquired in the
previous three seconds is recorded and displayed as a vertical bar on a histogram. In the
example above, eleven consecutive readings have been taken by stepping the ground
microphone along the length of the pipe and pressing the sample button at each position. This
indicates the greatest leak noise acquired and the probable position of the leak.
Selected measurement
Date and time of measurement
Delete all measurements
Noise level indicator
Noise level of selected
measurement
Survey Mode
Take measurement
