User Manual
ENGLISH
Power & Energy Logger
Models
PEL 112 & PEL 113
POWER & ENERGY LOGGERS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PEL 112 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AEMC instruments PEL 112

Summary of Contents for AEMC instruments PEL 112

  • Page 1 User Manual ENGLISH Power & Energy Logger Models PEL 112 & PEL 113 POWER & ENERGY LOGGERS...
  • Page 2 Copyright Chauvin Arnoux , Inc. d.b.a. AEMC Instruments. All rights reserved. © ® ® No part of this documentation may be reproduced in any form or by any means (including electronic storage and retrieval or translation into any other language) without prior agreement and written consent from Chauvin Arnoux , Inc., as governed by United States and International copyright laws.

  • Page 3: Statement Of Compliance

    Refer to our repair and calibration section at www.aemc.com/calibration. Serial #: Catalog #: 2137.53, 2137.54 / 2137.63, 2137.64 Model #: PEL 112 / PEL 113 Please fill in the appropriate date as indicated: Date Received: Date Calibration Due: Chauvin Arnoux , Inc.

  • Page 4: Table Of Contents

    TABLE OF CONTENTS 1. INTRODUCTION...............8 1.1 INTERNATIONAL ELECTRICAL SYMBOLS ......... 8 1.2 DEFINITION OF MEASUREMENT CATEGORIES (CAT) ... 8 1.3 PRECAUTIONS FOR USE ............9 1.4 RECEIVING YOUR SHIPMENT ............. 9 1.5 PRODUCT PACKAGING .............. 10 1.6 ORDERING INFORMATION ............11 1.6.1 Accessories ..................
  • Page 5 4. OPERATION ................34 4.1 HOOKING UP TO THE DISTRIBUTION SYSTEM ..... 34 4.1.1 Single Phase 2-Wire: 1P-2W ............34 4.1.2 Single Phase 3-Wire (Split Phase from a Center Tap Transformer): 1P-3W ................35 4.1.3 3-Phase 3-Wire Power Networks ..........35 4.1.3.1 3-Phase 3-Wire ∆...
  • Page 6 4.3.3 Harmonics ................57 4.3.3.1 Single-phase, 2-wire (1P-2W) ............. 57 4.3.3.2 Two-phase, 3-wire (1P-3W) ............57 4.3.3.3 Three-phase, 3-wire, unbalanced (3P-3WΔ2, 3P-3WΔ3, 3P-3WO2, 3P-3WO3, 3P-3WY2, 3P-3WY3) .......... 58 4.3.3.4 Three-phase, 3-wire ∆, balanced (3P-3W∆b) ......58 4.3.3.5 Three-phase, 4-wire, unbalanced (3P-4WY, 3P-4WY2, 3P-4WΔ, 3P-4WO) ..................
  • Page 7 7. MAINTENANCE ..............82 7.1 BATTERY ..................82 7.2 CLEANING ..................82 7.3 UPDATING THE FIRMWARE ............83 7.4 REPAIR AND CALIBRATION ............84 7.5 TECHNICAL ASSISTANCE ............84 7.6 LIMITED WARRANTY ..............85 7.6.1 Warranty Repairs ................. 85 8. APPENDIX A ................86 8.1 MEASUREMENTS .................

  • Page 8: Introduction

    Example: hardwired equipment in fixed installation and circuit breakers. CAT II: Corresponds to measurements performed on circuits directly connected to the electrical distribution system. Example: measurements on household appliances and portable tools. Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 9: Precautions For Use

    Save the damaged packing container to substantiate your claim. Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 10: Product Packaging

    Cat. #2140.48 Cat. #2140.44 Replacement is Qty of (1) (Only Shipped with Replacement reeling box is PEL 112 Cat. #2137.53 & sold separately (Qty 1) PEL 113 Cat. #2137.54) Cat. #5000.77 Cable - USB Type A to (1) Set of (12) Color...

  • Page 11: Ordering Information

    B cable, 5 ft 115 V power cord, NiMH AAA 8.4 V battery (installed), quick start guide, and USB drive with DataView software and user manual. ® Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 12: Accessories

    Cable reeling box for organizing leads less than 10 ft ...... Cat. #5000.77 Order Accessories and Replacement Parts Directly Online Check our Storefront at www.aemc.com/store for availability Dataview Software Updates are Available at www.aemc.com ® Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 13: Features

    2. FEATURES 2.1 DESCRIPTION PEL: Power and Energy Logger The PEL 112 and PEL 113 are simple-to-use, single-, dual- (split-phase) and three-phase (Y, ∆) Power & Energy Loggers. The PEL offers all the necessary functions for Power/Energy data logging for most of the (50, 60, 400) Hz and DC distribution systems worldwide, offering numerous distribution set-ups.

  • Page 14: Front Of Instrument

    See § Four voltage input terminals. Three current input terminals. Rigid molded casing over-molded with thermo-adhesive rubber. Digital LCD displaying measured, calculated and parameterizing quantities (PEL 113 only). Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 15: Back Of Instrument

    Table 1 2.3 BACK OF INSTRUMENT Figure 2 Item Designation Four magnets (molded into the rubber casing). Six recessed Torx screws (for factory service use only). ® Table 2 Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 16: Input Terminals

    ■ Detach the appropriate inserts from the color-coded marker and place them in the holes provided under the terminals (larger inserts for current terminals, smaller inserts for voltage terminals). Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 17: Connections

    Figure 4 2.5 CONNECTIONS Figure 5 Item Designation See § Power Cord Connector 3.2.1 SD-card Slot 2.10 USB Connector Ethernet RJ 45 Connector Table 4 Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 18: Mounting And Location

    In the measurement and power display modes, serves to display the phase angle values and partial energies (see § 4.6.1). Navigation Buttons (PEL113): These are used to browse the data displayed on the LCD screen. Table 5 Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 19: Lcd (Pel 113)

    PEL by the user through the PEL Control Panel. Measurements or display page titles. Measurement values. Status icons. Measured units Mode icons Table 6 Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 20: Status And Mode Icons

    ■ Phase order for voltage and current channels is displayed when the other screens are displayed. ■ The source and load must be parameterized using the PEL Control Panel to define the direction of the energy (imported or exported). Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 21: Status Indicators

    - Indicator lit green: SD-card is present, recognized, and unlocked - Indicator blinking light green: SD-card will be full before the end of the progress or pending recording Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 22: Sd-Card

    SD-card ready for use. Data recording sessions are stored on the SD-card. The PEL 112 and PEL 113 accept SD, SDHC and SDXC cards, FAT32 formatted, up to a capacity of 32 GB. If a replacement SD-card is unformatted, you will need to format it before use. It is best to format the SD-card using the PEL Control Panel, otherwise format using a PC.

  • Page 23: Memory Capacity

    Downloading over USB and Ethernet may be acceptable depending on the session size and network speed. We recommend putting the SD-card into your PC directly or with the external card reader for fastest download time. Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 24: Configuration

    PEL is connected to a live power outlet. Battery life is limited to approximately 1/2 h when the battery is fully charged, enough to cover brief power outages. Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 25: Turning Off

    ■ When the battery level is too low and a Low Bat condition occurs (the RED blinks twice per second), the instrument will eventually turn OFF. The PEL will start up again once it has been reconnected to a power supply. Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 26: Charging Battery

    If so, the LED blinks twice per second. In this case, at least five charge/discharge cycles will be necessary for your battery to recover 95 % of its capacity. Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 27: Connection Via Usb Or Lan Ethernet Link

    MODEL PEL 113 POWER & ENERGY LOGGER ETHERNET Figure 12 Then through whichever link was chosen, open the PEL Control Panel to connect to the instrument to the PC. Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 28: Lan Ethernet Connection To The Pel

    NOTE: When you press the Control button, if the REC indicator is blinking, the Control button is locked. The PEL Control Panel must be used to unlock the Control button. Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 29: Configuring The Instrument

    In this case, when there is an attempt to configure it, the instrument displays LOCK. After 3 minutes without pressing the Enter or Navigation button, the display returns to the measurement screen. Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 30: Current Sensors

    Three-phase, 3-wire open Δ (2 current sensors) 3P-3WO3 Three-phase, 3-wire open Δ (3 current sensors) 3P-4WO Three-phase, 4-wire, open Δ dC-2W DC 2-wire dC-3W DC 3-wire dC-4W DC 4-wire Table 9 Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 31: Alarm Conditions

    63 Hz. ■ E-mail indicates, when the field is checked, that when the alarm starts and when the alarm ends, a report will be emailed to the defined recipients. Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 32: E-Mail Report

    3.8 E-MAIL REPORT When recording data on the PEL 112 or PEL 113, you can configure the instrument to send periodic email reports up to five users. You can also configure the instrument to send email reports when alarms occur during a recording.
  • Page 33 In addition, the 1-week report includes a field for defining the day of the week that the report will be sent. The report will be generated and mailed at midnight on the start of the selected day. Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 34: Operation

    ■ Connect the terminal N test lead to the neutral conductor ■ Connect the terminal V1 test lead to the L1 phase conductor ■ Connect the current probe to the L1 phase conductor Figure 15 Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 35: Single Phase 3-Wire (Split Phase From A Center Tap Transformer): 1P-3W

    L3 phase conductor ■ Connect the terminal I1 current probe to the LI phase conductor ■ Connect the terminal I3 current probe to the L3 phase conductor Figure 17 Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 36: 3-Phase 3-Wire ∆ (With 3 Current Sensors): 3P-3W∆3

    L3 phase conductor ■ Connect the terminal I1 current probe to the LI phase conductor ■ Connect the terminal I3 current probe to the L3 phase conductor Figure 19 Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 37: 3-Phase 3-Wire Open ∆ (With 3 Current Sensors): 3P-3Wo3

    L3 phase conductor ■ Connect the terminal I1 current probe to the LI phase conductor ■ Connect the terminal I3 current probe to the L3 phase conductor Figure 21 Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 38: 3-Phase 3-Wire Y (With 3 Current Sensors): 3P-3Wy3

    L1 phase conductor ■ Connect the terminal V2 test lead to the L2 phase conductor ■ Connect the terminal I3 current probe to the L3 phase conductor Figure 23 Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 39: 3-Phase 4-Wire Y Power Networks

    ■ Connect the terminal V1 test lead to the L1 phase conductor ■ Connect the terminal I1 current probe to the L1 phase conductor Figure 25 Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 40: 3-Phase 4-Wire Y 2½ Element: 3P-4Wy2

    LI phase conductor ■ Connect the terminal I2 current probe to the L2 phase conductor ■ Connect the terminal I3 current probe to the L3 phase conductor Figure 27 Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 41: 3-Phase 4-Wire Open ∆: 3P-4Wo

    ■ Connect the terminal N test lead to the common conductor ■ Connect the terminal V1 test lead to conductor +1 ■ Connect the terminal I1 current probe to conductor +1 Figure 29 Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 42: Dc 3-Wire: Dc-3W

    ■ Connect the terminal I1 current probe to conductor +1 ■ Connect the terminal I2 current probe to conductor +2 ■ Connect the terminal I3 current probe to conductor +3 Figure 31 Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 43: Recording Data

    PEL Control Panel on your PC and de-select the Lock out the Control button option in the Configure Instrument dialog box, as explained in the PEL Control Panel online Help. Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 44: Measured-Value Display Modes (Pel 113 Only)

    PEL can only be fully configured through the PEL Control Panel. The PEL 112 can only be configured with the PEL Control Panel. For detailed instructions on configuring, recording and downloading measurements, refer to § 5.

  • Page 45: Measurement Mode

    The display depends on the network configured. Press the ▼ button to go from on screen to the next. 4.3.1.1 Single-phase, 2-wire (1P-2W) φ (I ▼ ▼ ▼ tan φ Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 46: Two-Phase, 3-Wire (1P-3W)

    4.4.1.2 Two-phase, 3-wire (1P-3W) φ (I φ (V ▼ φ (I φ (I ▼ ▼ tan φ Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 47: Three-Phase, 3-Wire, Unbalanced (3P-3Wδ2, 3P-3Wδ3, 3P-3Wo2, 3P-3Wo3, 3P-3Wy2, 3P-3Wy3)

    4.4.1.3 Three-phase, 3-wire, unbalanced (3P-3WΔ2, 3P-3WΔ3, 3P-3WO2, 3P-3WO3, 3P-3WY2, 3P-3WY3) φ (I φ (I φ (I φ (U φ (U ▼ φ (U φ (I φ (I ▼ φ (I ▼ tan φ Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 48: Three-Phase, 3-Wire ∆, Balanced (3P-3W∆B)

    4.4.1.4 Three-phase, 3-wire ∆, balanced (3P-3W∆b) ▼ φ (I ▼ ▼ tan φ Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 49: Three-Phase, 4-Wire, Unbalanced (3P-4Wy, 3P-4Wy2, 3P-4Wδ, 3P-4Wo)

    φ (V φ (V ▼ φ (V φ (U φ (U ▼ φ (U φ (I φ (I ▼ φ (I *: Not for 3P-4WΔ and 3P-4WO networks Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 50: Three-Phase, 4-Wire, Wye, Balanced (3P-4Wyb)

    ▼ tan φ 4.3.1.6 Three-phase, 4-wire, wye, balanced (3P-4WYb) ▼ ▼ Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 51: Dc 2-Wire, (Dc-2W)

    φ (I ▼ ▼ tan φ 4.4.1.7 DC 2-wire, (dC-2W) ▼ 4.4.1.8 DC 3-wire, (dC-3W) Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 52: Dc 4-Wire, (Dc-4W)

    ▼ ▼ 4.3.1.9 DC 4-wire, (dC-4W) ▼ Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 53: Energy Mode

    The display screens for AC and DC networks are different. 4.3.2.1 AC Networks Ep+: Total active energy consumed (by the load) in kW·h. Power & Energy Logger Models PEL 112 & 113 - User Manual...
  • Page 54 Eq1: Reactive energy consumed (by the load) in the inductive quadrant (quadrant 1) in kvarh. ▼ Eq2: Reactive energy delivered (by the source) in the capacitive quadrant (quadrant 2) in kvarh. ▼ Power & Energy Logger Models PEL 112 & 113 - User Manual...
  • Page 55 ▼ Eq4: Reactive energy consumed (by the load) in the capacitive quadrant (quadrant 4) in kvarh. ▼ Es+: Total apparent energy consumed (by the load) in kVAh. ▼ Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 56: Dc Networks

    (by the source) in kVAh. ▼ 4.3.2.2 DC Networks Ep+: Total active energy consumed (by the load) in kW·h. Ep-: Total active energy delivered (by the source) in kW·h. ▼ Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 57: Harmonics

    The harmonics display is not available for DC networks. The display unit indicates DC mode no THD. 4.3.3.1 Single-phase, 2-wire (1P-2W) I_THD V_THD 4.3.3.2 Two-phase, 3-wire (1P-3W) _THD _THD _THD _THD ▼ _THD Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 58: Three-Phase, 3-Wire, Unbalanced (3P-3Wδ2, 3P-3Wδ3, 3P-3Wo2, 3P-3Wo3, 3P-3Wy2, 3P-3Wy3)

    _THD ▼ _THD 4.3.3.4 Three-phase, 3-wire ∆, balanced (3P-3W∆b) _THD = I _THD _THD = I _THD _THD _THD _THD = U _THD ▼ _THD = U _THD Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 59: Three-Phase, 4-Wire, Unbalanced (3P-4Wy, 3P-4Wy2, 3P-4Wδ, 3P-4Wo)

    _THD ▼ _THD 4.3.3.6 Three-phase, 4-wire, wye, balanced (3P-4WYb) _THD _THD = I _THD _THD = I _THD _THD _THD = V _THD ▼ _THD = V _THD Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 60: Maximum Mode

    The maximum display is not available for DC networks. The display unit indicates DC Mode no MAX. 4.3.4.1 Single-phase, 2-wire (1P-2W) ▼ ▼ Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 61: Two-Phase, 3-Wire (1P-3W)

    4.3.4.2 Two-phase, 3-wire (1P-3W) ▼ ▼ ▼ Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 62: Three-Phase, 3-Wire (3P-3Wδ2, 3P-3Wδ3, 3P-3Wo2, 3P-3Wo3, 3P-3Wy2, 3P-3Wy3, 3P-3W∆B)

    4.3.4.3 Three-phase, 3-wire (3P-3WΔ2, 3P-3WΔ3, 3P-3WO2, 3P-3WO3, 3P-3WY2, 3P-3WY3, 3P-3W∆b) ▼ ▼ ▼ Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 63: Three-Phase, 4-Wire (3P-4Wy, 3P-4Wy2, 3P-4Wδ, 3P-4Wo, 3P-4Wyb)

    4.3.4.4 Three-phase, 4-wire (3P-4WY, 3P-4WY2, 3P-4WΔ, 3P-4WO, 3P-4WYb) For the balanced network (3P-4WYb), is not displayed. ▼ ▼ ▼ Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 64: Information Display Values

    ■ For MN93A 5 A range: (5 to 25,000) A «AGG.PERIOd» Displays the aggregation period in minutes (1, 2, 3, 4, 5, Aggregation 6, 10, 12, 15, 20, 30, 60) period Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 65: Configuration (Pel 113)

    3. Use the Navigation button to scroll through the allowable values for the setting. 4. When the desired value appears, press the Enter button. The setting will stop blinking. Power & Energy Logger Models PEL 112 & 113 - User Manual...
  • Page 66 PEL with no probes connected, you must use the PEL Control Panel. «AGG.PERIOd» Displays the aggregation period in minutes (1, 2, 3, 4, 5, 6, Aggregation 10, 12, 15, 20, 30, 60) period Table 12 Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 67: Dataview ® & Pel Control Panel

    ® AEMC Instruments devices, including the Model PEL 112 and PEL 113. As its ® name implies, the primary purpose of DataView is to view data that has been recorded by the instrument and display it as a report.
  • Page 68 4. Select the language version of DataView you want to install (English, French, or Spanish) then click Next. (By default, the language selected in step 3 is highlighted.) Figure 34 Power & Energy Logger Models PEL 112 & 113 - User Manual...
  • Page 69 When all programs are installed, a message appears informing you of this. Click Finish to return to the Setup screen Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 70: Pel Control Panel

    (PEL) Android app. This app, which can be downloaded free from the Google Play Store (https://play.google.com/store/apps/details?id=com.aemc.pel&hl=en) enables you to work with a PEL instrument from an Android mobile device. Power & Energy Logger Models PEL 112 & 113 - User Manual...
  • Page 71 The app is provided with a complete online Help system, which can be viewed independently at http://www.pel100.us/help-en/index.html. Consult this Help system for a complete description of the PEL app and all its capabilities. Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 72: Specifications

    ) with crest factor = √2 Input Impedance: 1 MW (except for AmpFlex /MiniFlex current sensors) ® ® 12.4 kW (AmpFlex /MiniFlex current sensors) ® ® Max Overload: 1.7 V Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 73: Accuracy Specifications (Excluding Current Sensors)

    I = (5 to 120) % I Power Factor (PF) PF = [0.2 inductive; 0.2 capacitive] ± 0.1 V = (100 to 1000) V I = (5 to 120) % I Power & Energy Logger Models PEL 112 & 113 - User Manual...
  • Page 74 The intrinsic uncertainty for neutral current is the maximum intrinsic uncertainty on I1, I2 and I3. – ** Indicative maximum value of the intrinsic uncertainty. Higher uncertainties can be noted, in particular with EMI. Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 75: Specifications @ 400 Hz

    I1, I2 and I3. – ** Indicative maximum value of the intrinsic uncertainty. Higher uncertainties can be noted, in particular with EMI. Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 76: Specifications @ Dc

    0.01 % I 6.2.3.6 Influence of Magnetic Field For current inputs to which MiniFlex or AmpFlex flexible current sensors are ® ® connected: 10 mA/A/m typically at 50/60 Hz. Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 77: Accuracy

    ± 3 % ± 50 mA ± 1.5 ° AC/DC Table 17 ** Indicative maximum value of the intrinsic uncertainty. Higher uncertainties can be noted, in particular, with EMI. Power & Energy Logger Models PEL 112 & 113 - User Manual...
  • Page 78 ** Indicative maximum value of the intrinsic uncertainty. Higher uncertainties can be noted, in particular with EMI. NOTE: When no current sensor is connected, the current values are forced to zero. Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 79: Power Supply

    NOTE: Configuration data is saved for up to 5 years during a low battery condition. When the instrument is off, the real-time clock is maintained for two weeks or longer. Autonomy ■ 30 minutes minimum with no Wi-Fi Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 80: Mechanical Specifications

    (-4 to 158) °F (-20 to 70) °C from (0 to 75) % RH Recommended long-term storage temperature for battery: (41 to 77) °F (5 to 25) °C % RH PEL 112 PEL 113 T (°C) 20 26 42.5 Figure 38 Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 81: Safety Specifications

    IEC 61326-1 (with an influence of 0.5 % typical of the full scale Specifications are subject to change without notice. 6.7.1 Radio Emission The devices are compliant with the 2014/53/EU RED directive and FCC Regulations. Wi-Fi: FCC certification QOQWF121 Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 82: Maintenance

    ■ Clean the body of the instrument with a damp and soapy cloth. ■ Do not submerge the instrument in water. ■ Do not use alcohol, solvents, or hydrocarbons. Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 83: Updating The Firmware

    7.3 UPDATING THE FIRMWARE The PEL 112 and PEL 113 firmware controls the features and functionality of the instrument. AEMC Instruments provides firmware updates free of charge to ® download through our DataView PEL Control Panel software. ® WARNING: Updating the firmware could reset the configuration and cause loss of stored data.

  • Page 84: Repair And Calibration

    Chauvin Arnoux , Inc. d.b.a. AEMC Instruments ® ® Phone: (800) 343-1391 (Ext. 351) Fax: (603) 742-2346 E-mail: techsupport@aemc.com www.aemc.com Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 85: Limited Warranty

    (603) 742-2346 E-mail: repair@aemc.com Caution: To protect yourself against in-transit loss, we recommend that you insure your returned material. NOTE: You must obtain a CSA# before returning any instrument. Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 86: Measurements

    ƒ Inside (42.5 to 57.5) Hz (50 Hz ±15 %), sampling period is locked to main frequency. 128 samples are available for each main cycle. ƒ Outside (42.5 to 57.5) Hz, sampling period is (128*50) Hz. Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 87: Locking Of Sampling Frequency

    ® 8.2.4 Measurement of Neutral Current For the PEL 112 and PEL 113, neutral current is calculated according to the distribution system. 8.2.5 200 mS Quantities The instrument calculates the following quantities every 200 ms on the basis of measurements on 10 periods for 50 Hz, 12 periods for 60 Hz, and 80 periods for 400 Hz.

  • Page 88: 1-Second Quantities

    However, the Total energy is available with the recording session data. NOTE: N is the number of 1-second values for the considered aggregation period (1, 2, 3, 4, 5, 6, 10, 12, 15, 20, 30 or 60) min. Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 89: Supported Electrical Networks

    3P-3WO3 § 4.1.3.4 Current measurements are performed on L1, L2 and L3 conductors. 3-Phase 3-Wire Y 3P-3WY3 Neutral is not available for current and § 4.1.3.6 voltage measurement Power & Energy Logger Models PEL 112 & 113 - User Manual...
  • Page 90 2·v1 + v3, u23= - v1 - 2·v3. It supposes that V2 is balanced. Current measurements are performed on L1, L2 and L3 conductors. Neutral current is calculated: iN = i1 + i2 + i3 Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 91: Phase Order

    ■ Phase order for current channels only is displayed when currents are displayed. ■ Phase order for voltage and current channels is displayed when the other screens are displayed. Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 92: Current Phase Order

    [ϕ (I1, I3), ϕ (I3, I2), ϕ (I2, I1)] = 120° ± 30° 3-Phase 4-Wire Open-∆ 3P-4WO∆ DC 2-Wire DC-2W DC 3-Wire DC-3W DC 4-Wire DC-4W Table 21 Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 93: Voltage Phase Order

    [ϕ (U12, U31), ϕ (U31, U23), ϕ (U23, U12)] = 120° ± 10° 3-Phase 4-Wire Open-∆ 3P-4WO∆ DC 2-Wire DC-2W DC 3-Wire DC-3W DC 4-Wire DC-4W Table 22 Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 94: Current Vs Voltage Phase Order

    [ϕ (I1, U12), ϕ (I2, U23), ϕ (I3, 3-Phase 4-Wire Open-∆ 3P-4WO∆ U31)] = 210° ± 60° for source DC 2-Wire DC-2W DC 3-Wire DC-3W DC 4-Wire DC-4W Table 23 Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 95: Quantities According To The Supply Systems

                             Source   Power & Energy Logger Models PEL 112 & 113 - User Manual...
  • Page 96            Source   Source  Source Source     Load   Load  Load Power & Energy Logger Models PEL 112 & 113 - User Manual...
  • Page 97    THD _U    THD _U    THD_I      THD_I     THD_I    Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 98: 4Wy, 3P-4Wyb, 3P-4Wy2, 3P-4W /3P-4W O

                                Power & Energy Logger Models PEL 112 & 113 - User Manual...
  • Page 99    Load                         Power & Energy Logger Models PEL 112 & 113 - User Manual...
  • Page 100  Hi_I     to 50 Hi_I     Hi_I     THD_V     THD_V     Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 101: Dc-2W, Dc-3W, Dc-4W

    (4) Always = 0 (5) Calculated 6) Order 7 for 400 Hz 8.8.3 DC-2W, DC-3W, DC-4W = YES  Quantities DC-2W DC-3W DC-4W       Power & Energy Logger Models PEL 112 & 113 - User Manual...
  • Page 102  Source    Source   Source  Source   Load    Load   Load  Load   Source Source Source Power & Energy Logger Models PEL 112 & 113 - User Manual...
  • Page 103 Cos ϕ Source Cos ϕ Source Cos ϕ Source Cos ϕ Load Cos ϕ Load Cos ϕ Load Cos ϕ Load TAN Φ TAN Φ Source TAN Φ Load Power & Energy Logger Models PEL 112 & 113 - User Manual...
  • Page 104 Angle Angle Angle Angle Angle Angle Angle Angle Angle Table 26 (3) Not a significant value (4) Always = 0 (5) Calculated 6) Order 7 for 400 Hz Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 105: Glossary Of Terms

    Minimum value Nominal Voltage Reference voltage of a network. Order of a Ratio of the frequency of the harmonic to the fundamental fre- Harmonic quency; a whole number. Power & Energy Logger Models PEL 112 & 113 - User Manual...
  • Page 106 Total harmonic distortion of phase-to-neutral voltage. Vunb Phase-to-neutral voltage unbalance. Vx-Hn Phase-to-neutral voltage value or percentage for harmonic order n. Active power unit (Watt). W·h Active energy unit (Watt - hour). Table 27 Power & Energy Logger Models PEL 112 & 113 - User Manual...

  • Page 107: Prefixes Of International System (Si) Units

    9.1 PREFIXES OF INTERNATIONAL SYSTEM (SI) UNITS Prefix Symbol Multiplies by milli kilo Mega Giga Tera Peta Table 28 Power & Energy Logger Models PEL 112 & 113 - User Manual...
  • Page 108 04/25 99-MAN 100620 v00 AEMC Instruments ® 15 Faraday Drive • Dover, NH 03820 USA Phone: +1 (603) 749-6434 • +1 (800) 343-1391 • Fax: +1 (603) 742-2346 www.aemc.com © 2025 Chauvin Arnoux , Inc. d.b.a. AEMC Instruments. All Rights Reserved. ®...

This manual is also suitable for:

Pel 113

Table of Contents
