Summary of Contents for AEMC instruments DL913
- Page 1 User Manual ENGLISH Data Logger Models DL913 & DL914 DATA LOGGERS WITH AEMC INSTRUMENTS ®...
- Page 2 Copyright © Chauvin Arnoux , Inc. d.b.a. AEMC Instruments. All rights reserved. ® ® No part of this documentation may be reproduced in any form or by any means (including electronic storage and retrieval or translation into any other language) without prior agreement and written consent from Chauvin Arnoux , Inc., as governed by United States and International copyright laws.
- Page 3 Refer to our repair and calibration section at www.aemc.com. Serial #: Catalog #: 2153.61 / 2153.62 Model #: DL913 / DL914 Please fill in the appropriate date as indicated: Date Received: Date Calibration Due: Chauvin Arnoux , Inc.
-
Page 4: Table Of Contents
TABLE OF CONTENTS 1. INTRODUCTION ................6 1.1 PRECAUTIONS FOR USE ............7 1.2 RECEIVING YOUR SHIPMENT ..........8 1.3 ORDERING INFORMATION ............. 8 1.3.1 Accessories and Replacement Parts ..........8 2. PRODUCT FEATURES ..............9 2.1 DESCRIPTION ................9 2.2 CONTROL FEATURES ............ - Page 5 6. SPECIFICATIONS ................30 6.1 ELECTRICAL ................30 6.2 MECHANICAL ................31 6.3 ENVIRONMENTAL ..............31 6.4 SAFETY & ELECTROMAGNETIC COMPATIBILITY .... 31 7. MAINTENANCE ................32 7.1 CLEANING ................32 7.2 REPAIR AND CALIBRATION ..........32 7.3 TECHNICAL ASSISTANCE ............. 33 7.4 LIMITED WARRANTY .............
-
Page 6: Introduction
1. INTRODUCTION Thank you for purchasing an AEMC Instruments Data Logger Model DL913 or ® DL914. For the best results from your instrument and for your safety, you must read the enclosed operating instructions carefully and comply with the precautions for use. -
Page 7: Precautions For Use
Use protective equipment when required Do not apply or remove the sensors from hazardous live parts or systems If hazardous voltages are present at the location of measurement, use suitable personal protective equipment Data Logger Model DL913 & DL914... -
Page 8: Receiving Your Shipment
Cable - 10 ft USB Type A to Type B ..........Cat. #2136.80 Cable - 6 ft USB Type A to Type B (Waterproof) for Models DL913 and DL914 ............Cat. #2153.79 Battery - Rechargeable Battery Pack, 4.2 A·h NiMH for Models DL913 and DL914 ............ -
Page 9: Product Features
2. PRODUCT FEATURES 2.1 DESCRIPTION The Models DL913 and DL914 are easy-to-use, rugged data loggers that can be used both indoors and outdoors. Recorded data is stored in the instrument’s internal memory. This data can then be downloaded to a computer using a Wi-Fi or USB connection. -
Page 10: Control Features
A short press (≤ 3 s) turns the LCD backlight on. 4. Control button starts and stops recordings (see § 4.3) and selects and enables the Wi-Fi communication type (see § 3.2.2). 5. Enter button cycles through the displayed data and options. Data Logger Model DL913 & DL914... -
Page 11: Lcd Display
Data Logger Control Panel. 5. Wi-Fi Direct ON (steady): Wi-Fi Direct is enabled and not transmitting. Blinking: Wi-Fi Direct is actively transmitting. OFF: Wi-Fi Direct is disabled. Data Logger Model DL913 & DL914... - Page 12 Please reference § 3.3 for instructions to erase memory through the Control Panel. 10. Battery Empty : The battery must be charged. Partially filled : The battery is partially charged. Filled : The battery is fully charged. Blinking: The battery is charging. Data Logger Model DL913 & DL914...
-
Page 13: Setup
5. Use the Up ▲ or Down ▼ button to display the Battery Status (BAT) screen. This screen displays the following parameters: 1. Charging current 2. Charging voltage 3. Battery voltage 6. When the battery is fully charged, the battery indicator will stop blinking and appear completely filled. Data Logger Model DL913 & DL914... -
Page 14: Configuration
3.2 CONFIGURATION The Data Logger Control Panel is the primary interface for setting up and operating the Models DL913 and DL914. Setup tasks include the following: Connecting the instrument to the computer ■ Setting the instrument date and time ■... -
Page 15: Enabling/Disabling The Wi-Fi
Wi-Fi is disabled. When the WIFI status is ON, you can connect the instrument to a computer via router connection (see § 5.3.2) or Wi-Fi Direct connection (§ 5.3.3). Data Logger Model DL913 & DL914... -
Page 16: Configuration
This screen will also show 1, 2, or 3 turns to indicate the instrument’s configuration for the number of sensor turns (wraps). You can configure the instrument for the number of turns in the software only. 2. Press to toggle between 300 A and 3000 A. Data Logger Model DL913 & DL914... -
Page 17: Aggregation Period
1:00. Although the recording will continue until 1:06, no aggregation will be performed for the final 6 minutes. 3.2.3.3 Recording Mode The Recording mode screen determines whether a recording will run in normal recording mode or extended recording mode. Data Logger Model DL913 & DL914... -
Page 18: Erasing Memory
1. In the Data Logger Control Panel, click Instrument in the toolbar. 2. Select Erase Memory in the drop-down menu. 3. From the list of stored recording sessions, select the recordings to delete. 4. Then, click OK. Data Logger Model DL913 & DL914... -
Page 19: Operation
1. Connect the instrument’s three (DL913) or four (DL914) captive current sensors to the distribution system under test. Each sensor is labeled (L1, L2, and L3 for the DL913; L1, L2, L3, and N for the DL914). 2. Connect each sensor to its corresponding phase. -
Page 20: Max Mode
(# TURN). § 3.2.3.1 Can be changed to either 300 or 3000 A via the Front Panel or the Data Logger Control Panel. Number of sensor wraps is only adjustable in the Data Logger Panel. Data Logger Model DL913 & DL914... - Page 21 Wi-Fi. The full address scrolls right to left at the § 5.3 bottom of the screen, followed by the port number and communication protocol (UDP or TCP) Data Logger Model DL913 & DL914...
-
Page 22: Recording Data
Maximum full battery life for Normal recording mode is approximately 4-days. External power would be required to successfully complete the 30-day recording. 1. Connect the instrument’s three (DL913) or four (DL914) captive current probes to the distribution system under test. 2. Press (≥... - Page 23 To view a recording, the instrument must be connected to a computer running the Data Logger Control Panel. For instructions about installing DataView and connecting the instrument to a computer, see § 5. Data Logger Model DL913 & DL914...
-
Page 24: Dataview
8. If you want to review or change any of your previous selections before installation, click Previous. Otherwise, click Install. If your computer does not have any previous versions of the software installed, the software will be installed without requesting confirmation. Data Logger Model DL913 & DL914... -
Page 25: Types Of Connections
5. After completing all screens, press Finish to exit the Add an Instrument wizard. The connected instrument will appear on the left side of the screen in the Data Logger Network frame. A green check mark next to the instrument’s name indicates that it is connected. Data Logger Model DL913 & DL914... -
Page 26: Wi-Fi Via Router
Control Panel’s status frame. 7. Click the Modify connection settings button at the top of the Status frame. The Add an Instrument wizard will appear. 8. Select Ethernet (Wi-Fi) in the Connection Type field, and click Next. Data Logger Model DL913 & DL914... -
Page 27: Wi-Fi Direct
6. Press Finish to exit the Add an Instrument wizard. The connected instrument will appear on the screen’s left side in the Data Logger Network frame. If connected, green check mark will be next to the instrument’s name. Data Logger Model DL913 & DL914... -
Page 28: Remote User Interface
For a Wi-Fi access point connection, enter http://192.168.2.1 For a Wi-Fi router connection, enter the address indicated in the information menu (see § 4.2). In the Wi-Fi tab, you can view and edit the instrument’s SSID, Password, and IP address. Data Logger Model DL913 & DL914... - Page 29 In the Info tab, you can view the device’s date, time, location, identifying information, firmare version, and current sensor information. In the Recording tab, you can view information about the in-progress recording or the most recent recording. Data Logger Model DL913 & DL914...
-
Page 30: Specifications
Extended recording mode: 7 days to 30 days* Battery Life (*Depending on the selected aggregation period) (Wi-Fi Disabled) Reference the table in § 3.2.3.3 for more in-depth information regarding the battery life, aggregation period, storage interval, and recording modes. Data Logger Model DL913 & DL914... -
Page 31: Mechanical
(5.9 x 5.9 x 3.57) in (150 x 150 x 91) mm w/o sensors DL913: 2.2 lb (1 kg) Weight DL914: 2.42 lb (1.1 kg) 3 (DL913) or 4 (DL914) integral 24 in (610 mm) MiniFlex ® Sensor/Cable Length probes with 6.5 ft (2 m) leads Maximum Conductor 7.64 in (190 mm) -
Page 32: Maintenance
(603) 742-2346 or (603) 749-6309 E-mail: repair@aemc.com (Or contact your authorized distributor.) Contact us for the costs for repair, standard calibration, and calibration traceable to N.I.S.T. NOTE: You must obtain a CSA# before returning any instrument. Data Logger Model DL913 & DL914... -
Page 33: Technical Assistance
AEMC Instruments will repair or replace the faulty ® material at our discretion. REGISTER ONLINE AT: www.aemc.com/warranty.html Data Logger Model DL913 & DL914... -
Page 34: Warranty Repairs
Phone: (800) 945-2362 (Ext. 360) / (603) 749-6434 (Ext. 360) Fax: (603) 742-2346 or (603) 749-6309 E-mail: repair@aemc.com Caution: To protect yourself against in-transit loss, we recommend that you insure your returned material. NOTE: You must obtain a CSA# before returning any instrument. Data Logger Model DL913 & DL914... - Page 35 NOTES:...
- Page 36 01/23 99-MAN 100550 v1 AEMC Instruments ® 15 Faraday Drive • Dover, NH 03820 USA Phone: (603) 749-6434 • (800) 343-1391 • Fax: (603) 742-2346 www.aemc.com © Chauvin Arnoux , Inc. d.b.a. AEMC Instruments. All Rights Reserved. ® ®...
