OWNER'S GUIDE & SERVICE MANUAL
M A R V E L U N D E R C O U N T E R R E F R I G E R AT I O N
Model: MLKR224-SSA1A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MLKR224-SSA1A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Marvel MLKR224-SSA1A

  • Page 1 OWNER’S GUIDE & SERVICE MANUAL M A R V E L U N D E R C O U N T E R R E F R I G E R AT I O N Model: MLKR224-SSA1A...
  • Page 2: Warranty Registration

    Got a Marvelous Design? located inside the cabinet on the left side near the top. We would love to see how your Marvel product looks in its new home. You can send us photos of your installed prod- uct at marketing@marvelrefrigeration.com, and we might...
  • Page 3: Table Of Contents

    TABLE OF CONTENTS Tip: Click on any section below to jump directly there Safety System Diagnosis Guide Important Safety Instructions Compressor Specifications Troubleshooting Extended Installation Thermistor Unpacking Your Appliance Defrost Electrical Remove Fan and Cover Cutout & Product Dimensions Warranty Installing Your Appliance Side-by-Side &...
  • Page 4: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS Important Safety Instructions Warnings and safety instructions appearing in this guide are not meant to cover all possible conditions and situations that may occur. Common sense, caution and care must be exercised when installing, maintaining or operating this appliance. Recognize Safety Symbols, Words and Labels WARNING...
  • Page 5: Unpacking Your Appliance

    UNPACKING YOUR APPLIANCE WARNING CAUTION If the appliance was shipped, handled or stored in other EXCESSIVE WEIGHT HAZARD than an upright position for any period of time, allow the Use two or more people to move product. appliance to sit upright for a period of at least 24 hours Failure to do so can result in personal injury.
  • Page 6: Electrical

    ELECTRICAL Electrical Connection A grounded 115 volt, 15 amp dedicated circuit is required. This product is factory equipped with a power supply cord that has a three-pronged, grounded plug. It must be Do not remove plugged into a mating grounding type receptacle in ground prong accordance with the National Electrical Code and applicable local codes and ordinances.
  • Page 7: Cutout & Product Dimensions

    CUTOUT & PRODUCT DIMENSIONS ROUGH-IN OPENING DIMENSIONS CABINET DIMENSIONS “A” “B” “C” “D” “E” “F” “G” “H” “J” 24” 34” to 35” 24” 23 7/8” 33 3/4” to 34 3/4” 22 7/8” 46 1/2” (61 cm) (86.4 cm to 88.9 cm) (61 cm) (60.7 cm) (85.7 cm to 88.3 cm)
  • Page 8 CUTOUT & PRODUCT DIMENSIONS PRODUCT DATA ELECTRICAL PRODUCT REQUITEMENTS # WEIGHT 140 lbs 115V/60Hz/15A (63.6 kg) “H” “D” “F” “E” Solid Door 21 1/2” 3 1/2” (8.9 cm) (54.6 cm) Shown Minimum Minimum rough-in opening is required to be larger than the adjusted height of the cabinet.
  • Page 9: Installing Your Appliance

    The could result in personal injury. Contact your dealer or overall height of your Marvel appliance may be adjusted Marvel customer service at 616-754-5601 to order. higher (by turning the leveling leg out, CCW) and lower (by For safety concerns 15"...
  • Page 10: Side-By-Side & Stacking Installations

    SIDE-BY-SIDE & STACKING INSTALLATION Side-by-Side Installation Stainless steel models which include the standard stainless handle will require 4 9/16” (116 mm) to allow both doors to Other Site Requirements open to 90° at the same time. Units must operate from separate, properly grounded elec- trical receptacles places according to each unit’s electrical 4 9/16”...
  • Page 11: Door Reversal

    DOOR REVERSAL Door Reversing Instructions Tools Needed: • 1/8” Hex Key • 5/32” Hex Key • Phillips Screwdriver 1. Open door and remove hinge pin from the upper hinge using a 1/8” hex key tool, making sure to steady the door. Slowly remove the door from the upper hinge and lift to remove off the base lower hinge.
  • Page 12 DOOR REVERSAL 6. Remove the toe kick from the door and attach it to the opposite side. Toe Kick Reversal 7. Reattach the upper and lower hinges, and hinge brackets to opposite sides. Then install the door.
  • Page 13: Integrated Panel Dimensions

    INTEGRATED PANEL DIMENSIONS NOTE • Panel thickness may be 5/8” or 3/4” • Center the unit in the 24” opening • If the hinge side of the product is pressed against the adjacent cabinet, use a 5/8” thick panel • The window cutout is for glass door models only •...
  • Page 14 USING YOUR BEVERAGE DISPENSER Shelving If you are using a quarter barrel of beer, you can add shelf The unit is shipped with the (2) shelves taped in place in space for keeping your mugs chilled. The quarter barrel must set on the floor, it cannot fit on the shelf.Be sure the the upper and the lower shelf positions.
  • Page 15: Tools Required For Installation

    USING YOUR BEVERAGE DISPENSER Tools required for installation: This beer dispensing unit will support one half ( ⁄ ) barrel or one quarter ( ⁄ ) barrel. The double draft tower units can Flat bladed screwdriver support two sixth ( ⁄...
  • Page 16 USING YOUR BEVERAGE DISPENSER Single Dispense Tower Kit Double Dispense Tower Kit Connect ,etc..Connect ,etc..Figure 32 Double Single Dispense Hose clamps Dispense Tower use for connections Tower Hose clamps use for connections Coupler Coupler Coupler Regulator 5 Pound with red Gas Tank airline...
  • Page 17 USING YOUR BEVERAGE DISPENSER Rear of counter top 4. If you are installing your keg refrigerator under a counter you will need to drill 5 holes in the counter top ⁄ " to mount the tower. The first hole is a 1 ⁄...
  • Page 18 USING YOUR BEVERAGE DISPENSER 9. Hooking up the keg coupler to the keg: Verify the coupler is in the "OFF" position. Align the lugs on the keg with the corresponding openings on the keg Connect coupler and turn clockwise until the coupler stops with "S"...
  • Page 19 USING YOUR BEVERAGE DISPENSER Optional gas tank external mounting bracket: CAUTION The optional mounting bracket is designed to hold the 5# gas cylinder that comes with the beer dispenser. Larger cylinders may be purchased from a third party and mounted If the gas tank is placed on the floor it must be secured in externally.
  • Page 20 USING YOUR BEVERAGE DISPENSER Gas Regulator (Single Dispense Tower) Gas Regulator (Double Dispense Tower) Your beer dispenser comes equipped with a 5 pound gas Your beer dispenser comes equipped with a 5 pound gas tank and a single gauge regulator. The gauge reads the tank and a dual gauge regulator.
  • Page 21: Cleaning The Drain Sump

    Cleaning the drain sump: On a free standing beverage dispenser remove the Marvel grate from in front of the tower, clean with soap and water and dry before reinstalling. Clean the sump area with soapy water and dry. On a built in beverage dispenser remove the Marvel...
  • Page 22: Integrated Panel Installation

    INTEGRATED PANEL INSTALLATION Step 2: Remove the door gasket Cut and prepare panels according to the information provided in the Integrated Panel Dimensions section. With the door laying on a flat surface and starting at a corner of the door, remove the magnetic door gasket from the interior side of the door.
  • Page 23: Step 4: Install The Door

    INTEGRATED PANEL INSTALLATION Step 4: Install the Door If reversing the door swing, reinstall hinges per Door Reversal Instructions. Carefully slide lower hinge bushing over bottom hinge pin. Install the new upper hinge bushing into adaptor plate. Align hinge bushing with top hinge and reinstall upper hinge pin using 1/8”...
  • Page 24: Using Your Electronic Control

    Time to reach set point varies based upon ambient temperature, temperature of product loaded, door openings, etc. Marvel recommends allowing the unit to reach set points before loading.
  • Page 25: Interior Adjustments

    INTERIOR ADJUSTMENTS Installing the Shelves NOTE With flanges pointing up, insert the shelf tabs into the liner holes on the left side of the unit. Rest the right side of the shelves on the shelf hanging brackets. The shelves are labeled “Top” and “Bottom”. The bottom shelf fits inside of the top shelf for storage convenience.
  • Page 26: Stainless Steel Maintenance

    STAINLESS STEEL MAINTENANCE Background NOTE Stainless steel does not stain, corrode, or rust as easily as ordinary steel, but it is not stain or corrosion proof. Stainless steels can discolor or corrode if not maintained Stainless steel products should never be installed, or stored properly.
  • Page 27: Energy Saving Tips

    ENERGY SAVING TIPS The following suggestions will minimize the cost of operating your refrigeration appliance. 1. Do not install your appliance next to a hot appliance (cooker, dishwasher, etc.), heating air duct, or other heat sources. 2. Install product out of direct sunlight. 3.
  • Page 28: Service

    Winterization If the unit will be exposed to temperatures of 40° F (5° C) or less, the steps above must be followed. For questions regarding winterization, please call Marvel at (616) 754-5601. CAUTION Damage caused by freezing temperatures is not covered...
  • Page 29: Obtaining Service

    OBTAINING SERVICE If Service is Required: • If the product is within the first year warranty period please contact your dealer or call Marvel Customer Service at 616.754.5601 for directions on how to obtain warranty coverage in your area. •...
  • Page 30: Troubleshooting

    • Compressor: The compressor makes a hum or pulsing- sound that may be heard when it operates. If you think your Marvel product is malfunctioning, read the • Evaporator: Refrigerant flowing through an evaporator- Control Operation section to clearly understand the may sound like boiling liquid.
  • Page 31: Checking Product Temperature

    TROUBLESHOOTING Checking Product Temperature Causes which affect the internal temperatures of the cabinet include: • Temperature setting. • Ambient temperature where installed. • Installation in direct sunlight or near a heat source. • The number of door openings and the time the door is open.
  • Page 32: Wire Diagram

    WIRE DIAGRAM Door Switch User Interface 2nd Switch (Drawer Models) OG RD Fresh Food Thermistor Evap Fan Interior LED 2nd LED Optional Compressor Condenser Fan...
  • Page 33: Product Liability

    The part that caused the damage must be returned to Marvel in its entirety. The part must be clearly labeled with the serial number of the unit it was removed from, the date, and the servicer who removed the part.
  • Page 34: Warranty Claims

    Final billing - Remodel • 60 day submittal deadline from date of completed service Warranty parts will be shipped at no charge after Marvel confirms warranty status. Please provide the model, serial • Only one repair or unit per warranty claim number, part number and part description.
  • Page 35: Ordering Replacement Parts

    Warranty parts will be shipped at no charge after Marvel confirms warranty status. Please provide the model, serial number, part number and part description. Some parts will require color or voltage information.
  • Page 36: R600A Specifications

    R-600a is heavier than air, do not allow any leakage/migra- tion to low areas such as basements and stairs. Never use a torch on a fully charged refrigeration system. Never substitute Marvel OEM replacement parts or methods of construction. R-600a must be stored and transported in approved...
  • Page 37 R600A SPECIFICATIONS R-600A Specifications/Labeling WARNING R-600a equipped products are labeled (both the unit and the compressor). Only skilled and well trained service technicians R-600a is colorless and odorless. permitted to service R-600a equipped products. R-600a is considered non-toxic, but is flammable when All tools and equipment must be approved for use with mixed with air.
  • Page 38: Leak Detection

    R600A SPECIFICATIONS Evacuate/reclaim via the piecing pliers to ensure the When re-brazing, the system must be purged with system is empty of R-600a before any system work is nitrogen and at least one access point open to the performed. atmosphere. When re-brazing, proper ventilation is required along with constant monitoring for the presence of R600a refrigerant.
  • Page 39 R600A SPECIFICATIONS The low side of the refrigeration system (evaporator, compressor and suction line) must be leak tested with the compressor off (equalized pressure). Recharging No air is ever to be allowed inside the refrigeration system (R-600a refrigerant or dry nitrogen only). Never use a torch on a fully charged refrigeration system.
  • Page 40: System Diagnosis Guide

    SYSTEM DIAGNOSIS GUIDE Refrigeration System Diagnosis Guide System Suction Suction Compressor Condenser Capillary Evaporator Wattage Condition Pressure Line Discharge Tube Normal Normal Slightly Very hot Very hot Warm Cold Normal below room temperature Overcharge Higher than Very cold Slightly warm Hot to warm Cool Cold...
  • Page 41: Compressor Specifications

    COMPRESSOR SPECIFICATIONS ESX36CBC WARNING Refrigerant R600A Electrocution can cause death or serious injury. Burns Voltage 115-127 VAC from hot or cold surfaces can cause serious injury. Frequency 60 Hz Take precautions when servicing this unit. Start Winding 11 Ohm at 77°F Disconnect the power source.
  • Page 42: Troubleshooting Extended

    Evaporator: Refrigerant flowing through an evaporator Included in this section are some diagnostic tips; if may sound like boiling liquid. additional help is required, please contact Marvel at • Condenser Fan: Air moving through a condenser may 616.754.5601 for assistance.
  • Page 43 TROUBLESHOOTING EXTENDED...
  • Page 44: Main Control

    TROUBLESHOOTING EXTENDED Main Control CAUTION The main control board is very robust and is rarely the cause of system issues. It is important to fully diagnose the board for any suspected failures before attempting Precautions must be taken while working with live to remove the board for replacement or service.
  • Page 45: Thermistor

    THERMISTOR Thermistors Thermistor Resistance Data Thermistors are used for various temperature readings. Thermistors provide reliable temperature readings using a resistance which varies based on surrounding temperatures. If a faulty thermistor is suspected it may be tested using an accurate ohmmeter. Both thermistors in the unit are identical.
  • Page 46: Defrost

    DEFROST Defrost Outdoor units defrost every 3 hours of compressor runtime for 40 minutes. If you have verified that the unit does not have an ambient air leak, utilize the Control Operation - Service section and adjust unit to defrost every 2 hours for 60 minutes...
  • Page 47: Remove Fan And Cover

    REMOVE FAN & COVER Convection Cooling This unit is equipped with an advanced convection cooling system. Convection cooling stabilizes cabinet temperature, cools product faster and increases energy efficiency. Evaporator Fan The evaporator fan is responsible for circulating warm air from the refrigeration zone, past the evaporator and back into the refrigerated zone.
  • Page 48 REMOVE FAN & COVER NOTE Fan must be oriented to pull air in through lower evaporator cover vents and push air out at fan mounting location. 13. Installation is the reverse of removal. 14. Care must be taken to assure the bottom of the evaporator cover is reinstalled behind the front edge of the train trough.
  • Page 49: Warranty

    For designated Marvel Professional product, Marvel offers a one year extension of the two year warranty coverage from the date of purchase, free of charge. To take advantage of this third year warranty, you must register your product with Marvel within 60 days from the date of purchase at marvelrefrigeration.com and provide proof of purchase.
  • Page 50 Marvel Refrigeration 1260 E. Van Deinse St. Greenville MI 48838 616.754.5601 All specifications and product designs subject to change without notice. Such revisions do not entitle the buyer to corresponding changes, improvements, additions, replacements or compensation for previously purchased products.
