Technical Manual
RS DUNDEE RIE Platform,BTE
GN ReSound A/S
Global Technical Operations
https://gto.gnresound.com
Lautrupbjerg 7
DK-2750 Ballerup
Denmark

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ReSound NEXIA and is the answer not in the manual?

Questions and answers

Summary of Contents for GN Resound ReSound NEXIA

  • Page 1 Technical Manual GN ReSound A/S RS DUNDEE RIE Platform,BTE Global Technical Operations https://gto.gnresound.com Lautrupbjerg 7 DK-2750 Ballerup Denmark...
  • Page 2: Table Of Contents

    Doc 0476800 rev. D Table of Contents Form-Factor-Matrix & Product Information ..................3 Part list..............................4 Part list - HSG parts..........................5 Part list - SureFit receiver tubes ......................6 Part list - SureFit domes ........................7 Part list - SureFit accessories ......................8 Replacing parts..........................9-13 For internal GN Operations only ......................14 Test equipment DSA 6000 .........................15 Test equipment DSA 7000 ......................
  • Page 3: Form-Factor-Matrix & Product Information

    Form-Factor-Matrix & Product Information - NEXIA Doc 0476800 rev. D Platform DUNDEE RIE C6 Product Model DATA SHEET NX960S-DRWC NEXIA NX760S-DRWC 402383000 STD REC 402384000 M&RIE REC Wireless programming & HI test NX560S-DRWC Integrated Batt - rechargeable NX460S-DRWC CX160S-DRWC 402397000 (CROS) The HIs are available with 4 selectable receiver power levels: Low Power (LP), Medium Power (MP), High Power (HP) &...
  • Page 4: Part List

    Part List Doc 0476800 rev. D Description Part No Description Part No PB,DUNDEE,SOFT 22603000 PIN,0.60X7.25 (TOP HSG BAT end) 16059800 SEALING SKT,NG8,MLD 20674800 PIN,0.60X4.30 mm (TOP HSG sound end) 17932500 PIN REMOVAL TOOL. PACKED (white tool) 15502500 CLEANING BRUSH, BLK 17435000 AUTOPHONE MAGNETS 17294600...
  • Page 5: Part List - Hsg Parts

    Part List - HSG Parts 60S-DRWC (RHI) Doc 0476800 rev. D COLOUR TOP HSG ASM BOT HSG GOLD 22907170 22623170 22907270 WARM GREY 22907171 22623171 22907271 ESPRESSO 22907172 22623172 22907272 DEEP BLACK 22907173 22623173 22907273 BRONZE 22907174 22623174 22907274 CHAMPAGNE 22907175 22623175 22907275...
  • Page 6: Part List - Surefit Receiver Tubes

    Part List - SureFit 3 Rec Tubes (8 pin) Doc 0476800 rev. D SUREFIT 3 M&RIE SUREFIT 3 (8 pin) (8 pin) Rec with mic attached SIZE HP (SF3B) SIZE SF3B SF3C 21878800 22406500 21384100 21385100 21879200 21878801 22406501 21384200 21385200 21879201 21878802...
  • Page 7: Part List - Surefit Domes

    Part List - SureFit (SFDomes Doc 0476800 rev. D SUREFIT (SF3) - STD, OPEN & CLOSED DOMES (light grey) Description Bag (10 pcs) DOME,REC,STD,BAG,10PC 21432300 DOME,OPEN,REC,SM,BAG,10PC 21432400 DOME,OPEN, REC,MDM,BAG,10PC 21432500 DOME,OPEN, REC,LGE,BAG,10PC 21432600 DOME,CLOSED,REC,SM,BAG,10PC 21432000 DOME,CLOSED,REC,MDM,BAG,10PC 21432100 DOME,CLOSED,REC,LGE,BAG,10PC 21432200 SUREFIT (SF) - POWER DOMES Description Bag (10 pcs) DOME,PWR REC,SM,BAG,10PC...
  • Page 8: Part List - Surefit Accessories

    Part List - SureFit (SFAccessories Doc 0476800 rev. D Description Part No FILT,MIC,CASE,8PCS FILT,GN WAXG,BOX,8PCS 22035700 20439700 SF3C M&RIE SF3B&C M&RIE/SF3 REC TUBES FITTING KIT,M&RIE,SF3B 22125800 FITTING KIT,M&RIE,SF3C 22466000 MIC FILTER,M&RIE,BAG,8PCS (SF2B) 21536500 FITTING KIT,REC,SF3B 21997400 FILTER,MIC,CASE,8PCS (SF3C M&RIE) 22035700 FILTER,GN WAXGUARD,BOX,8PCS (SF3B&C M&RIE &...
  • Page 9: Replacing Parts

    Replacing Parts Doc 0476800 rev. D PIN REMOVAL TOOL 15502500 Remove the pin located in the BAT end of the HI using a pin removal tool. Pull the pin complete out using a tweezers. Gently lift off the TOP HSG and module from the BOT HSG as shown.
  • Page 10 Replacing Parts Doc 0476800 rev. D How to mount the SEALING SKT,NG8: The ID plate is not a spare part. If the BOT HSG is damaged and Flip the sealing socket around and insert it into the BOT HSG. needs to be replaced, the ID plate must therefore be moved from Make sure the sealing is turned and positioned the right way damaged BOT HSG and transferred to the new BOT HSG It will only be held in place by the friction between HSG BOT...
  • Page 11 Replacing Rec Tube Doc 0476800 rev. D Remove the rec Use either the removal procedure described here or use the rec removal tool - see instr in the guide enclosed rec removal tool kit Pop out Start removing the receiver by pushing down with a fingernail on the red or blue receiver lock. The receiver lock will unlock the receiver and it will pop out.
  • Page 12 Replacing Filter in Rec Tube Doc 0476800 rev. D Remove the used wax filter: If a dome is mounted, remove Box of 8 wax filter tools. The wax filter Insert the removal tip into the used wax filter and then pull the tool straight it before starting replace the tool has two functions: out.
  • Page 13 Replacing Mic Filter in M&RIE SF3 Rec Tube Doc 0476800 rev. D Filter removal Filter Locate the mic filter at the back of the rec tube. Use the filter removal end of the mic filter pin to remove the defective filter (p/n 21536500 MIC FILTER,M&RIE,BAG,8).
  • Page 14: For Internal Gn Operations Only

    Doc 0476800 rev. D The remaining part of the Technical Manual is for internal GN operations only Page 14 of 19 Not subject to issue control when printed...
  • Page 15: Test Equipment Dsa6000

    Test Equipment DSA6000 Doc 0476800 rev. D Description Part No COUPL MIC,TM-12, FOAM,LUX RHI MEASURED p/n 20878000 p/n 18220700 support for NOAHLINK WL CPD-1 20310800 test rec & coupler FOAM,LUXOR RHI 20878000 FRAME (BLK test frame for ATC4000/TBS25 sound chamber) 16902800 TEST JIG,CAMB RHI&13&DUNDEE (DSA6000 &...
  • Page 16: Test Equipment Dsa 7000

    Test Equipment - DSA7000 Doc 0476800 rev. D Description Part No NOAHLINK WL CPD-1 20310800 FOAM,LUXOR RHI 20878000 NOAHLINK WL CPD-1 TEST JIG,CAM RHI&13 FRAME (BLK test frame for ATC4000/TBS25 sound chamber) 16902800 p/n 20310800 & DUNDEE p/n 21570100 TEST JIG,CAMBRIDGE RHI&13&DUNDEE 21570100 (DSA6000 &...
  • Page 17: Rubber Washer

    Test Equipment - DSA7000 Doc 0476800 rev. D Description Part No RIE ADAPTOR,DSA7000 22239900 RIE ADAPTOR NUT,DSA7000 22240000 NG8 CONE REC,DSA7000 22240200 RUBBER WASHER (DSA6000 & DSA7000 test rec) 20012000 ASM TEST REC,NG8,DSA7000 22240400 RUBBER WASHER NG8 CONE REC,DSA7000 RIE ADAPT,DSA7000 RIE ADAPT,NUT,DSA7000 p/n 22239900 p/n 20012000...
  • Page 18: Hi Testing

    HI Test - DSA6000 & DSA7000 Doc 0476800 rev. D https://gto.gnresound.com Please also see GTO info doc “GI-01-10-002 – Guide to “WL Only test” - to be found on GTO web Connect the test rec to the HI as shown Mount 2cc coupler to the TM12 coupl mic.
  • Page 19: Wireless Test

    Wireless Test Doc 0476800 rev. D The wireless range test is a combined DSA6000/ NOAHLINK SAS-3 DSA7000 Noahlink/SAS Range Check test using the SAS-3 with its MAC address entered into the DSA 6000/DSA7000 system configuration and a Noahlink mounted directly in any of the DSA units USB ports.
