Assembly Instructions and User's Manual
3 Piece Seating Set
Style # 178038
Please keep this instruction manual for future reference
Customer Service: (888) 922-2336
7:00 am to 5:00 pm CST (daily)
Live Chat at: www.academy.com
Email: customerservice@academy.com
Questions, problems, missing parts? Before returning to the store,
call Customer Service
(Made in China)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Mosaic 178038
Summary of Contents for Mosaic 178038
- Page 1 Assembly Instructions and User's Manual 3 Piece Seating Set Style # 178038 Please keep this instruction manual for future reference Customer Service: (888) 922-2336 7:00 am to 5:00 pm CST (daily) Live Chat at: www.academy.com Email: customerservice@academy.com Questions, problems, missing parts? Before returning to the store,...
-
Page 2: Table Of Contents
Table of Contents Warnings ................2 Tools and Parts ………...…………………………………..3-4 Assembly Instructions ............5-8 Care and Maintenance ............9 Warranty Information ............9 Note: Before beginning assembly of product, make sure all parts are present. Compare parts with package content list. If any part is missing or damaged do not attempt to assemble the unit. -
Page 3: Warnings
Warnings WARNING: Please keep children out of assembly area during assembly. WARNING: Do not stand or put heavy things on furniture. CAUTION: Use furniture on the ground only. IMPORTANT: Please check the tightness of the bolts every 90 days. NOTE: Sharp objects will cause damage of furniture. READ ALL INSTRUCTIONS BEFORE USE To reduce the risk of injury to persons: 1. -
Page 4: Tools And Parts
Parts List (Love seat) Description Picture Back Seat Armrest (Left) Armrest (Right) Hardware List (Love seat) Description Picture Nut Cover PVC Bolt Cover Steel Washer M6X35MM Bolt M6X55MM Bolt M6 Nut Wrench Nut Wrench Page 3 of 9... - Page 5 Parts List (Chair) Description Picture Back Seat Armrest (Left) Armrest (Right) Hardware List (Chair) Description Picture Nut Cover PVC Bolt Cover Steel Washer M6X35MM Bolt M6X55MM Bolt M6 Nut Wrench Nut Wrench Page 4 of 9...
-
Page 6: Assembly Instructions
Assembly Instructions (Love Seat) Step 1: IMPORTANT: Do not fully tighten bolts until all bolts are fastened. Place Armrest (D1) on its side on a flat smooth surface. Then attach Back (A1) to Armrest (D1) with hardware Bolt (DD1) and Steel Washer (CC1) using Wrench (GG1). - Page 7 Assembly Instructions (Love Seat) Step 3: Turn loveseat upright. Attach Armrest (C1) to Seat (B1) with hardware Bolt (EE1), Bolt (CC1), Nut (FF1) and Nut Cover (AA1) using Nut Wrench (JJ1). Step 4: Attach Armrest (C1) to Back (A1) with hardware Bolt (DD1) and Steel Washer (CC1).
- Page 8 Assembly Instructions (Chair) Step 5: IMPORTANT: Do not fully tighten bolts until all bolts are fastened. Place Armrest (D2) on its side on a flat smooth surface. Then attach Back (A2) to Armrest (D2) with hardware PVC Bolt Cover (BB2), Bolt (DD2) and Steel Washer (CC2) using Wrench (GG1).
- Page 9 Assembly Instructions (Chair) Step 7: Turn chair upright. Attach Armrest (C2) to Seat (B2) with hardware Bolt (EE2), Bolt (CC2), Nut (FF2) and Nut Cover (AA2) using Nut Wrench (JJ1). Step 8: Attach Armrest (C2) to Back (A2) with hardware Bolt (DD2) and Steel Washer (CC2) using Wrench (GG1).
-
Page 10: Care And Maintenance
In addition, purchased parts are not covered under this warranty. We reserve the right to make substitutions with similar merchan- dise, if the model in question is no longer in production. SP-JW-178038-ADMY-23001 Page 9 of 9...
