Ivy Bench

FSMVPT2048

WARNING!

Adult assembly required.

Keep screws and small parts out of reach of children.

or (1-855) 242-7255,

WARNING：

THIS PRODUCT CONTAINS ONE OR MORE CHEMICALS KNOWN TO THE STATE OF CALIFORNIA

TO CAUSE CANCER AND/OR BIRTH DEFECTS OR OTHER REPRODUCTIVE HARM.

Need help?

Do you have a question about the Ivy Bench and is the answer not in the manual?

Page 1 Ivy Bench FSMVPT2048 WARNING! Adult assembly required. Keep screws and small parts out of reach of children. or (1-855) 242-7255, WARNING： THIS PRODUCT CONTAINS ONE OR MORE CHEMICALS KNOWN TO THE STATE OF CALIFORNIA TO CAUSE CANCER AND/OR BIRTH DEFECTS OR OTHER REPRODUCTIVE HARM.
Page 2 Table Of Contents Warnings Care and Maintenance Warranty Information Tools Required Parts List Hardware Assembly Instructions...
Page 3 This bench requires adult assembly. Keep screws and parts away from children. Please read this manual before assembly or use. Do not tighten nuts or screws until assembly is complete. Before assembly, check the package contents carefully to ensure that all parts are included. For missing or replacement parts, contact customer service at (888) 922-2336 or (1-855) 242-7255.
Page 4: Limited Warranty
Limited Warranty Frame is under warranty from defects for a period of one (1) year. Wrench Allen wrench...
Page 5 Right Leg Left Leg Bench Seat Bench Back 70mm Bolt 50mm Bolt Hexagonal Nut Washer End Cap...
Page 6 Step 1: I G H Attach the bench back(D) to the left leg(B) using two 70mm bolts(E), two washers(H) and two hexagonal nuts (G). Repeat this step to attach the bench back to the right leg(A). Hand tighten only. Step 2: Attach the bench seat(C)to the left leg (B) using two 50mm bolts(F), two washers(H) and two hexagonal nuts...
