KickAss ULTRA-X KA12230X-LION Owner's Manual

Lithium batteries

Advertisement

Quick Links

ULTRA-X SERIES
LITHIUM BATTERIES
OWNER'S MANUAL
KA12230X-LION | KA12230SLIMX-LION | KA12230X-LION-W | KA12230SLIMX-LION-W
V1.3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ULTRA-X KA12230X-LION and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for KickAss ULTRA-X KA12230X-LION

  • Page 1 ULTRA-X SERIES LITHIUM BATTERIES OWNER’S MANUAL KA12230X-LION | KA12230SLIMX-LION | KA12230X-LION-W | KA12230SLIMX-LION-W V1.3...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS WARNING AND SAFETY INFORMATION ------------------------------------------------------ PRODUCT SPECIFICATIONS ------------------------------------------------------------------ DIMENSIONS ---------------------------------------------------------------------------------- INCLUDED COMPONENTS -------------------------------------------------------------------- OPTIONAL ACCESSORIES ----------------------------------------------------------------- PRODUCT FEATURES ------------------------------------------------------------------------- REMOTE BLUETOOTH MONITORING ------------------------------------------------------ MONITORING VIA REMOTE DISPLAY ------------------------------------------------------ PARALLEL AND SERIES CONFIGURATION ------------------------------------------------ REMOTE DISPLAY MONITORING FOR SERIES AND PARALLEL CONFIGURATION ------- KA LITHIUM APP ---------------------------------------------------------------------------...
  • Page 3: Warning And Safety Information

    WARNING AND SAFETY INFORMATION • Always use the specified charger designed for the lithium battery. Using an incorrect charger may cause damage or create a safety hazard. • Do not charge the battery beyond its recommended voltage or current limits. Overcharging can lead to overheating, fire, or explosion.
  • Page 4: Product Specifications

    PRODUCT SPECIFICATIONS KA12230X-LION KA12230SLIMX-LION KA12230X-LION-W KA12230SLIMX-LION-W Battery Type LiFePO4 Nominal Voltage 12.8V Rated Capacity 230Ah Energy 2944Wh Parallel Connection Yes (4 Max) Series Connection Yes (4 Max) Bluetooth Monitoring Remote Display Monitoring Max Charge Voltage 14.6V Charge Temperature 0 ~ +55°C Max Continuous Charge Current 230A Discharge Temperature...
  • Page 5: Dimensions

    DIMENSIONS 223mm 213mm 360mm 70mm 510mm 500mm...
  • Page 6: Included Components

    Mounting Bracket 50cm RJ45 cable 2 x MB x 16mm bolt with flat and spring washer KA12230SLIMX-LION OPTIONAL ACCESSORIES KickAss Remote Smart 400mm Long Battery Linking 525mm Long Battery Linking Lithium Battery Display Unit cables for KA12230X-LION cables for KA12230X-LION...
  • Page 7: Product Features

    PRODUCT FEATURES Remote Bluetooth Monitoring The KA Lithium App allows users to connect and monitor one or multiple batteries simultaneously, whether configured in parallel or series, directly from a mobile device. Features of the KA Lithium App: • State of Charge (SOC): Displays the remaining charge in the battery/battery pack.
  • Page 8: Monitoring Via Remote Display

    Monitoring via Remote Display The remote display offers a fixed monitoring solution for your KickAss Battery, or battery bank. It connects via an RJ45 cable and provides the following information: • State of Charge (SOC): Displays the remaining charge in the battery.
  • Page 9: Remote Display Monitoring For Series And Parallel Configuration

    In a series configuration, the system voltage increases while the capacity (measured in Ah) and the total continuous charge and discharge ratings remain consistent System System Max Continuous System Voltage (V) Discharge Rate (A) Capacity (Ah) Watthours (Wh) 1 x 230Ah Battery 12.8V 230Ah 2944Wh...
  • Page 10: Parallel And Series Power Calculations

    Parallel and Series Power Calculations When configured as a parallel battery bank, the KA Lithium App calculates the State of Charge (SOC) and Voltage as the average values across all connected batteries. In this configuration, the app displays the total Current and Capacity for the entire parallel battery bank, reflecting the combined output.
  • Page 11: Battery Management System

    Battery Management System The Battery Management System (BMS) is a crucial component of the Ultra-X battery range, ensuring its safe and efficient operation. The BMS performs two primary functions: • Monitoring: Continuously tracks key parameters such as cell voltage, charge/discharge rates, and temperature to maintain safe operating conditions for the battery.
  • Page 12: Product Installation

    PRODUCT INSTALLATION Installing Mounting Brackets M8 Mounting Hardware (not supplied). Please use appropriate mounting hardware for the material the battery will be mounted to. M8 Mounting Hardware (not supplied). Please use appropriate mounting hardware for the material the battery will be mounted to.
  • Page 13: Wiring Diagram

    Wiring Diagram M8 BOLT SPRING WASHER WASHER BATTERY HOOK UP CABLE...
  • Page 14: Parallel Wiring Diagram

    5 YEAR WARRANTY INFO/SUPPORT 5 YEAR WARRANTY INFO/SUPPORT 5 YEAR WARRANTY INFO/SUPPORT 5 YEAR WARRANTY INFO/SUPPORT MADE IN CHINA | KICKASS QUALITY MADE IN CHINA | KICKASS QUALITY MADE IN CHINA | KICKASS QUALITY MADE IN CHINA | KICKASS QUALITY...
  • Page 15 Doing so may damage the Remote Display Communication port. WARNING: Verify that all loads or devices to be powered by the KickAss LiFePO4 battery are turned off before starting the installation. WARNING: Ensure any isolation devices used in the installation are switched off...
  • Page 16: Series Wiring Diagram

    5 YEAR WARRANTY INFO/SUPPORT 5 YEAR WARRANTY INFO/SUPPORT 5 YEAR WARRANTY INFO/SUPPORT 5 YEAR WARRANTY INFO/SUPPORT MADE IN CHINA | KICKASS QUALITY MADE IN CHINA | KICKASS QUALITY MADE IN CHINA | KICKASS QUALITY MADE IN CHINA | KICKASS QUALITY...
  • Page 17 Doing so may damage the Remote Display Communication port. WARNING: Verify that all loads or devices to be powered by the KickAss LiFePO4 battery are turned off before starting the installation. WARNING: Ensure any isolation devices used in the installation are switched off...
  • Page 18: Bluetooth Connection

    Bluetooth Connection Download and open the KA Lithium App. 1. Select “Single”. 2. Select the battery 3. Select the desired selection menu to battery. connect. 4. Select the back button. 5. The battery is now 6. For quick connection connected. after the App is closed, select the “Connect the selected device”...
  • Page 19: Bluetooth Connection - Parallel Configuration

    Bluetooth Connection – Parallel Configuration 1. Select “Paralleling”. 2. Select the battery 3. Select the desired selection menu to batteries. connect. 4. Select the back button. 5. Batteries are now 6. For quick connection configured for parallel after the App is closed, configuration.
  • Page 20: Bluetooth Connection - Series Configuration

    Bluetooth Connection – Series Configuration 1. Select “Series”. 2. Select the battery 3. Select the desired selection menu to batteries. connect. 4. Select the back button. 5. Batteries are now 6. For quick connection configured for series after the App is closed, configuration.
  • Page 21: Troubleshooting

    TROUBLESHOOTING SOC Calibration After receiving your KickAss Lithium battery, or if the battery has been in storage or powering only a small load for an extended period, it may require a full charge to recalibrate the State of Charge (SOC). Prolonged inactivity can lead to...
  • Page 22: Bms Warning An Fault Codes

    BMS Warning an Fault Codes WARNING / BMS ACTION RELEASE METHOD USER ACTION FAULT CODE Over Voltage The BMS will Protection is automatically Ensure you use the correct Protection stop further released once the battery cells charger for your lithium charging.
  • Page 23: Warranty Disclaimer

    KICKASS PRODUCTS PTY LTD. WARRANTY DISCLAIMER At Kickass Products Pty Ltd., we stand behind the quality and durability of our outdoor and camping products. Our product team rigorously tests every item in demanding conditions to ensure performance in normal use environments.
  • Page 24 KickAss is a registered trademark of KickAss Products Pty Ltd. Designed & imported by KickAss Products Pty Ltd 39 Iris Place, Acacia Ridge, QLD 4110 Australia Made in China...
