KickAss KA12120XB-LION Owner's Manual

12v deep cycle lithium battery

Advertisement

Quick Links

12V DEEP CYCLE
LITHIUM BATTERY
OWNER'S MANUAL
KA12120XB-LION | KA12200XB-LION
V1.3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KA12120XB-LION and is the answer not in the manual?

Questions and answers

Summary of Contents for KickAss KA12120XB-LION

  • Page 1 12V DEEP CYCLE LITHIUM BATTERY OWNER’S MANUAL KA12120XB-LION | KA12200XB-LION V1.3...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS ---------------------------------------------------------- QUICK START GUIDE ------------------------------------------------------- SAFETY INFORMATION -------------------------------------------------- PRODUCT SPECIFICATIONS ------------------------------------------------------------------ DIMENSIONS ----------------------------------------------------- INCLUDED COMPONENTS --------------------------------------------------------- PRODUCT FEATURES ------------------------------------ A-GRADE LIFEPO4 PRISMATIC CELLS ------------------------------------------------ 100% USABLE CAPACITY -------------------------------- CONTINUOUS CHARGE AND DISCHARGE ------------------------------- PARALLEL AND SERIES CONFIGURATION ------------------ 4000+ CYCLES @ 80% DEPTH OF DISCHARGE –...
  • Page 3: Quick Start Guide

    QUICK START GUIDE • You KickAss Smart Lithium Battery has been shipped at approximately 60% SOC. When you first receive your battery, please complete a full charge of the battery before use, ensuring the battery charger indicates the battery is full before removing the battery from charge.
  • Page 4: Safety Information

    SAFETY INFORMATION • Always use the specified charger designed for the lithium battery. Using an incorrect charger may cause damage or create a safety hazard. • Do not charge the battery beyond its recommended voltage or current limits. • Overcharging can lead to overheating, fire, or explosion. •...
  • Page 5: Product Specifications

    PRODUCT SPECIFICATIONS KA12120XB-LION KA12200XB-LION Battery Type LiFePO4 LiFePO4 Voltage 12.8V 12.8V Capacity 120Ah 200Ah Energy 1536Wh 2560Wh Parallel Connection Yes (4 Max) Yes (4 Max) Series Connection Yes (4 Max) Yes (4 Max) Max Charge Voltage 14.6V 14.6V Charge Temperature Range 0 ~ +60°C...
  • Page 6: Dimensions

    DIMENSIONS 211mm 11.85Kg 159mm 316mm 241mm 244mm 522mm 20.40Kg...
  • Page 7: Included Components

    2 X M8 X 16mm bolt with flat and spring washer flat and spring washer OPTIONAL ACCESSORIES OPTIONAL ACCESSORIES KickAss N70 Tray KickAss 200Ah Battery Tray SKU: KAN70TRAY SKU: KA12200TRAY KickAss Battery Linking Cables KickAss Battery Linking Cables 2AWG 400mm...
  • Page 8: Product Features

    Pod Machine 1.3hrs 2.2hrs Continuous Charge and Discharge The KickAss KickAss 12V Deep Cycle Lithium – LiFePO4, supports a 1C continuous charge and discharge current. Parallel and Series Configuration KickAss 12V Deep Cycle Lithium Batteries - LiFePO4 batteries can be connected in either parallel or series configurations, but not simultaneously in...
  • Page 9: 4000+ Cycles @ 80% Depth Of Discharge - 0.5C

    Table C 4000+ Cycles @ 80% Depth of Discharge – 0.5C The KickAss 12V 120Ah Deep Cycle Lithium Battery - LiFePO4 is rated for 4000+ cycles at a depth of discharge (DoD) of 80% at discharge rate of 0.5C. Reducing or increasing the average DoD of the battery will increase, or reduce the cycle life of the battery accordingly.
  • Page 10: Battery Management System

    Battery Management System The Battery Management System (BMS) is a crucial component of the LiFePO4 battery, ensuring its safe and efficient operation. The BMS performs two primary functions: • Cell Balancing: Balances the voltages of individual LiFePO4 cells during charging to ensure even cell performance, thereby enhancing battery longevity •...
  • Page 11: Product Overview

    PRODUCT OVERVIEW Wiring Diagram M8 BOLT SPRING WASHER WASHER BATTERY HOOK UP CABLE...
  • Page 12: Parallel Wiring Diagram

    Failure to follow this procedure may affect the performance and lifespan of the LiFePO4 batteries. B) We recommended using our KickAss Battery Linking Cables, 2AWG, 400mm length (BALINK8400), for connecting batteries in parallel. Series Wiring Diagram...
  • Page 13: Product Installation

    WARNING: Before connecting the battery, ensure it has been fully charged and allowed to rest for 30 minutes. WARNING: Verify that all loads or devices to be powered by the KickAss LiFePO4 battery are turned off before starting the installation.
  • Page 14: Troubleshooting

    TROUBLESHOOTING BMS PROTECTION AND EXPECTED BEHAVIOUR Protection Action Release Condition User Action Type Cell Over- BMS will stop the Protection is Check that the output Voltage battery from charging. automatically released voltage of the connected Protection once the battery cell charger is below the voltage returns to a safe maximum charge...
  • Page 15 Protection Action Release Condition User Action Type Short Circuit BMS will stop the battery Protection is automatically Check the installation for Protection from discharging. released once the load is any signs of a short disconnected or a circuit. Rectify the charging source is installation if required.
  • Page 16: Warranty Disclaimer

    KICKASS PRODUCTS PTY LTD. WARRANTY DISCLAIMER At Kickass Products Pty Ltd., we stand behind the quality and durability of our outdoor and camping products. Our product team rigorously tests every item in demanding conditions to ensure performance in normal use environments.
  • Page 17 KickAss is a registered trademark of KickAss Products Pty Ltd Designed & imported by KickAss Products Pty Ltd 39 Iris Place, Acacia Ridge, QLD 4110 Australia Made in China...
