Summary of Contents for KickAss ULTRA SLIM KA12105ULTRASLIM-LI

  • Page 1 ULTRA SLIM LITHIUM LiFePO USER MANUAL KA12105ULTRASLIM-LI VER 0.9 © 2023, KickAss Products Pty Ltd. All rights reserved.
  • Page 2: Table Of Contents

    - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - THE ULTIMATE KICKASS ULTRA SLIM SETUP...
  • Page 3: Introduction

    Designed by the KickAss Team KickAss are proud to add to our growing range of Lithium power solutions. The new KickAss Ultra Slim Lithium Battery has been specifically designed for fitments where space is a limited. Through customer feedback and research, the team designed a feature rich plug &...
  • Page 4: Important Safety Instructions

    Keep out of reach of children. Ÿ When charging or discharging KickAss Lithium Batteries, ensure the total charge or discharge current does not exceed the maximum specified - see battery specifications table located on the battery and in this user manual.
  • Page 5: Overview

    OVERVIEW Metal case with DCDC mounting points mounting brackets (optional bracket) HIGH QUALITY HIGH QUALITY POWER COATED POWER COATED STEEL CASE STEEL CASE 2 X 50A Anderson Connectors (max. 50A) 10A 12V Socket 10A Resettable Circuit Breaker Bluetooth Indicator KA Remote Display Unit Connector 2 X 175A Anderson Connectors (Max.
  • Page 6: Battery

    BATTERY Features Ÿ 105Ah Lithium Iron Phosphate (LiFePO4) Battery Ÿ 100A Internal Battery Management System (BMS) Ÿ BMS supervised Lithium Battery protection and alarms Ÿ Bluetooth compatibility with KA App (Android and iOS) Ÿ Monitor battery status via the Remote Display Unit (RDU) screen - Plugs into battery.
  • Page 7: Dimensions

    DIMENSIONS...
  • Page 8: Optional Accessories

    OPTIONAL ACCESSORIES DCDC Bracket Kit The KickAss DCDC Bracket kit allows easy fitment of KickAss DCDC-MPPT chargers and includes everything needed for easy plug & play installation. The bracket can be installed in two mounting positions - upright and sideways orientations.
  • Page 9: Inverter Cables

    Inverter Cables (Optional) KickAss Inverter leads have been designed to allow you to easily connect a high powered load to the battery. The Inverter Cables have been designed to work flawlessly to provide high current flow to your 1200W Inverter, and will also work perfectly to connect other KA products like the KickAss Control Hub.
  • Page 10: Kickass Control Hub Connection

    KICKASS Control Hub Connection KACTRLHBDCDC...
  • Page 11: Remote Display Unit

    The KickAss Lithium Battery Remote Display Unit (RDU) has been specifically designed to pair seamlessly with the KickAss Lithium Battery range. The RDU allows you to monitor the state and condition of the battery from up to 10m away. The unit features the following: ●...
  • Page 12: Connecting Rdu

    Connecting RDU To connect the RDU to the Ultra Slim Battery, simply align connectors, push together and secure by twisting treaded locking ring.
  • Page 13: Kickass Lithium App

    KICKASS LITHIUM APP The KickAss Lithium Battery has been designed with the latest Bluetooth technology to remotely State Of Charge State of Charge monitor your battery from your smartphone. The app features the 100% State Of Charge Ring following: Ÿ...
  • Page 14: Connecting To The App

    Outback Proof Gear App from the Google Play store or the Apple iTunes Store. If the app is already downloaded on your device for use with your KickAss Bluetooth Fridge, you must ensure that any updates to the App are installed prior to connecting.
  • Page 15: Kickass Lithium Bms Alarm Modes

    KICKASS LITHIUM BMS ALARM MODES LCD screen ALARM MODE APP SYSTEM WARNING SYSTEM WARNING Charging Over Voltage Error Over Voltage Protection: The voltage of your battery has exceeded the normal range. Remove charger View Error from battery CHARGING OVER VOLTAGE...
  • Page 16: Lithium Battery Bms Recovery Procedures

    LITHIUM BATTERY BMS RECOVERY PROCEDURES The KickAss Ultra Slim Lithium Battery BMS have been designed to safely maximise the life of the battery by protecting the internal LiFePO4 cells. Several of the protection features require a recovery procedure be conducted to re-activate the battery. These Recovery features are: Ÿ...
  • Page 17: Connections

    CONNECTIONS Note: The total output load of all connections combined must not exceed 100A INPUTS/OUTPUTS 2x 50A ANDERSON CONNECTOR = Input/Output for connecting chargers and loads = Total combined power must not exceed 50A total current = Protected by 50A Auto resettable circuit breaker WARNING: 1.
  • Page 18: Connecting To External Chargers

    NOTE: CANNOT EXCEED A TOTAL OF 100 AMPS COMBINED Battery Box Vehicle Recovery Cables KABBJUMP CONNECTING TO EXTERNAL CHARGERS The KickAss Ultra Slim Lithium Battery may be charged in a number of ways: Ÿ Connecting an AC charger to any of the in/out Anderson style connectors. Ÿ...
  • Page 19: Typical Diagrams

    TYPICAL DIAGRAMS POWER LEAD ACID GEL LITHIUM C O M PAT I B I L I T Y CHARGING/ FAULT KACHG1222 KAPWM30A KASB160 KARTSP170 VEHICLE IGNITION VEHICLE KAPRDBWK8MMPP BATTERY...
  • Page 20: Connecting Dcdc Charger

    CONNECTING DCDC CHARGER Charging via vehicle alternator is simple and can done easily by using the KickAss Plug & Play wiring kit. (Sold separately) The triple Anderson style connector fitted to the DCDC interfaces with the KickAss Plug & Play Wiring Kit, providing a simple, quick connect vehicle charging solution. This triple connector and cable provides alternator power to the DCDC, along with an Ignition Source for charging in vehicles that are fitted with Smart or Temperature...
  • Page 21: Connecting To Unregulated Solar

    CONNECTING TO UNREGULATED SOLAR KickAss Ultra Slim Lithium Battery when installed with a KA DCDC - MPPT Charger with built-in regulator will be suitable for charging from unregulated solar panels. To connect your solar panel to the regulator simply plug it in via the Anderson style solar input plug labeled on the charger.
  • Page 22: The Ultimate Kickass Ultra Slim Setup

    THE ULTIMATE KICKASS ULTRA SLIM SETUP KACTRLHBDCDC KACHG1222 POWER LEAD ACID GEL LITHIUM C O M PAT I B I L I T Y CHARGING/ FAULT KABB-IC KABB-IC DIGITAL CONTROL 1200W PURE SINE WAVE DIGITAL INVERTER INPUT: 12V OUTPUT: 220-240V~,50Hz USB OUTPUT: 5V 2.1A...
  • Page 23: Technical Specifications

    WARNING: 1. Combined output must not exceed 100A. 1. Do not plug in multiple chargers as inputs 2. KickAss Lithium batteries should not be used 2. Do not use an external charger while the DCDC for jump starting. Charger is operating 3.
