Parts and Service Manual
BW213D-5 / BW219D-5 DRUM ROLLER
HEPA H14 Variable Speed Pressuriser | INPRESS TS Cabin Display with CO2 Sensor | HEPA Return Air Filter
BOMAG
Controlled Document: M0298
Issue Date: 20/12/23
Revision: 1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Bomag BW213D-5
Summary of Contents for Bomag BW213D-5
- Page 1 Kit Part Number: 700044 Parts and Service Manual BOMAG BW213D-5 / BW219D-5 DRUM ROLLER HEPA H14 Variable Speed Pressuriser | INPRESS TS Cabin Display with CO2 Sensor | HEPA Return Air Filter +61 7 3276 7833 www.breathe-safe.com.au Controlled Document: M0298 sales@breathe-safe.com...
-
Page 2: Table Of Contents
BOMAG BW213D-5 / BW219D-5 Drum Roller INSTALLATION INSTALLATION OVERVIEW Manufacturer Bomag CONTENTS Type Drum Roller Model BW213D-5 / BW219D-5 Installation ........1 Cabin Pressure Max Safety ..........2 Set Auto Cabin Pressure Critical Parts & Maintenance Schedule ........3 Operator Guide ......4 Specifications - Pressuriser ..... -
Page 3: Safety
BOMAG BW213D-5 / BW219D-5 Drum Roller SAFETY WARNING Particulate Behaviour THE PRESSURISATION SYSTEM DESCRIBED IN THIS MANUAL HAS THE FOLLOWING AREAS WHICH MAY BE DANGEROUS IF NOT TREATED WITH This is the length of time it takes for a particle to drop from a height GREAT CARE. -
Page 4: Critical Parts & Maintenance Schedule
BOMAG BW213D-5 / BW219D-5 Drum Roller CRITICAL PARTS & MAINTENANCE SCHEDULE Maintenance Schedule The following tables show our suggested maintenance schedule Critical Parts for all units. Please note that site conditions may alter this. Item Part Number Qty. Description Service Interval Excludes high corrosion environments. -
Page 5: Normal Operating Condition
BOMAG BW213D-5 / BW219D-5 Drum Roller OPERATOR GUIDE OPERATORS CHECKLIST PRE-START Visually inspect the BreatheSafe system for any damage. Visually inspect the cabin for any damage to doors, windows, seals. Please remove dust & debris from shoes and clothes before entering the cabin. -
Page 6: Specifications - Pressuriser
BOMAG BW213D-5 / BW219D-5 Drum Roller SPECIFICATIONS HIGH-CAPACITY HEPA PRESSURISER Specifications High-Capacity HEPA Pressuriser List of Abbreviations Blower : Brushless Blower P/N 200003. Dual HEPA Protection : Locked Rotor Protection (Sub Zero Environments) Under DHPR Dual HEPA Powered Recirculation Voltage, Under/Over Current & Over Temperature. - Page 7 BOMAG BW213D-5 / BW219D-5 Drum Roller Item No. Qty. Description Part No. PARTS LIST – TL2 12V DC PRESSURISER UNIT Pre-cleaner Hood & Rotor Assy 200004 Pre-cleaner Injector Ring 200005 200001 PRESSURISER ASSEMBLY No: TL Fan Blade (inc. in #7)
-
Page 8: Parts List
BOMAG BW213D-5 / BW219D-5 Drum Roller Item No. Part No. Rev Description Colour Category PARTS LIST GA 100009A01 Pressuriser Module Charcoal Grey MX83-682 Module 100009F01 Fresh Air Module Charcoal Grey MX83-682 Module 700044 COMPLETE ASSEMBLY No: 100009M01 Monitor Mount Assembly... - Page 9 BOMAG BW213D-5 / BW219D-5 Drum Roller Item No. Part No. Rev Description Material Thickness Colour Category PARTS LIST – PRESSURISER MODULE 100009A02 TL Spigot Mount Assy Weld Assy 200001 TL2 12V DC Unit Stock Item...
- Page 10 BOMAG BW213D-5 / BW219D-5 Drum Roller Item No. Part No. Rev Description Material Thickness Colour Category PARTS LIST – FRESH AIR MODULE 100009F02 Fresh Air Welded Assy Weld Assy...
- Page 11 BOMAG BW213D-5 / BW219D-5 Drum Roller Item No. Part No. Rev Description Material Thickness Colour Category PARTS LIST – MONITOR MODULE 250101 Controller LRG STD Box (Prt Dwgs) (Per Assy) Stock Item...
- Page 12 BOMAG BW213D-5 / BW219D-5 Drum Roller Item No. Part No. Rev Description Material Thickness Colour Category PARTS LIST – PIPEWORK MODULE 300388-0285 76.3 x 1.6 @285mm Stainless Steel Ø3.0”ODx1.6WT (Per Assy) 200307 3” x 90* Elbow Long Drop Sil Silicone...
- Page 13 BOMAG BW213D-5 / BW219D-5 Drum Roller Item No. Part No. Rev Description Material Thickness Colour Category PARTS LIST – RETURN AIR MODULE 100009R02 Filter Base Welded Assy (Prt Dwgs) (Prt Dwgs) Charcoal Grey MX83-682 Weld Assy 100009R04 Clamp (Prt Dwgs)
-
Page 14: Technical Details
BOMAG BW213D-5 / BW219D-5 Drum Roller TECHNICAL DETAILS CO2 Sensor Display Key Features • • CO2 Sensor Type is NDIR (Non-Dispersive Infrared) Digital cabin pressure monitoring system • • Sample Rate is every 2 seconds Automatic cabin pressure control •... -
Page 15: Wiring Diagram
BOMAG BW213D-5 / BW219D-5 Drum Roller TECHNICAL DETAILS Connections: 200027 Wiring Diagram Item Destination PIPE A – AMBIENT PRESSURE – OUTSIDE PIPE P – POSITIVE PRESSURE – INSIDE RJ45 CONNECTOR – CO2 SENSOR OVERRIDE TOGGLE SW = MAX SPEED Item Destination... -
Page 16: Smoke Emitter Cabin Pressure Leak Test
BOMAG BW213D-5 / BW219D-5 Drum Roller * Do not handle until MSDS & all safety precautions have been read and understood. Use personal protective equipment as required. SMOKE EMITTER CABIN PRESSURE LEAK TEST Before use, carefully read the product label. Safe work practices are advised to avoid eye or skin contact and inhalation. Observe good personal hygiene, including washing hands before eating. -
Page 17: Cabin Sealing Test Pressure
BOMAG BW213D-5 / BW219D-5 Drum Roller CABIN SEALING TEST PROCEDURE Cabin Sealing Efficiency Test Procedure Start Engine – Pressuriser System is ON Ensure all windows & door(s) are CLOSED correctly (no cabin pressure leaks) NOTE: for a new cabin with effective seals, you may need to open a window slightly before closing the door to bleed the static cabin air pressure outwards. Once door is fully closed then close windows to begin testing. -
Page 18: Commissioning Procedures
BOMAG BW213D-5 / BW219D-5 Drum Roller COMMISSIONING PROCEDURES – CABIN PRESSURISER Commissioning Procedures Follow each step of the installation guide that was supplied with the BreatheSafe kit. Cabin sealing is an integral part of RS20 & ISO 23875; you must ensure that cabin seals are adequate for maintaining positive pressure. In addition, the site (end- user) must have the correct procedure(s) for servicing OPERATOR enclosure seals in a proactive manner rather than reactive. -
Page 19: Troubleshooting Guide
BOMAG BW213D-5 / BW219D-5 Drum Roller BREATHESAFE SYSTEM TROUBLE SHOOTING GUIDE *TOUCH CONTROL FAULT POSSIBLE CAUSE SOLUTION *ERR error code Poor sensor connection Remove & refit pod connection cable Corrupted coding Contact support for default reset pin *Check filter alarm... -
Page 20: Enter Setup Mode
BOMAG BW213D-5 / BW219D-5 Drum Roller USER SETTINGS INSTRUCTIONS User Settings Instructions ENTER SET UP MODE Start-Up Screen > Main Screen > Settings Button > Settings Screen > Site Access Button > Insert Pin > Site Menu BACK Enter Pin To enter the Setup mode, press the SETTING button. - Page 21 BOMAG BW213D-5 / BW219D-5 Drum Roller PRESSURE ALARM SETTING USER SETTINGS INSTRUCTIONS PRESSURE SETPOINT The mining industry benchmark for cabin pressure is 50 pascals and low-pressure is The pressure setpoint changes the pressure that the cabin will be maintained. set at 20 pascals.
-
Page 22: Service Interval
BOMAG BW213D-5 / BW219D-5 Drum Roller USER SETTINGS INSTRUCTIONS SERVICE INTERVAL DATE & TIME SETTINGS Use the onscreen UP and DOWN buttons to change the service interval setpoint. Change the recorded date displayed and measured by the INPRESS TS. To reset the current runtime to zero, press the RESET CURRENT RUNTIME button and enter the site access pin. - Page 23 BOMAG BW213D-5 / BW219D-5 Drum Roller ALARM BUZZER SETTINGS PRESSURE ALARM BUZZER SETTING CALIBRATE ZERO SENSOR To disable the buzzer, toggle through to the ENABLED and DISABLED buttons. Over long runtime, the 200027 may need recalibration. This screen allows the sensor to be recalibrated if more than 5 Pascals are out.
- Page 24 BOMAG BW213D-5 / BW219D-5 Drum Roller CO2 SETTINGS CO2 MODULE ENABLE/DISABLE CO2 PRIMARY ALARM POINT Enable or disable to CO2 module used for measuring CO2 levels within the cabin. The first alarm will sound when CO2 levels inside the enclosure reach this point.
- Page 25 BOMAG BW213D-5 / BW219D-5 Drum Roller CO2 SETTINGS CO2 ALARM DELAY CO2 CRITICAL ALARM MUTE RESET After CO2 (concentration in ppm) within the cabin reaches the 1000 ppm setpoint, the The critical alarm is set at 2500 PPM and cannot be changed. The mute delay, alarm will sound after this designated amount of time.
-
Page 26: Data Download
BOMAG BW213D-5 / BW219D-5 Drum Roller DATA DOWNLOAD Data Download – Setting up RS232 Connection Click OK once the correct Plug the RS232/USB adaptor communication port has into a free USB port on your been identified. computer. Open up TeraTerm software. - Page 27 BOMAG BW213D-5 / BW219D-5 Drum Roller DATA DOWNLOAD Data Download – Setting up RS232 Connection If required, you may choose From the drop-down menu, to save the COM port click on Restore setup. settings. Go to Settings and click save the setup.
-
Page 28: Controller Setup
BOMAG BW213D-5 / BW219D-5 Drum Roller CONTROLLER SET UP INPRESS Controller Set Up 4. Press ‘LOG SETTINGS’. 1. Press ‘SITE ACCESS MENU’. 2. Enter the access pin ‘7597’. 5. Press ‘DOWNLOAD LOG FILE’. 3. Press ‘NEXT’. 6. Data is now downloading from... - Page 29 BOMAG BW213D-5 / BW219D-5 Drum Roller DATA DOWNLOAD Data Download – Copying Contents from Terminal to Spreadsheet Excel Data Instructions – Unformatted 12 From the drop-down menu, Open an Excel sheet and select the first cell A-1. Next, press and hold down...
-
Page 30: Warranty
BOMAG BW213D-5 / BW219D-5 Drum Roller INPRESS TL WARRANTY BreatheSafe responsibilities Express Warranty If there is a defect in material or workmanship not caused by the excluded failures during the warranty period, All BreatheSafe products carry a warranty against defects in materials or workmanship, provided the BreatheSafe will either replace the defective goods at our Queensland factory, or designated branch.
