D5CERAA
Outdoor Unit Cooling Only Ductless System
Sizes 9K - 24K
Fig. 1 -All Sizes
NOTES: Read the entire instruction manual before
starting the installation.
Images are for illustration purposes only. Actual
models may differ slightly.
Installation Instructions
Specifications subject to change without notice.
TABLE OF CONTENTS
SAFETY CONSIDERATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
CAPACITY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
DIMENSIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
CLEARANCES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
INSTALL THE OUTDOOR UNIT . . . . . . . . . . . . . . . . . . . . . . . . . 15
REFRIGERANT PIPING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
AIR EVACUATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
WIRING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
TEST RUN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
CARE AND MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
PACKING AND UNPACKING THE UNIT . . . . . . . . . . . . . . . . . . 24
ERROR CODES. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
DUCTLESS START-UP CHECKLIST . . . . . . . . . . . . . . . . . . . . . . 26
Page
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Carrier D5CERAA
Summary of Contents for Carrier D5CERAA
-
Page 1: Table Of Contents
D5CERAA Outdoor Unit Cooling Only Ductless System Sizes 9K - 24K Installation Instructions TABLE OF CONTENTS Page SAFETY CONSIDERATIONS ......2 CAPACITY . -
Page 2: Safety Considerations
D5CERAA: Installation Instructions SAFETY CONSIDERATIONS CAUTION Installing, starting up, and servicing air-conditioning equipment can be hazardous due to system pressures, electrical components, and equipment location (roofs, elevated structures, etc.). EQUIPMENT DAMAGE HAZARD Only trained, qualified installers and service mechanics should install, Failure to follow this caution may result in equipment damage or start-up, and service this equipment. - Page 3 D5CERAA: Installation Instructions WARNING WARNING Turn of the unit and disconnect the power before performing any FOR FLAMMABLE REFRIGERANTS installation or repairing. Failure to do so can cause electric shock. Do not use means to accelerate the defrosting process or to clean, other than those recommended by the manufacturer.
- Page 4 D5CERAA: Installation Instructions 1. Installation (where refrigerant pipes are allowed) isolated from the vacuum pump and the pressure shall not rise Any person who is involved with working on or breaking into a above 1500 microns within 10 min. The vacuum pressure level...
- Page 5 D5CERAA: Installation Instructions 9. No ignition sources 13. Cabling No person carrying out work in relation to a REFRIGERATING Check that cabling is not subjected to wear, corrosion, excessive SYSTEM which involves exposing any pipe work shall use any pressure, vibration, sharp edges or any other adverse environmental sources of ignition in such a manner that it may lead to the risk of effects.
- Page 6 D5CERAA: Installation Instructions 15. Charging procedures When removing refrigerant from a system, either for servicing or decommissioning, it is recommended good practice that all In addition to conventional charging procedures, the following refrigerants are removed safely. requirements shall be followed: When transferring refrigerant into cylinders, ensure that only •...
- Page 7 D5CERAA: Installation Instructions appliance, if those devices have a potential to become an ignition c. Marking of equipment using signs source. Signs for similar appliances used in a work area are generally • a warning that if appliances connected via an air duct system to...
- Page 8 D5CERAA: Installation Instructions Table 1 — A (min) Ho, release height ft (m) Mc or Mrel ≤ 7.2 (2.2) 7.5 (2.3) 7.9 (2.4) 8.5 (2.6) 9.2 (2.8) 9.8 (3.0) lbs ( kg) ≤ 3.91 (1.776) 12 (1.10) 4.0 (1.8) 60 (5.53) 57 (5.29)
-
Page 9: Capacity
D5CERAA: Installation Instructions CAPACITY Table 2 — Compatible Indoor Units MODEL INDOOR UNIT OUTDOOR UNIT D5FEHAA09XCK D5CERAA09AAK 12K (115V) D5FEHAA12XCJ D5CERAA12AAJ D5FEHAA12XCK D5CERAA12AAK D5FEHAA18XCK D5CERAA18AAK D5FEHAA24XCK D5CERAA24AAK ACCESSORIES Table 3 — Accessories NAME OF ACCESSORIES QUANTITY IMAGE Installation Manual Drain Joint... -
Page 10: Dimensions
D5CERAA: Installation Instructions DIMENSIONS Table 5 — Dimensions and Weights 12K 115V System Size (115 V) (208/230 V) (208/230 V) (208/230 V) (208/230 V) inch 19.49 19.49 19.49 21.85 21.81 Height (H) inch 28.35 28.35 28.35 30.12 31.69 Width (W) inch 10.63... - Page 11 D5CERAA: Installation Instructions DIMENSIONS (CONT.) Fig. 3 —Dimensions (18k) Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.
- Page 12 D5CERAA: Installation Instructions DIMENSIONS (CONT.) Fig. 4 —Dimensions (24k) Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.
-
Page 13: Clearances
D5CERAA: Installation Instructions CLEARANCES Air inlet Air outlet Fig. 5 — Outdoor Unit Clearances Table 6 — Outdoor Unit Clearance Dimensions MINIMUM VALUE UNIT in. (mm) 20 (500) 14 (350) 20 (500) 4 (100) 4 (100) 19in (48cm) or more on... -
Page 14: Installation
D5CERAA: Installation Instructions INSTALLATION OVERVIEW NOTE: Illustrations in this manual are for explanatory purposes. The actual shape of your indoor unit may be slightly different. The actual shape shall prevail. Wall Mounting Plate Drain Pipe Remote Controller Front Panel Connection Cable... -
Page 15: Install The Outdoor Unit
D5CERAA: Installation Instructions INSTALL THE OUTDOOR UNIT 1. Select installation location NOTE: Prior to Installation Before installing the outdoor unit, you must choose an appropriate location. The following are standards that will help you choose an appropriate location for the unit. -
Page 16: Install Drain Joint
D5CERAA: Installation Instructions INSTALL DRAIN JOINT ANCHOR OUTDOOR UNIT WARNING NOTE: Before bolting the outdoor unit in place, you must install the drain joint at the bottom of the unit. For the units with base pan built-in with multiple holes for... -
Page 17: Refrigerant Piping
D5CERAA: Installation Instructions REFRIGERANT PIPING If you install the unit on a wall-mounted bracket, do the following: • Mark the position of bracket holes based on dimensions chart. PIPING CONNECTION PRECAUTIONS • Pre-drill the holes for the expansion bolts. • Place a washer and nut on the end of each expansion bolt. Thread... - Page 18 D5CERAA: Installation Instructions • Remove PVC tape from ends of pipe when ready to perform flaring REFER TO TORQUE REQUIREMENT TO work. CONNECT PIPES • Clamp flare form on the end of the pipe. The end of the pipe must extend beyond the edge of the flare form in accordance with the...
- Page 19 D5CERAA: Installation Instructions Table 11 — Torque Requirements CAUTION Outer Diameter Flare dimension Tightening Torque Flare shape of Pipe Ø 1/4in 13.28 ~ 14.75 ft.lbs. 0.33~0.34in (8.4~8.7mm) (Ø 6.35mm) 18~20 N.m USE WRENCH TO GRIP MAIN BODY OF VALVE 90 ° ± 4 23.6 ~ 28.76 ft.lbs.
-
Page 20: Air Evacuation
D5CERAA: Installation Instructions AIR EVACUATION 6. If there is a change in system pressure, refer to Gas Leak Check section for information on how to check for leaks. NOTE: PREPARATIONS AND PRECAUTIONS 7. If there is no change in system pressure, unscrew the cap from the Air and foreign matter in the refrigerant circuit can packed valve (high pressure valve). - Page 21 D5CERAA: Installation Instructions Table 13 — Electrical Data 12K 115V Outdoor Unit (115V) (208/230V) (208/230V) (208/230V) (208/230V) Minimum Circuit Ampacity (MCA) Maximum Overcurrent Protection Ampacity (MOPA) Voltage-Phase-Frequency 115-1-60 208/230-1-60 Max – Min Voltage Range 127-104 253-187 Cooling (with entry tier high wall CO IDU) Running current 10.3...
-
Page 22: Wiring
D5CERAA: Installation Instructions WIRING WARNING Before performing any electrical work, read these regulations. Before performing any electrical work or wiring work, turn off the main power to the system. 1. All wires must be sized per NEC (National Electrical Code) or CEC (Canadian Electrical Code) and local codes. -
Page 23: Electrical And Gas Leak Checks
D5CERAA: Installation Instructions ELECTRICAL AND GAS LEAK CHECKS WARNING Terminal block RISK OF ELECTRIC SHOCK ALL WIRING MUST COMPLY WITH LOCAL AND Connecting cable NATIONAL ELECTRICAL CODES, AND MUST BE NSTALLED BY A LICENSED ELECTRICIAN. Power supply cord CAUTION Conduit panel... -
Page 24: Test Run
D5CERAA: Installation Instructions TEST RUN Perform Test Run as normal. WARNING BEFORE TEST RUN Only perform test run after you have completed the following steps: Electrical Safety Checks – Confirm that the unit’s electrical Manual system is safe and operating properly... -
Page 25: Error Codes
D5CERAA: Installation Instructions ERROR CODES Table 15 — Error Codes Display Malfunction and Protection Indication Display Malfunction and Protection Indication Outdoor DC fan motor speed out of control ODL DC bus voltage too high protection EC07 PC11 ODU EEPROM error... -
Page 26: Ductless Start-Up Checklist
D5CERAA: Installation Instructions DUCTLESS START-UP CHECKLIST Installation Data Site Address:_______________________________________________________________________________________________________ City:________________________________________________________ State:___________ Zip Code:__________________ Installing Contractor:______________________________________________________ Contractor Contact #: ( ) _____-___________ Job Name:_______________________________________________________________ Start-up Date:_____________________________ Distributor:_______________________________________________________________ System Details Units Model No. Serial No. Controller OUTDOOR UNIT INDOOR UNIT A... -
Page 27: Performance Check
D5CERAA: Installation Instructions Ductless Start-Up Checklist (CONT) Piping Leak Check: System held 500 psig (max. 550psi) for a minimum of 30 minutes using dry nitrogen. YES:______ NO:______ Evacuation Method: • YES:______ NO:______ Was the Triple Evacuation Method used as outlined in the installation manual? •... - Page 28 D5CERAA: Installation Instructions © 2024 Carrier. All rights reserved. Edition Date: 11/24 Catalog No: D5CERAA-01SI Replaces: NEW Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.
