GSC3516/GSC3506 (V2) - User Manual
WELCOME
The GSC3516 is a SIP intercom speaker and microphone that allows offices, schools, hospitals, apartments, and more to build
powerful voice intercom solutions that expand security and communication. This robust SIP intercom device offers 2-way
voice functionality with both a high fidelity 15W HD speaker and 3 directional microphones with Multichannel Microphone
Array Design (MMAD) and 1 omnidirectional auxiliary microphone that offers a 4.2-meter pickup distance. The GSC3516
supports a wide range of peripherals including Bluetooth devices, a built-in allowlist, and blocklists to block unwanted calls
easily, integrated dual-band Wi-Fi, and advanced acoustic echo cancellation. By pairing the GSC3516 with other Grandstream
devices, including desktop and cordless IP phones as well as the GDS series of Facility Access products, users can easily sculpt
a state-of-the-art security and voice intercom solution. Thanks to its modern industrial design, a cleanable exterior surface,
and rich features, the GSC3516 is the ideal intercom speaker/microphone for any setting.
The GSC3506 and GSC3506 V2 are a 1-way public address SIP speaker that allows offices, schools, hospitals, apartments, and
more to build powerful public address announcement solutions that expand security and communication. This robust SIP
speaker offers crystal clear HD audio functionality with a high-fidelity 30-Watt HD speaker. The GSC3506 and GSC3506 V2
support built-in allowlists, blocklists, and greylists to easily block unwanted calls, SIP and multicast paging, group paging, and
Push-to-Talk. users can easily sculpt a state-of-the-art security and PA announcement solution. Thanks to their modern
industrial design and rich features, the GSC3506 and GSC3506 V2 are the ideal SIP speakers for any setting.
PRODUCT OVERVIEW
Feature Highlights
The following table contains the major features of the GSC3516/GSC3506 (V2):
GSC3516
GSC3506
GSC3506 V2
● Up to 16 SIP accounts.
● Ethernet RJ45 10/100Mbps, PoE/PoE+, Integrated Bluetooth, Wi-Fi.
● 2-way voice functionality with both a high-fidelity 15W HD speaker and
3 directional microphones with Multichannel Microphone Array Design
(MMAD) and 1 omnidirectional auxiliary microphone that offer a 4.2
meter pickup distance
● Up to 16 SIP accounts.
● Ethernet RJ45 10/100Mbps, PoE/PoE+
● 1-way public address SIP speaker with crystal clear HD audio
functionality with a high-fidelity 30-Watt HD speaker.
● 2-Pin port enabling  Alarm configuration
● USB Plug support
● Up to 16 SIP accounts.
● Ethernet RJ45 10/100Mbps, PoE/PoE+/PoE++
● 1-way public address SIP speaker with crystal clear HD audio
functionality with a high-fidelity 30-Watt HD speaker.
● 2-Pin Switch-in input port
● 2-Pin Alarm-in input port
● Differential line out port
● USB Plug support
GSC3516/GSC3506/GSC3506 V2 Features in a Glance
