- Page 1 STICK/LIFT TIG WELDER Hot Start, Arc Force and Anti-Stick ARC200 - 9GEN 110V/220V MADE BY BESTARC MUST BE QUALITY PRODUCTS...
-
Page 2: Table Of Contents
CONTENTS www.bestarc.com Safety Parameter Accessories Func�on Layout Installa�on S�ck Opera�on Li� TIG Opera�on 2 IN 1 STICK/LIFT TIG WELDER... -
Page 3: Safety
Incorrectly installed or improperly grounded equipment is a hazard, and can cause serious. Damage, Properly install and ground this equipment according to this manual and na�onal, state, and local codes. Please contact us if any ques�on by mail: support@bestarc.com 2 IN 1 STICK/LIFT TIG WELDER... - Page 4 SAFETY www.bestarc.com WARNING Welding and cu�ng is dangerous to the operator, people in or near the working and surrounding areas, if the equipment is not operated correctly. Therefore the performance of welding/cu�ng must only be under the strict and comprehensive observance of all relevant safety regula�ons.
- Page 5 SAFETY www.bestarc.com CAUTION 1 Working Environment 1.1 The environment in which this welding equipment is installed must be free of grinding dust, corrosive chemicals, flammable gas or materials etc, and at no more than maximum of 80% humidity. 1.2 When using the machine outdoors protect the machine from direct sun light, rain water and snow etc;the temperature of working environment should be...
-
Page 6: Maintenance
SAFETY www.bestarc.com MAINTENANCE Exposure to extremely dusty, damp, or corrosive air is damaging to the welding machine. In order to prevent any possible failure or fault of this welding equipment, clean the dust at regular intervals with clean and dry compressed air of required pressure. -
Page 7: Parameter
PARAMETER www.bestarc.com FEATURES • S�ck /Li� TIG 2 in 1 Welder • 110/220V Dual Voltage • An�-S�ck Feature • Electrode Diameter Selec�on • Adjustable Hot Start & Arc Force • Digital Pulse Width Modula�on (PWM) • Voltage Reduc�on Duty Cycle (VRD) •... -
Page 8: Accessories
ACCESSORIES www.bestarc.com ACCESSORIES DESCRIPTION ARC200 (110V/220V) 1 × ARC200 Welder √ 1 × Earth Clamp With Cable √ 1 × S�ck Holder √ 1 × Wire Adapter √ 1 × Shoulder Strap √ 2 IN 1 STICK/LIFT TIG WELDER... - Page 9 FUNCTION www.bestarc.com Welding mode selec�on: S�ck/Li� TIG Electrode Diameter Selec�on: Φ1.6 Φ2.0 Φ2.5 Φ3.2 Φ4.0 Automa�cally detect input voltage of the machine The fan only runs when the machine gets hot Voltage Reducing Device: Reduce arc voltage when there is no welding current to prevent electric shock.
-
Page 10: Layout
LAYOUT www.bestarc.com FRONT & REAR PANEL LAYOUT ARC200 Handle Electrode Diameter Selec�on Current Knob Arc Force/Hot Start Op�on S�ck/Li� TIG Mode Posi�ve Electrode Nega�ve Electrode Power Cable Power Switch 2 IN 1 STICK/LIFT TIG WELDER... -
Page 11: Installa�On
INSTALLATION www.bestarc.com HOW TO INSTALL MACHINE Earth Clamp S�ck Holder Metal Piece 2 IN 1 STICK/LIFT TIG WELDER... - Page 12 INSTALLATION www.bestarc.com Argon Bo�le Earth Clamp LIFT TIG Torch Matel Piece TIG torch is an op�on, not included in standard accessories. CONNECTION OF THE POWER WIRES • Each machine is equipped with primary power wire, according to the input voltage please connect the primary wire to the suitable voltage class.
- Page 13 INSTALLATION www.bestarc.com CONNECTION OF OUTPUT WIRES • Each welder has two air sockets, connect the plug to the socket on the panel board, �ghten it and make sure that it’s well-connected, otherwise it may causes the damage to both the plug and socket.
-
Page 14: Stick Operation
STICK OPERATION www.bestarc.com STICK OPERATION STARTING METHODS Tapping Method Scratch/Match Method 1. Turn on the power switch on the rear of the unit. Allow unit to cycle through its start upprogram. 2. Select the �ck mode with the TlG/CutS�ck selector switch. - Page 15 LIFT TIG OPERATION www.bestarc.com LIFT TIG OPERATION <1/8 <1/8” 1. Posi�on the point of the sharpened tungsten about 1/8” or less above the metal. 2. Press the torch trigger or press the foot pedal to ini�ate the arc. The HF arc will be ini�ated.
