MODEL 84943
HYDRAULICALLY OPERATED
GREASE PUMP -
SERIES "A"
OWNERS MANUAL
-
0 -
SPECIFICATIONS
RATIO (See Note in Fig. 2) 16:1
INPUT PRESSURE 300-3000 P.S.I.
INPUT FLOW 1 .O G.P.M.
MAXIMUM HYDRAULIC TEMP. 210" F
OUTPUT PRESSURE 3500 P.S.I. MAX.
OUTPUT FLOW 11 CU. INJMIN.
AMBIENT TEMP.
-40" TO +135" F
SEALS
BUNA-N
FILTRATION REQUIRED 10 MICRON
-
DESCRIPTION
Model 64943 is an hydraulically operated
grease pump designed for centralized
lubrication systems on off-road equip-
ment which utilize 24VDC power
sources.
OWNER/OPERATOR
RESPONSIBILITY
It is the owner/operator responsibility to
properly use and maintain this
equipment.
The instructions and warnings contained
in this manual shall be read and under-
stood by the owner/operator prior to
operating this equipment.
If an owner/operator does not under-
stand English, the contents of this
manual shall be explained in the owner/
operator native language to assure the
owner/operator comprehends.
It is the owner/operator responsibility to
maintain the legibility of all warning and
instruction labels.
The owner/operator shall retain this
manual for future reference to
important warnings, operating and
maintenance instructions.
iAlLURE TO HEED THE FOLLOWING
VARNINGS INCLUDING MISUSE,
)VER PRESSURIZING, MODIFYING
' A RTS, USING iNCOMPATiBLE
:HEMiCALS AND FLUIDS, OR USING
VORN OR DAMAGED PARTS, MAY
IESULT IN EQUIPMENT DAMAGE
LNDIOR SERIOUS PERSONAL
NJURY.
l
Do not exceed the stated maximum
working pressure of the pump or of
the lowest rated component in your
system.
l
Do not alter or modify any part of
this equipment.
9 Do not attempt to repair or
disassemble the equipment while
the system is pressurized.
l
Make sure all fluid connections
are securely tightened before
using this equipment.
l
Always read and follow the fluid
manufacturer' s recommendations
regarding fluid compatibility, and
the use of protective clothing and
equipment.
l
Check all equipment regularly and
repair or replace worn or damaged
parts immediately.
