Yunca Gas TOMMI INBUILT Installation Instructions Manual

Wood burner

Advertisement

 Tested to AS/NZS 2918:2001 Appendix B.
 These instructions cover installations of the Yunca Tommi Inbuilt, where the
factory-fitted "Zero Clearance Box" is being used - enabling installation into a
suitably constructed enclosure as per AS/NZS 2918: 2001.
The term "Zero Clearance", or "ZC" is in common parlance, however it refers to
reduced rather than actual nil clearances. Please refer to specifications in this
document in conjunction with the relevant building code if unsure of clearances.
SAFETY INFORMATION
General:
This appliance is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety.
For the protection of young children, install an effective fire safety screen around your fire. Always keep
children well away from the wood burner when it is alight.
Supervise young children to ensure they do not play with the appliance.
During initial burns of the appliance, ventilate the rooms well. It is recommended that babies, small
children, pregnant women and pets should not be present in the area during initial burns as this is the
firebox paint curing period.
Do not make any modifications to the unit and use it only in the manner described in the manual. Using it
in any manner not recommended by the manufacturer may result in injury or death.
Electrical connections:
As the Tommi Inbuilt wood burner is required to be permanently connected to an electrical source, an
isolating switch (wall switch) must be installed.
New circuits or modifications, if required, but be made using the services of a certified electrician only.
Ensure that the outlets you use are grounded properly, polarised and provided with fuse units.
Ensure that the isolation switch is readily accessible after installation. The wood burner must not be
located immediately below an electrical socket.
Never operate the appliance with a damaged plug or cord, or if you observe the fan unit is malfunctioning
or the heater has been damaged in any way. Call the authorised service person immediately for repairs or
making electrical or mechanical adjustments. – Isolate the electrical supply to alleviate any potential risk.
If the supply cord is damaged, the manufacturer, its service agent or a suitably qualified person must
replace it to avoid electrical hazard. Any cord similar to the original can be used.
Install-Tommi_INBUILT_ZC - 2024-08-22.docx
A division of Terry Young Ltd, New Zealand
INSTALLATION INSTRUCTIONS for
TOMMI INBUILT
WOOD BURNER
• Clean Air 0.4g/kg
INBUILT "ZC" INSTALLATIONS
AUGUST 2024
www.yunca.co.nz
Page 1 of 16

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TOMMI INBUILT and is the answer not in the manual?

Questions and answers

Summary of Contents for Yunca Gas TOMMI INBUILT

  • Page 1 Electrical connections:  As the Tommi Inbuilt wood burner is required to be permanently connected to an electrical source, an isolating switch (wall switch) must be installed. ...
  • Page 2: Floor Protector

    IMPORTANT INFORMATION It is imperative that you familiarise yourself with this entire document, and also ensure you have sufficient knowledge of relevant building regulations prior to proceeding with an installation. The term “Zero Clearance”, or “ZC” is in common parlance, however it refers to reduced rather than actual nil clearances.
  • Page 3: Mantel Clearances

    Mantel shelf and mantel upright clearances have not been tested with this appliance, and should therefore be installed as per clause 3.4.1.3(b) of AS/NZS 2918:2001. Tommi Inbuilt Wood Burner Dimensions Fig. 1  Dimensions given include the factory-fitted Inbuilt “Zero Clearance” cabinet.
  • Page 4 The first internal noggin/dwang must be a TOMMI INBUILT (ZC) CAVITY minimum of 600mm above the top of the MINIMUM DIMENSIONS (mm) zero clearance box. The noggin must not be closer than 190mm to the outer flue casing. WIDTH HEIGHT...
  • Page 5 YUNCA Insert Flue Kit – Zero Clearance (Complies with AS/NZS 2918:2001): Zero Clearance Inbuilt Flue Kit consists of the following:  175mm x 1200mm stainless steel flue (3x)  175mm x 600mm stainless steel flue (1x)  225mm x 1200mm galvanised inner liner (3x) ...
  • Page 6 Typical Inbuilt (ZC) Flue Installation (Fig. 3) Complies (with heater) to AS/NZS 2918:2001 (Not drawn to scale) Fig. 3 Install-Tommi_INBUILT_ZC - 2024-08-22.docx www.yunca.co.nz Page 6 of 16...
  • Page 7: Minimum Height Of Flue System Exit

    Conditions for Flues (Fig. The FLUE shall extend to: Not less than 600mm above the highest point on the roof if within 3.0m of that point, or Not less than 1000mm above the intersection point with the roof and not lower than any point of the roof within 3.0m.
  • Page 8 Tommi Inbuilt (ZC) Installation Thermal Clearances  THERMAL CLEARANCES FRONT VIEW Fig. 5 Install-Tommi_INBUILT_ZC - 2024-08-22.docx www.yunca.co.nz Page 8 of 16...
  • Page 9  THERMAL CLEARANCES CROSS SECTION Fig. 6 Install-Tommi_INBUILT_ZC - 2024-08-22.docx www.yunca.co.nz Page 9 of 16...
  • Page 10 Attaching Flue System to ZC Box / Firebox Remove the Door and Fascia panel set as per Section Q Once the fascia is removed, unscrew the Outer Casing Top-Front Panel using a 4mm Hex Key / Allen Key (2 screws). Pull the Top-Front Panel towards you to remove it from the outer casing assembly.
  • Page 11 Reinstall the Outer Casing Top-Front Panel by sliding it into place, from front to back [a reversal of the removal procedure], while taking care to position the sides of this panel over the outside edges of the ZC Box side panels. Secure the outer casing panel in place using the 2 screws removed earlier.
  • Page 12 Main Outside Air Intake Assembly (Not to scale) Corner Parallel Item Drawing Description Arrangement Arrangement Ref. Number Parts Qty. Parts Qty. 0007400 100mm OUTER WALL VENT ASSEMBLY 0007393 100 x 600mm S/S INLET DUCT 0007338 AS 4-2 BLIND RIVET 0007399 FLEXI-DUCT (Optional) 0007405 HOSE CLAMP SS 90-110mm (Optional)
  • Page 13 Tommi Inbuilt Seismic Fixings Prior to installation, ensure the cavity floor is level both ways, smooth and bump free. Ensure the unit is securely fixed using sleeve anchors or similar at the locations shown in the images on this page.
  • Page 14 Removing the Door and Fascia Panel Set Remove the two air slide control knobs (1 each side of fascia), by firmly pulling them away from the panel set [there will be some resistance] Open the door fully. Insert one of the included metal dowels (or equivalent) under each hinge arm. Slowly close the door until the dowels take up the tension, and the door is suspended partially open.
  • Page 15 Un-screw the fascia on four locations using a 4mm Hex Key. Pull the bottom edge of the fascia out at an angle, then lift the fascia up to remove it. Put the fascia aside in a safe place where it cannot fall or be knocked, as damage Q10.
  • Page 16  Note: A thin ruler or similar can be used to help position the levers, as shown (below right) Ensure the four screw holes are all lined up correctly, and insert the screws to secure the panel set to the ZC Box. If the door hinges are not already propped open, do so as per removal instruction [Section While ensuring the dowels do not fall out of the hinges;...
