Yunca Gas XANDER INSERT Installation Instructions Manual

Wood burner
Hide thumbs Also See for XANDER INSERT:

Advertisement

Quick Links

Download this manual
• Clean Air Sub 1.0
A. Yunca recommends that competent trades persons carry out all installations (e.g.
NZHHA Registered Installer), to obtain maximum performance and safe, efficient heating.
B. A permit is required and we suggest you check with local building inspectors as by-laws
do vary from area to area.
Also notify your Insurance Company that a solid fuel heater has been installed.
C. Floor Protector –
1. Must extend as per table A as it can be reduced as the installation height is increased.
2. Must be at minimum of 860mm wide overall or 430mm from the centre of the unit.
3.
Ash Floor Protector must be constructed of non-combustible materials.
D. Seismic restraint –
Heater must be restrained from seismic movement as required by AS/NZS 2918:2001.
E. Mantel Clearances.
1. Zero Clearance installation must have a minimum of 1180mm vertically to the
nearest combustible material.
2. Masonry Install must have a minimum of 600mm vertically from the top vent to the
nearest combustible material.
F. YUNCA Insert Flue Kit – Masonry
FIG A & F
1. 4.8m x 150mm stainless steel flue.
2. 1.2m x 250mm galvanised liner.
3. 1 x top cap & cowl.
YUNCA Insert Flue Kit – Zero Clearance
FIG B & G
1. 4.8m x 150mm stainless steel flue.
2. 4.8m x 200mm galvanised liner.
3. 4.8m x 250mm galvanised liner.
4. 1 x top cap & cowl.
Please Note: All flue joints must be sealed with flue sealing compound. Use stainless
steel screws or rivets to join the flue pipe (three equally spaced places at each joint). The
first length of flue must be fixed to the flue spigot with at least one stainless steel screw
or rivet. The required minimum flue termination height is 4.6 m above the floor protector.
Install-Xander_Insert - 2016-11-29.doc
A division of Terry Young Ltd, New Zealand
INSTALLATION INSTRUCTIONS for
XANDER INSERT
WOOD BURNER
NOVEMBER 2016
TESTED in compliance with AS/NZS 2918: 2001
(Complies with AS/NZS 2918:2001 Appendix F):
• Non Clean Air (Rural)
(Complies with AS/NZS 2918:2001 Appendix F):
www.yunca.co.nz
Page 1 of 15
