Yunca Gas QEWB 2000 Installation Instructions

Complies with TO NZS 7421-1990 Appendix J Procedures and Clause A4-4 of NZS 7421-1985

Pre-Installation

Check fireplace-opening dimensions to make sure unit will fit. If opening of fireplace is greater then 800
wide and 650 high, then masonry work or fascia backing plate should be used to reduce the opening.
Sweep the chimney and remove all ash. Check the condition of brickwork to ensure the structure is
sound.
A. Manufacturer recommends all installations be carried out by competent trades persons.
e.g. (Space Heater Installer) to obtain maximum performance and maintenance free heating.
B. A permit is normally required and we suggest you check with your local building inspectors, as
by-laws can vary from area to area. Also notify your Insurance Company that a space heater has been
installed.
C. Hearth - Refer to Figure No 7 Hearth Variations
D. Mantel - As in accordance with the above listed standards, the minimum clearance for a mantel
positioning is 300mm above the fascia, Projecting 75mm maximum from the face of the concrete
surround
E. Flue Kit - Inbuilt
1. 3.6 m x 150 mm stainless steel flue
2. 1 x weather cap & cowl
F. Note: All joints must be sealed with flue sealing compound and screwed together. Also screw flue to
unit spigot.
2. Weather cowl must be screwed to flue, after trimming to correct length. Flue must not project
more than 5mm above cowl. See fig No. 1
3. IMPORTANT - Pack Kao Wool or Boiler Batt around fire outer case. Kao Wool/boiler batts are
not supplied by manufacturer.
09-06-01
A division of Terry Young Ltd.
February 2001

INSTALLATION INSTRUCTIONS

qewb_2000_inbuilt_feb.doc
