- Page 1 QUICK START GUIDE Get Smarter about Your Home Security FCC ID：2AZL7-ZS-GX1S...
-
Page 2: Warranty Service
How to Activate the Free 1-year Warranty Extension? Send us the order number and SN number via email. Please email us within 30 days of receiving the camera. Email: Support@zumimall.com Product Service Email: Tech@zumimall.com Distributor: Distributor@zumimall.com More About Us Web: www.zumimall.com Facebook: www.facebook.com/zumimalloffice... - Page 3 first-class services, it won the love and trust of millions of custom- ers as soon as it went public. Over the years, ZUMIMALL has served 45 countries, covering 80% of the population. We are the provider of smart lifestyles and a guardian of...
-
Page 4: Table Of Contents
INDEX PAGE 1. What's in the Box - X2 ------------------------------------------- P1 2. What's in the Box - X2K ----------------------------------------- P2 3. Product Diagram --------------------------------------------- P3 4. Download and Install App -------------------------------------- P4 5. Account Registration ------------------------------------------ P5 6. Add Camera to App ------------------------------------------ P5 6.1 Preparations for Connection ---------------------------------- P5... - Page 5 INDEX PAGE 13.2 Alarm Notification -----------------------------------------P15 13.3 Record/Playback/Delete ----------------------------------- P15 14. Power Saving Settings ---------------------------------------- P16 14.1 Alarm Interval -------------------------------------------- P16 14.2 Recording Time ------------------------------------------ P16 14.3 Alarm Plan ---------------------------------------------- P17 15. Battery Management ---------------------------------------- P18 16. Multi Device Management ------------------------------------ P19 16.1 Multi Camera Management -------------------------------- P19 16.2 Multi-User Sharing ---------------------------------------- P19...
- Page 6 1. What's in the Box - X2 QUICK START GUIDE Get Smarter about Your Home Security FCC ID：2AZL7-ZS-GX1S ZUMIMALL Battery Camera * 1 Outdoor Mount * 1 Quick User Guide * 1 Charging Cable * 1 Screws Set * 1 NOTE: Micro SD card and power adapter are not included.
-
Page 7: What's In The Box - X2K
2. What's in the Box - X2K QUICK START GUIDE Get Smarter about Your Home Security FCC ID：2AZL7-ZS-GX1S ZUMIMALL Battery Camera * 1 Solar Panel with Cable * 1 Quick User Guide * 1 Outdoor Mount * 1 Screws Set * 1... -
Page 8: Product Diagram
3. Product Diagram Wi-Fi Antenna Charge Port PIR Sensor DC 5V Microphone Power Key Power Light Speaker White Light Reset Key Power Reset Lens SD Card Slot Mode Indicator Power Button Keep pressing for 5-10 seconds to power on/power off Keep pressing for 5-10 seconds to reset Reset Button Blink Slowly in Red... -
Page 9: Download And Install App
NOTE: Please turn on both of the following permissions. ① Allow ZUMIMALL App to access mobile cellular data and wireless LAN, otherwise it will fail to connect the camera. ② Allow ZUMIMALL App to receive pushed messages, otherwise, the phone will not receive alarms when motion is detected. -
Page 10: Account Registration
5. Account Registration New user needs to sign up ZUMIMALL App with an email address. Click ' Sign up ' to create a New Account and follow the steps to complete registration. Step 3 Step 1 Step 2 6. Add Camera to App 6.1 Preparations for Connection... -
Page 11: Method 1: Bluetooth Setup(Recommended)
Method 1: Bluetooth Setup(RECOMMENDED) 1) On the Homepage, tap ' Add ' or ' + ' in the upper right corner, tap ' Add Device ' . 2) If the Bluetooth of cellphone doesn't turn on, the app will show a pop-up, please allow it to turn on Bluetooth. - Page 12 4) Select the 2.4GHz Wi-Fi that you want the camera to connect to and enter password. When the Bluetooth is on, the app will automatically show you the 2.4GHz Wi-Fi that could be connected. 5GHz Wi-Fi will not be shown. Normally, the Wi-Fi name and password of your 2.4GHz and 5GHz Wi-Fi are the same or similar.
-
Page 13: Method 2: Qr Code Setup
Method 2: QR Code Setup Tap 'Add Device' Select Camera Turn on the Camera Input Wi-Fi Password Prepare the Scanning Scan QR Code... - Page 14 Installation Complete at 100% Name the Camera View Installation Tips 03-26-2024 10:16:44 AM 23KB/s Perform Network Diagnosis Using the Camera...
-
Page 15: How To Reset The Camera
7. How to Reset the Camera ① Go to the device homepage, select the camera that needs to be reset, and keep pressing it to remove it from the app. ② Press the camera's reset button for 5-10s until hear the ' Boogu ' sound. ③... -
Page 16: Camera Installation
8. Camera Installation ① Fix the bracket to where you want to install the camera with the supplied screw. ② Fasten the camera on the mount, and fix them. ③ Adjust the viewing angle of the camera. NOTE: Move the lens horizontally and tilt it The camera lens supports horizontal rotation of 355°... -
Page 17: Monitoring Area
10. Monitoring Area ① It is not suggested to install the camera vertically towards the moving objects, otherwise, it may not detect the motion events or cause delay. ② It is suggested to make the angle between PIR Sensor and detected objects more than 10 degrees. -
Page 18: Device Menu
11. Device Menu 064588341 064588341 064588341 03-26-2024 12:53:01 AM 03-26-2024 12:53:01 AM 03-26-2024 13:26:05 AM 0 3 - 2 6 - 2 0 2 4 1 2: 5 6: 0 8 A M 064588341 Add Device and Scan Code Two-Way Talk More Functions Record to Phone Real Time... -
Page 19: Two-Way Audio
12. Two - Way Audio 064588341 03-26-2024 12:53:01 AM ① Open the microphone permission of ZUMIMALL APP. ② Long press the intercom button to start speaking, and the sound will be emitted from the camera at this time. ③ Release the intercom button to listen to the speech, and the sound will be emitted from the mobile phone. -
Page 20: Alarm Notification
13.2 Alarm Notification This camera does not support 7*24 hours all day recording, it is an event recording camera. It is only triggered when body motion is detected. Here are system's reactions: ① Alarm notifications with sounds from App. ② Pictures/videos automatically stored in Micro SD Card or Cloud. 13.3 Record/Playback/Delete ①... -
Page 21: Power Saving Settings
14. Power Saving Settings 14.1 Alarm Interval This is a function that avoids repeated alarms for the same event. You can choose an alarm interval of different lengths, if the interval is 5 minutes, then the camera is triggered at 08:00, you will receive an alarm message, and you will not receive a new alarm push in the next 5 minutes, even if motion detection continues to occur. -
Page 22: Alarm Plan
14.3 Alarm Plan You can set the weekly/daily alarm schedule as you need. If you set the camera's working hours from 0:00 to 1:00 .The camera will only be triggered and record alarm video during this time period. NOTE：Alarm schedule can be set for up to 4 time periods. -
Page 23: Battery Management
15. Battery Management ① The camera has a built-in high-capacity battery, which can be used for 2-3 months, assuming the camera wakes up 15 times per day and play video for 10 minutes each day. NOTE: The battery's durability depends on how frequently the camera is activated. The more it is activated, the faster the battery drains. -
Page 24: Multi Device Management
But camera can be shared form A to B. Share steps： ① B download ZUMIMALL App to his/her phone and create a new account in the App. ② Click ' Add ' in App on A's phone. ③ A scan B's QR Code or input B's account ID. - Page 25 064588341 You have two ways to share: QR code The person being shared clicks On the camera's settings Scan this QR code and enter your account number on the QR code on the 'My' page page, tap Share Or enter the account number of the Customise the permissions of the View Shared Records Accepting sharing...
- Page 26 If you have other questions, please send us the SN number of your camera and describe the problem you have encountered, we will solve it as soon as possible. Email: Tech@zumimall.com How to find SN number? 064588341 064588341 03-26-2024 12:53:01 AM...
