applicable to serial numbers prior to, and including
1
2
Crossover Dish
5
6
7
HF Driver shown with mounting plate
11
12
Front view of Y112M with grill taken off
*NOTE: Replacement grills & HF Driver supports are 'Special-Order' and are only available while the model is in production.
Parts-Serv-y112m-1v3.xls
104xxxx
4
8
10
diaphram not shown
13
ftp.yorkville.com
#
Part#
Description
Labeled Components
1
8511
BLK X-OVER DISH - PLASTIC
2
3924
1/4" JCK PCB MT VERT 2XTIP HI-CURRENT
3
3647
12V 18W SC BAYONET #1141
3
4
3641
S.C. BAYONET WIRE SOCKET TINNED
5
8879
M5 X 10 DIN 7985 MS ZINC SCREW
6
8886
NEOPRENE N252 DRIVER GASKET
7
M694
GENERIC DRIVER SUPPORT*
8
N252PP
N252 REPLACEMENT PHASE PLUG
9
N252XN
8R 30W 1"DRIVER RCF-N252XN
10
M-73
N252 REPLACEMENT DIAPHRAM
11
Z243
Y112M GRILL*
12
8239
"Y" LOGO "Y" SERIES LARGED DOMED
13
7317
12" 8R 150WPGM SPEAKER
14
H07
HORN 60 X 40 1" STY 2000HZ
15
8569
CORNER, 2 LEGS NO LIP BLACK OXIDE
16
8562
CORNER, 3 LEGS, BLACK OXIDE
17
8484
ADAPTOR,SPEAKER STAND,PLASTIC,BLACK
18
8458
10.5" STRAP HANDLE, PLASTIC COVERS
19
8547
PLASTIC FOOT BLACK
9
14
Bottom and side view
BULB
15
17
16
Speaker Enclosure
18
19
