SERVICE MANUAL
MICRO COMPONENT SYSTEM
STANDBY/ON
DISPLAY
SLEEP
AUX
PROG
RANDOM
REPEAT
SOUND
AUTO
FM/AM
MODE
PRESET
FM MODE
CD
TAPE
CD
CANCEL
MULTI KEY
SET
AHB
PRO
VOLUME
RM-SUXP3U REMOTE CONTROL
Contents
Safety precautions
Preventing static electricity
Important for laser products
Disassembly method
Main adjustment
Flow of functional operation
until TOC read (CD)
UX-P3
COMPACT
DIGITAL AUDIO
STANDBY
M I C R O
C O M P O N E N T
S Y S T E M
STANDBY
/
ON
AHB PRO
CD
TAPE
FM/AM
/
DIRECT OPERATING
FUNCTION
SOUND
A U T O R E V E R S E
AUTO TAPE SELECTOR
PHONES
SP-UXP3
CA-UXP3
1-2
1-4
1-6
1-7
1-14
1-18
COPYRIGHT
2001 VICTOR COMPANY OF JAPAN, LTD.
C D - R / R W P L A Y B A C K
U X · P 3
CLOCK
AUX
VOLUME
TIMER
REV .MODE
REC
SP-UXP3
UB
UP
US
UW
UY
Maintenance of laser pickup
Replacement of laser pickup
Description of major ICs
Internal connection of display
UX-P3
UX-P3
Area Suffix
Hong Kong
Korea
Singapore
South Africa
Argentina
1-19
1-19
1-20
1-39
No.20984
1-1
Jun. 2001

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UX-P3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for JVC UX-P3

Summary of Contents for JVC UX-P3

  • Page 1 UX-P3 UX-P3 SERVICE MANUAL MICRO COMPONENT SYSTEM UX-P3 COMPACT DIGITAL AUDIO C D - R / R W P L A Y B A C K STANDBY M I C R O C O M P O N E N T S Y S T E M U X ·...
  • Page 2 UX-P3 1. This design of this product contains special hardware and many circuits and components specially for safety purposes. For continued protection, no changes should be made to the original design unless authorized in writing by the manufacturer. Replacement parts must be identical to those used in the original circuits. Services should be performed by qualified personnel only.
  • Page 3 UX-P3 (U.K only) 1. This design of this product contains special hardware and many circuits and components specially for safety purposes. For continued protection, no changes should be made to the original design unless authorized in writing by the manufacturer.

  • Page 4: Preventing Static Electricity

    UX-P3 Preventing static electricity Electrostatic discharge (ESD), which occurs when static electricity stored in the body, fabric, etc. is discharged, can destroy the laser diode in the traverse unit (optical pickup). Take care to prevent this when performing repairs. 1.1. Grounding to prevent damage by static electricity Static electricity in the work area can destroy the optical pickup (laser diode) in devices such as DVD players.

  • Page 5: Cd Servo Board

    UX-P3 1.3. Cautions on removing the CD traverse unit * For removing the CD traverse unit in detail, refer to the "Adjustment Method" section of this manual. 1. Before disconnecting the flexible wire from the connector CN601 on the CD SERVO board, solder the part shown in the figure below.

  • Page 6: Important For Laser Products

    UX-P3 Important for laser products 5.CAUTION : If safety switches malfunction, the laser is able 1.CLASS 1 LASER PRODUCT to function. 2.DANGER : Invisible laser radiation when open and inter 6.CAUTION : Use of controls, adjustments or performance of lock failed or defeated. Avoid direct exposure to beam.

  • Page 7: Disassembly Method

    UX-P3 Disassembly method Metal cover <Main body> Removing the metal cover (See Fig.1 and 2) Remove the six screws A on the back of the body. Remove the two screws B on the side of the body. Pull both sides of the metal cover outward and lift the rear part of the cover.
  • Page 8 UX-P3 Removing the tuner board (See Fig.4 and 5) Tuner board Prior to performing the following procedure, remove the metal cover. Disconnect the card wire from connector CN1 on the tuner board. Remove the screw D on the right side of the body.
  • Page 9 UX-P3 Remove the rear panel (See Fig.8 to 11) Joint a Joint a Prior to performing the following procedure, remove the metal cover, rear cover and the CD mechanism assembly. Remove the five screws G attaching the rear panel. Disconnect the card wire from CN902 on the main board.
  • Page 10 UX-P3 CN931 Removing the main board / heat sink CN901 (See Fig.13 to 15) CN900 Prior to performing the following procedure, remove Main board the metal cover, the rear cover, the CD mechanism assembly and the rear panel. Disconnect the card wire from connector CN900, CN901 and CN931 on the main board.
  • Page 11 UX-P3 Removing power transformer J1000 assembly (See Fig.16 and 17) Prior to performing the following procedure, remove the metal cover, the rear cover, the CD mechanism assembly and the rear panel. Remove the cord stopper upwards on the back of the body.
  • Page 12 UX-P3 Front panel assembly Removing the display board / switch board (See Fig.20 to 22) Prior to performing the following procedure, remove the front panel assembly. VOLUME knob Pull out the VOLUME knob on the front panel. Remove the fifteen screws M attaching the display board and the switch board on the back ofthe front panel.
  • Page 13 UX-P3 Removing the headphone board (See Fig.23) Display board Prior to performing the following procedure, remove the front panel assembly. Remove the screw O on the back of the front panel. Band If necessary, remove the band bundling the wire extending from the headphone board and the display board.

  • Page 14: Main Adjustment

    UX-P3 Main adjustment Tuner section Measurement Instruments Required for Adjustment B/E/EN version 1. Low frequency oscillator FM Band cover: 87.5 108MHz This oscillator should have a capacity to output MW Band cover: 522 1,629kHz 0dBs to 600 at an oscillation frequency of...
  • Page 15 UX-P3 << >> Arrangement of Adjusting Position Cassette mechanism section Cassette mechanism section (Back side) Head azimuth Head azimuth adjusting screw adjusting screw (Forward side) (Reverse side) Head azimuth Head azimuth Playback/Recording & adjusting screw adjusting screw eraser head (Forward side)
  • Page 16 UX-P3 Tape Recorder Section Measurement Adjusting Standard Items Measurement method conditions positions Values Adjust the head Confirmation Test tape 1 Playback the test tape VTT703L (8kHz) Maximum azimuth screw of head angle : VTT703L (8kHz) 2 With the recording & playback mechanism,...
  • Page 17 UX-P3 Electrical Performance Adjusting Measurement Standard Items Measurement method positions conditions Values VR31 AC-225 Adjustment of Mode: Forward or 1 With the recording and playback : 4.20 recording bias reverse mode mechanism, load the test tapes (AC-514 to AC-514 current...

  • Page 18: Flow Of Functional Operation Until Toc Read (Cd)

    UX-P3 Flow of functional operation until TOC read (CD) Check Point Slider turns REST Power Key Power ON Check that the voltage at the pin4 SW ON. of CN601 is 0V (a moment)? Automatic tuning of TE offset Check that the voltage at the...

  • Page 19: Maintenance Of Laser Pickup

    UX-P3 Maintenance of laser pickup Replacement of laser pickup (1) Cleaning the pick up lens Befor you replace the pick up, please try to Turn off the power switch and,disconnect the clean the lens with a alcohol soaked cotton power cord from the ac outlet.

  • Page 20: Description Of Major Ics

    UX-P3 Description of major ICs UPD780058 (IC931 ) : Main micon 1. Pin layout 80 ~ 25 ~ 2. Pin function Port Name Function Function SAFETY0 Irregular voltage detection 0 P15/AN15 Safety DOOR_RST REST/CLOSE switch detect port P16/AN16 Door P17/AN17...
  • Page 21 UX-P3 Port Name Function Function LEDRV P64/RD Lite LED indicate Reverse LED_REC Lite LED indicate REC P65/WR LEDFR Lite LED indicate Forward P66/WAIT P67/ASTB STTA Tape IC Strobe Tape LCDAT LCD data P30/TO0 LMODE P31/TO1 LCD date mode control LCDCK...
  • Page 22 UX-P3 LA6541 (IC801) : Foucus & Spindle & Feed & Tracking BTL driver 1. Pin Layout & block diagram Vref Vin4 Vin3 Level B T L B T L Level RESET shift driver driver shift Level B T L B T L...
  • Page 23 UX-P3 MN662748RPM (IC651) : Digital servo & digital signal processer 1. Pin layout 20 ~ 41 ~ 2.Block diagram AVSS1 LRCKIN(MSEL) 8TIMES AVDD1 BCLK(SSEL) DIGITAL OVER SAMPUNC OUTR SRDATAIN DEEMPHSIS 1BIT DIGITAL FILTER (PSEL) LOGIC IOSEL CLVS BLKCK OUTL CLDCK...
  • Page 24 UX-P3 3. Pin function Symbol I/O Function Symbol I/O Function Not used Tracking error shunt signal output (H:shunt) BCLK Not used LRCK PLAY Not used SRDATA WVEL Not used Not used DVDD1 Power supply (Digital) RF signal input DVSS1 Connected to GND...
  • Page 25 UX-P3 BA15218F-XE (IC904) : Dual operation amplifier 1. Pin layout OUT1 1 8 Vcc -IN1 2 7 OUT2 +IN1 3 6 -IN2 VEE 4 5 +IN2 2. Block diagram OTHER Q114 OUTPUT 1-25...
  • Page 26 UX-P3 KIA78S06P-T (IC933) : Regulator 1. Pin layout 2. Block diagram 3 INPUT 1 2 3 1 OUTPUT 2 COMMON 1-26...
  • Page 27 UX-P3 LA4628 (IC905) : Power amp 1. Pin layout 10 11 12 13 14 2.Block diagram -OUT GND1 +OUT -OUT GND2 +OUT 1-27...
  • Page 28 UX-P3 AN22000A(IC601):RF & SERVO AMP 1. Pin layout 2. Block RF IN OFTR RF OUT C.AGC CBDO COFTR OFTR RF_EQ 3TENV NRFDET 3TOUT NRFDET SUBT FEOUT SUBT TEOUT TEBPF VDET VDET VREF GCTL TBAL FBAL CDDG VCC 3. Function Symbol...
  • Page 29 UX-P3 LA1838 (IC1): FM AM IF AMP&detector, FM MPX decoder 1. Block Diagram DECODER RF.AMP ANIT-BIRDIE MUTE BUFF STEREO P-DET AM IF PILOT 384KHz COMP S-METER AM/FM S-CLRVE S-METER IF-BUFF TUNING STEREO DRIVE DRIVE FM IF 2. Pin Function Symbol...
  • Page 30 UX-P3 LC72136N (IC2) : PLL frequency synthesizer 1. Pin layout FM/AM LPFOUT LPFIN CLOCK FM/ST/VCO FMIN AM/FM AMIN IFCONT SDIN IFIN 2. Block diagram Phase Reference Detector Driver Charge Pump Swallow Counter Swallow Counter 1/16,1/17 4bit 1/16,1/17 4bit Unlock Detector...
  • Page 31 UX-P3 LC72723(IC3):RDS Pin Assignment Block diagram VREF FLOUT CIN Vdda CLOCK Vddd RECOVERY REFERENCE (57kHz) (1187.5kHz) VOLTAGE Vssa VREF Vssd 57kHz ANTIALIASING DATA SMOOTHING RDDA MPXIN (SCF) FILTER FILTER DECODER RDCL MDDE (128-bits) CLK(4.332MHz) RDS-ID RDS-ID/ TEST TEST DETECT READY XDUT 3.
  • Page 32 UX-P3 LB1641 (IC802) : DC Motor driver 1. Pin layout GND OUT1 P1 IN2 VCC1 VCC2 P2 OUT2 2. Pin function Input Output Mode OUT1 OUT2 Brake CLOCKWISE COUNTER-CLOCKWISE Brake BU4094BC(IC33):Serial to parallel port extension 1.Pin layout 2.Block diagram STROBE...
  • Page 33 UX-P3 BA3126N(IC31) : R/P Switch GP1U26X (IC933) 1-33...
  • Page 34 UX-P3 NJU6433FG1 (IC934) 1. Pin layout 2. Bock diagram Common Latch Circuit/Segment Driver Driver Divider Input Input Input Input Shift Register 4 Shift Register 3 Shift Register 2 Circuit Shift Register 1 Switching Switching Switching Switching Circuit Circuit Circuit Circuit...
  • Page 35 UX-P3 LC75345M (IC901) 1. Pin layout 2. Block Diagram 1-35...
  • Page 36 UX-P3 3. Descriptions Pin name Pin No. Descriptions Input signal pin LSEL0 Input selector output pin. RSEL0 LBASS1 LBASS2 RBASS1 Capacitor and resistor connection pins comprising filters for RBASS2 bass and super-bass band. ATT + equalizer output pin/capacitor connection pin...
  • Page 37 UX-P3 Pin name Pin No. Descriptions VDD voltage generation block for analog ground. Vref Capacitor of several 10 F to be connected between Vref and AWSS (VSS) as a counter-measure against power ripple. Ground pin Supply pin Chip enable pin.
  • Page 38 UX-P3 AN7317 (IC32) : PB/REC amp 1-38...

  • Page 39: Internal Connection Of Display

    UX-P3 Internal connection of display QLD0160-001 (D1934) 1-39...
  • Page 40 UX-P3 <<MEMO>> 1-40...
  • Page 41 UX-P3 UX-P3 VICTOR COMPANY OF JAPAN, LIMITED AUDIO & COMMUNICATION BUSINESS DIVISION PERSONAL & MOBILE NETWORK BUSINESS UNIT 10-1,1Chome,Ohwatari-machi,Maebashi-city,371-8543,Japan 1-41 No.20984 200106(O)
  • Page 42 UX-P3 Block diagram...

  • Page 43: Standard Schematic Diagrams

    UX-P3 UX-P3 Standard schematic diagrams Front circuit CN904 CN903 QGF1205F1-16 QGF1205F1-13 REST/OP_SW/CL_SW DI934 QLD0160-001 Q7031 2SC2412K/R/-X 0.001 C7123 RECR RECL R7218 R7217 JS731 QSW0917-001 TAPE1 R7215 TAPE0 R7065 R7064 R7214 SEG32 SEG31 R7117 2.2K DTC114EKA-X 2.2K R7159 LEDREC CLOSE R7341...
  • Page 44 UX-P3 Main circuit CN907 CN907 QGD2504C1-04Z QGD2504C1-04Z C2119 C2119 0.27 0.27 LA4628 LA4628 22/16 22/16 C2117 C2117 C2215 C2215 IC905 IC905 220K 220K R2147 R2147 L2200 L2200 QQR0797-001 QQR0797-001 0.012 0.012 C2126 C2126 C2133 C2133 10/35 10/35 IC901 IC901 R2125 R2125 0.0033...
  • Page 45 UX-P3 UX-P3 CD servo circuit W605 QJP001-03201 R601 220K TBAL R602 270K FBAL GCTRL R604 180K C606 R643 C604 0.022 CN651 QGF1201F1-16 C641 C603 STAT C601 390K 0.001 R642 VDET SQCK C602 0.001 LDON SUBQ C653 MCLK 0.1/16 150P 150P...
  • Page 46 UX-P3 Cassette amplifier circuit 1SR139-400-T2 SG-105F3-BB,C Q201 C211 R212 DTC114TKA 2.2K 0.0015 C208 R208 R211 C204 R203 R202 5.6K 4.7/25 0.033 2.4K 1.8K R204 1.2K MSI-5U2LWA QGB2011L1-10 Q203 DTC114TKA IC31 BA3126N R304 FW31 CN32 QGB2011M1-10 VWS304-06A13K R301 IC32 AN7317 QAH0047-001...
  • Page 47 UX-P3 UX-P3 Tuner circuit 0.0039 0.47/50 0.0022 470P 0.047 22/16 0.27 1/50 0.047 22/16 0.001 10/16 10/16 100/10 1000P R8( D2) *C43 *C42 3.3K VCF2L3B-105Z LC72136N 1SS133-T2 LA1838 1SS133-T2 QNB0014-001 VCF2L3B-105Z 5.6K DTA114YKA-X 150P QQR0793-001 150P 150P 1/50 1.2K 0.022 QQR0796-002 0.047...
  • Page 48 UX-P3 Power supply circuit A.GND A.GND A.GND T1000 T1000 T1000 QQT0284-003 QQT0284-003 QQT0284-002 J1000 J1000 J1000 QGA7901C1-2 QGA7901C1-2 QGA7901C1-2 L1000 L1000 L1000 QQR1145-001 QQR1145-001 QQR1145-001 A.GND T1000 QQT0284-003 S1000 QSW0812-001 J1000 QGA7901C1-2 L1000 QQR1145-001 Parts are safety assurance parts. When replacing those parts make sure to use the specified one.

  • Page 49: Printed Circuit Boards

    UX-P3 UX-P3 Printed circuit boards Main board Block No. 01 Q7003 SW9V SW9V R7232 CLOSE C7010 R7160 D7007 OPEN R7159 OP-SW CN931 CL-SW R7078 R7236 CD+B CD+B R7077 K7003 R7076 D7004 R7010 D7005 R7202 C7123 R2034 R2134 R7123 Q2215 Q2216...
  • Page 50 UX-P3 Front board Block No. 02 CD servo board Block No. 03 R710 R708 B618 D831 IC802 C669 C679 C832 CN606 R709 C833 D601 IC652 CLSW B604 C694 OPSW R707 R667 R684 M.GND R681 SW10 SW10 A.GND CLOSE OPEN OPSW...
  • Page 51 UX-P3 UX-P3 Tuner board Block No. 04 Head amplifier board Block No. 05 B102 R371 C376 Q375 CN32 R375 CN34 B152 D375 Q376 C307 Q371 Q372 R372 R373 C375 R205 R112 B198 C113 R111 R105 C213 R110 R212 C105 R210...

  • Page 52: Table Of Contents

    UX-P3 PARTS LIST [ UX-P3 ] * All printed circuit boards and its assemblies are not available as service parts. Area suffix UB -------------------- Hong Kong UP --------------------------- Korea US --------------------- Singapore UY ---------------------- Argentina UW --------- Brazil,Mexico,Peru - Contents -...
  • Page 53 UX-P3 < M E M O >...

  • Page 54: Exploded View Of General Assembly And Parts List

    UX-P3 Exploded view of general assembly and parts list Block No. Main board Tuner board board CD servo board board Front board Power suplly board...
  • Page 55 UX-P3 Parts list (General assembly) Parts list (General assembly) Block No. M1MM Block No. M1MM Item Parts number Parts name Q'ty Description Area Item Parts number Parts name Q'ty Description Area GV10064-002A FRONT PANEL QYSBSF3008Z SCREW CLAMP.BASE/LOAD GV40077-002A JVC BADGE...
  • Page 56 UX-P3 Parts list (General assembly) Block No. M1MM Item Parts number Parts name Q'ty Description Area US,UW,UY,UP QQT0284-003 POWER TRANSF T1000 QQT0284-002 POWER TRANSF T1000 GV40121-003A SPACER GV40167-001A H.SINL BRACKET QYSBSF3012Z SCREW H.SINK/H.SINK BKT QYSBSGY3008E SPECIAL SCREW R.PANEL/H.SINK QYSBSF3012E SPECIAL SCREW VOL.SEL./R.PANEL...

  • Page 57: Cassette Mechanism Assembly And Parts List

    UX-P3 Cassette mechanism assembly and parts list Block No. SLC-S21M Grease = EM-30L =UD-24 =UD-24H2 =LEN-320M =JC-888B =MOBIL-1 The lower side Switch board Head amplifier board...
  • Page 58 UX-P3 (Cassette mechanism) Parts list Block No. M2MM Item Parts number Parts name Q'ty Description Area VKS1165-00J CHASSIS B.ASS'Y VKS2274-002 REEL GEAR VKW5286-002 B.T. SPRING VKS5559-001 PLAY IDLE GEAR VKS5597-00B BLIND VKW5296-001 EARTH SPRING SLC-RP1SVM HEAD MOUNT ASSY VKY3149-002 CASSETTE SP.

  • Page 59: Cd Loading Base Assembly And Parts List

    UX-P3 CD loading base assembly and parts list Block No. Grease = G-474C = EBS0006-009B FIG A Apply grease to groove and support convex. FIG A Dimension gap for motor pulley...
  • Page 60 UX-P3 Parts list (CD loading baes) Block No. M3MM Item Parts number Parts name Q'ty Description Area VYH1238-001 LODING BASE MMN-6F1LB8K MOTOR QGF1201F3-05 CONNECTOR CN505 QSW0472-001 SWITCH S851 QYSPSPT2640Z MINI SCREW E75984-221 MOTOR PULLEY E75950-002 BELT E75985-221 GEAR(1) E75986-221 GEAR(2)

  • Page 61: Cd Mechanism Assembly And Parts List

    UX-P3 CD mechanism assembly and parts list Block No. Grease & Bond = EBS0006-013B = 1401B Turn table hight EXL-M7MB (CD mechanism) Parts list Block No. M4MM Item Parts number Parts name Q'ty Description Area E102731-221SM CD MECHA BASE A...
  • Page 62 UX-P3 Electrical parts list (Main board) Block No. 01 Item Remarks Item Remarks Parts number Parts name Area Parts number Parts name Area CN900 QGF1205C1-10 CONNECTOR C2212 EETC1HM-105ZJC E CAPACITOR CN901 QGF1205C1-09 CONNECTOR C2213 EETC1CM-106ZJC E CAPACITOR CN902 QGF1205F1-09 CONNECTOR...
  • Page 63 UX-P3 Electrical parts list Block No. 01 (Main board) Item Remarks Item Remarks Parts number Parts name Area Parts number Parts name Area D7001 1SS133-T2 SI DIODE US5V R2015 QRE141J-473Y C RESISTOR 47K 5% 1/4W D7002 1SS133-T2 SI DIODE R2016...

  • Page 64: Electrical Parts List

    UX-P3 Electrical parts list (Main board) Block No. 01 Item Remarks Item Remarks Parts number Parts name Area Parts number Parts name Area R7001 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W R7152 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W R7002 QRE141J-103Y C RESISTOR...
  • Page 65 UX-P3 Electrical parts list (Front board) Block No. 02 Item Remarks Item Remarks Parts number Parts name Area Parts number Parts name Area CN932 QGF1205F1-17 CONNECTOR R7321 QRE141J-391Y C RESISTOR 390 5% 1/4W C1000 QFLM1HJ-104Z M CAPACITOR .10MF 5% 50V...
  • Page 66 UX-P3 Electrical parts list (CD servo board) Block No. 03 Item Remarks Item Remarks Parts number Parts name Area Parts number Parts name Area C 601 NCB31HK-102X C CAPACITOR CN606 QGF1205F1-05 CONNECTOR C 602 NCB31HK-102X C CAPACITOR CN651 QGF1205F1-16 CONNECTOR...
  • Page 67 UX-P3 (CD servo board) Electrical parts list Block No. 03 Item Remarks Parts number Parts name Area R 802 NRSA63J-392X MG RESISTOR R 803 NRSA63J-222X MG RESISTOR R 804 NRSA63J-224X MG RESISTOR R 805 NRSA63J-133X MG RESISTOR R 806 NRSA63J-243X...
  • Page 68 UX-P3 Electrical parts list (Tuner board) Block No. 04 Item Remarks Item Remarks Parts number Parts name Area Parts number Parts name Area NCB21HK-223X C CAPACITOR IC 2 LC72136N NCB21HK-103X C CAPACITOR QNB0014-001 ANT TERMINAL EETC1CM-106ZJC E CAPACITOR QQR0796-002 COIL BLOCK...
  • Page 69 UX-P3 Electrical parts list (Head amplifier board) Block No. 05 Item Remarks Item Remarks Parts number Parts name Area Parts number Parts name Area C 101 NCS21HJ-821X C CAPACITOR Q 371 2SA952/LK/-T TRANSISTOR MOTER+B C 102 NCS21HJ-221X C CAPACITOR Q 372...
  • Page 70 UX-P3 Electrical parts list (Cassette switch board) Block No. 06 Item Remarks Parts number Parts name Area CN 1 QGB2011L1-10 B TO B CONNECTO 1SR139-400-T2 SI DIODE IC 1 SG-105F3-BB,C PHOTO SENSER QNZ0104-001 POST PIN SW 1 QSW0832-001 LEAF SWITCH R.REC...

  • Page 71: Packing Materials And Accessories Parts List

    UX-P3 Packing materials and accessories parts list Block No. Block No. A1~A7 3-20...

  • Page 72: Parts List

    UX-P3 Parts list (Packing) Block No. M5MM Item Parts number Parts name Q'ty Description Area QPC02503515P POLY BAG FOR INST GV20111-001A CARTON ASSY GV10070-001A CUSHION UPPER TOP / REAR GV10075-001A CUSHION BOTTOM TOP / REAR QPC05006515P POLY BAG 139763681053 TOP CUSHION...
