- Page 1 RENOGY Portable Solar Panel Blanket 200W/400W RPP200SB-SE-G1 VERSION A0 RSP400SB-G3 April 1, 2025 USER MANUAL...
-
Page 2: Before Getting Started
Renogy is not responsible or liable for any failure, damage, or injury resulting from repair attempts by unqualified personnel, improper installation, or inappropriate operation. -
Page 3: Table Of Contents
How to Adjust the Shoulder Strap Length? .................... 2 Backpack-Style Carry ..........................3 Folding/Unfolding ..........................3 Renogy 200W Portable Solar Panel Blanket (RPP200SB-SE-G1) ............3 Renogy 400W Portable Solar Panel Blanket (RSP400SB-G3) ............4 How to Properly Hang and Secure Your Solar Panel Blanket? ............. 5 Renogy 200W Portable Solar Panel Blanket (RPP200SB-SE-G1) ............ -
Page 4: General Safety Information
Improper installation, improper operation, and malfunction of a peripheral device. z Contamination with hazardous substances or radiation. z Alterations to the solar panel blanket without express written consent from Renogy. The installation and service of the solar panel blanket must be carried out by qualified personnel. -
Page 5: Introduction
MC4 output ports and USB output interfaces (applicable to RPP200SB-SE-G1 only), ensuring reliable charging during outdoor adventures. Its foldable design allows for easy storage, making it an ideal choice for SUV, pickup, and 4x4 truck camper users with limited space who cannot accommodate high-power portable solar panels. -
Page 6: Backpack-Style Carry
You can then wear the bag like a backpack and start your journey. Folding/Unfolding Follow the steps below to unfold your solar panel blanket. To fold it, simply reverse the steps. Renogy 200W Portable Solar Panel Blanket (RPP200SB-SE-G1) — 3 —... -
Page 7: Renogy 400W Portable Solar Panel Blanket (Rsp400Sb-G3)
Renogy 400W Portable Solar Panel Blanket (RSP400SB-G3) — 4 —... -
Page 8: How To Properly Hang And Secure Your Solar Panel Blanket
When hanging your solar panel blanket, always use all the loops on one side to ensure even weight distribution and avoid damage caused by excessive stress on a single loop. Renogy 200W Portable Solar Panel Blanket (RPP200SB-SE-G1) Renogy 400W Portable Solar Panel Blanket (RSP400SB-G3) -
Page 9: Charging
Battery *Both the battery ANL fuse and solar panel fuse are available on renogy.com. For fuse sizing details, refer to Size Fuses or Circuit Breakers for a Solar Power System at Renogy Learning Center. For scenarios involving solar panel blankets connected in series or parallel, refer to “Series/ Parallel Connection“... -
Page 10: How To Charge Usb Devices? (Rpp200Sb-Se-G1 Only)
How to Charge USB Devices? (RPP200SB-SE-G1 Only) USB charging is applicable to 200W Portable Solar Panel Blanket (RPP200SB-SE-G1) models only. The RPP200SB-SE solar panel blanket provides three USB ports as below: z USB C (PD3.0): 5V/3A , 9V/3A, 12V/3A, or 15V/3A, 45W Max z *USB A1 (QC): 5V/3A, 9V/2A, or 12V/1.5A, 18W Max... -
Page 11: Series/Parallel Connection
Series/Parallel Connection To expand the power output, connect multiple Renogy 200W/400W Portable Solar Panel Blankets either in series or parallel. When connecting solar panel blankets in series or parallel, the following conditions must be satisfied: All solar panel blankets should have been purchased around the same time. -
Page 12: Parallel Connection
The illustration in this section is based on a scenario involving two solar panel blankets with a pair of Renogy Solar Y Branch Connectors. Solar... -
Page 13: Specifications
Specifications Model RPP200SB-SE-G1 RSP400SB-G3 Max Power at STC 200W 400W Optimum Operating Voltage 16.8V 33.60V Optimum Operating 11.9A 11.9A Current Open-Circuit Voltage 19.6V 39.2V Short-Circuit Current 13.1 A 13.1 A Cell Type Monocrystalline Silicon Monocrystalline Silicon Connector MC4 & USB... -
Page 14: Renogy Support
Questionnaire Investigation To explore more possibilities of solar systems, visit Renogy Learning Center at: renogy.com/learning-center For technical questions about your product in the U.S., contact the Renogy technical support team through: renogy.com/contact-us 1(909)2877111 For technical support outside the U.S., visit the local website below: Canada ca.renogy.com... -
Page 15: Fcc Statement
FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. - Page 16 Renogy Power PLUS Renogy Power Plus allows you to stay in the loop with upcoming solar energy innovations, share your experiences with your solar energy journey, and connect with like-minded people who are changing the world in the Renogy Power Plus community.
