- Page 1 SOLAR SUITCASE 100W Version 2.0...
- Page 2 Important Safety Instructions Please save these instructions. This manual contains important safety, installation, and operating instructions for the charge controller. The following symbols are used throughout the manual to indicate potentially dangerous conditions or important safety information. Indicates a potentially dangerous condition. Use extreme caution when WARNING performing this task Indicates a procedure or function that is important to the safe and...
-
Page 3: Table Of Contents
Table of Contents General Information Identification of Parts Installation Recommended Wiring Frequently Asked Questions Technical Specifications Solar Panel Parameters Dimensions... -
Page 4: General Information
General Information The Renogy Solar Suitcases combines 2 highly efficient 50W monocrystalline solar panels. This system is specifically designed for mobile off-grid applications, where space and weight limitations are abundant. The Solar Suitcase models support 12V deep cycle battery varieties such as sealed, lead acid, gel, and flooded. -
Page 5: Identification Of Parts
Identification of Parts ① ① ⑤ ③ ② ② ④ ③ Key Parts 1. Junction Boxes 2. Tilt Stands 3. Latches 4. Handle 5. MC4 Connections Installation 1. Unlatch and unfold unit... - Page 6 2. Unscrew butterfly nut tilt to desired angle and lock butterfly nut To maximize the output, adjust the angle of the suitcase regularly to track the sun’s movement throughout the season – 15° Summer Fall and Spring + 15° Winter...
-
Page 7: Recommended Wiring
Recommended Wiring The 100W Solar Suitcase is shipped by itself without any additional components. In order to utilize the suitcase efficiently, it is highly recommended that users put their system together with the following components: 1. Adapter kit—has an MC4 connection on one end and bare wire on the other end for connecting to a charge controller. - Page 8 2. Connect adapter kit to MC4 connections coming from the suitcase’s junction box 3. Connect adapter kit to charge controller PV terminals...
-
Page 9: Frequently Asked Questions
Frequently Asked Questions Q. What type of batteries can be used with this kit? A. Battery type compatibility depends on the charge controller specified compatible battery types. Follow charge controller manufacturer's specifications and guidelines for supported battery chemistries. Deep cycle battery types include sealed lead acid, gel, flooded, LFP 12V batteries (typically used in caravans, motorhomes, boats, etc.). -
Page 10: Technical Specifications
Technical Specifications Solar Panel Parameters Description 100W Parameters Maximum Power 100 W Open Circuit Voltage (Voc) 24.3 V Short Circuit Current (Isc) 2 x 2.73 A Maximum Power Voltage (Vmp) 20.3 V Maximum Power Current (Imp) 2 x 2.47 A Cell Type Monocrystalline Operating Temperature... -
Page 11: Dimensions
Dimensions 100W Suitcase 1334 mm [52.5 in] 71 mm 1260 mm [49.6 in] [2.8 in] 630 mm [24.8 in] 509mm [20 in] 27mm [1.1in]... - Page 12 RENOGY.COM Renogy reserves the right to change the contents of this manual without notice. 2775 E Philadelphia St, Ontario, CA 91761, USA 909-287-7111 www.renogy.com customerservice@renogy.com 苏州高新区科技城培源路1号5号楼-4 400-6636-695 https://www.renogy.cn sales@renogy.cn https://www.renogy.jp onlinestorejp@renogy.com https://ca.renogy.com onlinestoreca@renogy.com https://au.renogy.com onlinestoreau@renogy.com https://uk.renogy.com onlinestoreuk@renogy.com https://de.renogy.com onlinestorede@renogy.com https://fr.renogy.com...
