Monocrystalline Foldable
Solar Suitcase with Voyager
100W/200W 20A
VERSION A0
RNG-KIT-STCS100D-VOY20/RNG-KIT-STCS200D-VOY20
September 6, 2024
USER MANUAL

Advertisement

loading
Need help?

Need help?

Do you have a question about the RNG-KIT-STCS100D-VOY20 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Renogy RNG-KIT-STCS100D-VOY20

  • Page 1 RENOGY Monocrystalline Foldable Solar Suitcase with Voyager 100W/200W 20A VERSION A0 RNG-KIT-STCS100D-VOY20/RNG-KIT-STCS200D-VOY20 September 6, 2024 USER MANUAL...
  • Page 2 Renogy is not responsible or liable for any failure, damage, or injury resulting from repair attempts by unqualified personnel, improper installation, or inappropriate operation.
  • Page 3 Introduction ............................1 Key Features ............................1 SKU ..............................1 What’s In the Box?..........................2 Get to Know Renogy Solar Suitcase with Voyager ................ 2 Dimensions ............................3 System Setup ............................4 Step 1. Unfold and Install the Solar Panels ..................4 Step 2.
  • Page 4 Adjustable Stand: Corrosion-resistant aluminum stand for maximum solar light capture. z Easy Setup: Includes alligator clips for simple connection of the Voyager charge controller to your battery, ideal for mobile systems seeking flexibility. RENOGY 100W Solar Suitcase with 20A Voyager RNG-KIT-STCS100D-VOY20 RENOGY 200W Solar Suitcase with 20A Voyager RNG-KIT-STCS200D-VOY20 —...
  • Page 5 The accessories and product manual listed are crucial for the installation, excluding warranty information and any additional items. Please note that the package contents may vary depending on the specific product model. Get to Know Renogy Solar Suitcase with Voyager 20A Voyager Waterproof Junction Box...
  • Page 6 Dimensions Dimension tolerance: ±0.2 in (0.5 mm) █ RENOGY 100W Solar Suitcase with 20A Voyager 41.8 in (1062 mm) 1.4 in (35 mm) 20.9 in (530 mm)
  • Page 7 Expansion”. A solar connector fuse is required to protect your solar suitcase from overcurrent. You can purchase a proper solar connector fuse at www.renogy.com. Step 1. Unfold and Install the Solar Panels To ensure safe, efficient system operation, always follow the installation instructions in the order depicted in the manual.
  • Page 8 For detailed instructions on how to determine the angle and orientation of solar panels, visit How to Find the Best Orientation and Angle of Solar Panels? Renogy Learning Center. Summer = Latitude - 15° Fall and Spring...
  • Page 9 Connector Fuse 12V Battery You can purchase a proper solar connector fuse at renogy.com. Step 4. Install a Battery Temperature Sensor (Optional) You can install a battery temperature sensor on the Voyager charge controller. The temperature sensor measures the surrounding temperature of the battery and compensates the floating charge voltage when the battery temperature is low.
  • Page 10 Connect to TEMP SENSOR Port Battery Temperature Sensor Mount the sensor securely at a suitable location in close proximity to the battery. Replace Fuses for Solar Connector to Alligator Clips Cable The integrated 15A fuse in the Solar Connector to Alligator Clips Cable blows out when the charging current is higher than 15A.
  • Page 11 Expansion for 12V Systems z For a 100W solar suitcase, you can expand RNG-KIT-STCS100D-VOY20 to achieve 20.4V at solar output power of 200W by connecting the suitcase to a 100W 12V Foldable Solar Suitcase (RNG-KIT-STCS100D-NC) in parallel.
  • Page 12 For a 200W solar suitcase, you can expand it to achieve 40.8V at solar output power of 400W by connecting the suitcase to a 200W 12V Foldable Solar Suitcase (RNG-KIT-STCS200D-NC) in series. Recommended Accessories *Adapter Kit (14 AWG) *Solar Connector Fuse (15A) Accessories marked with “*” are available on renogy.com. 24V Battery — 9 —...
  • Page 13 Operation Power On/Off The Voyager charge controller automatically turns on when it is connected to a battery. To power it off, disconnect the solar panels from the charge controller, followed by the battery. LCD Screen The charge controller provides an intuitive LCD screen that automatically cycles through the following Main Interfaces: z PV Array Voltage: the output voltage of solar panels.
  • Page 14 Setting Buttons The Voyager charge controller provides two easy-to-use setting buttons, allowing you to check and adjust relative parameters on demand. Icon Operation Function z In the Main Interface: Cycle forwards through different display interfaces. Single press z In the Battery Voltage Interface: Cycle through different parameter values.
  • Page 15 Set Nominal and Boost Voltage for Lithium Batteries █ Setting Instructions The Voyager charge controller automatically detects 12V and 24V nominal voltages for non- lithium batteries once you set the correct battery type. For lithium batteries, manual setting of the nominal voltage is required. Step 1: In the Main Interface, press the AMP/VOLT button to navigate to the Battery Voltage interface.
  • Page 16 Parameter SLD/AGM Flooded Lithium Overvoltage Reconnect 15.0V Equalizing Voltage 14.6V 14.8V 14.2V Boost Voltage 14.2V 14.4V 14.6V (User-defined: 12V to 16V) Float Voltage 13.8V 13.8V 13.8V Boost Return Voltage 13.2V Low Voltage Disconnect 11.1V Low Voltage Reconnect 12.6V Undervoltage Warning 12.0V Undervoltage Recover 12.2V...
  • Page 17 is required to be controlled by specified voltage regulation set points for Absorption, Float, and Equalization charging stages. The Voyager charge controller uses automatic duty cycle conversion, creating pulses of current to charge the battery. The duty cycle is proportional to the difference between the sensed battery voltage and the specified voltage regulation set point.
  • Page 18 the voltage to a float level. At this point, the battery is fully charged, and any excess current is converted to heat or gas. The charger then maintains a lower voltage to offset power consumption, ensuring a full battery capacity. If a load exceeds the charge current, the charger exits float mode and returns to bulk charging.
  • Page 19 Charge controller LCD not the charge controller will not display unless there is at least 9V for 12V systems or 18V for 24V systems coming from the battery. For further assistance, contact Renogy technical support service at renogy.com/contact- — 16 —...
  • Page 20 Technical Specifications Solar Panel 100W Model 200W Model Item (RNG-KIT-STCS100D-NC) (RNG-KIT-STCS200D-NC) Maximum Power at STC 100W 200W Open Circuit Voltage (Voc) 24.3V Short Circuit Current (Isc) 5.45A 10.42A Maximum Power Voltage (Vmp) 20.4V Maximum Power Current (Imp) 4.91A 9.82A Cell Type Monocrystalline Operating Temperature −40°F to 185°F (-40°C to 85°C)
  • Page 21 You can also refer to “Series, Parallel, and Series-Parallel Connections of Batteries” at renogy.com/learning-center. █ Is there any risk that the solar suitcase will over charge my battery? The included Voyager charge controller provides an overcharge protection function to mitigate the overcharge risks.
  • Page 22 z It is recommended that all cables should not exceed 10 meters because excessively long cables result in a voltage drop. z The cable specifications listed in the user manual account for critical, less than 3% voltage drop and may not account for all configurations. z Do not expose the solar suitcase to strong electrostatic fields, strong magnetic fields, or radiation.
  • Page 23 Questionnaire Investigation To explore more possibilities of solar systems, visit Renogy Learning Center at: renogy.com/learning-center For technical questions about your product in the U.S., contact the Renogy technical support team through: renogy.com/contact-us 1(909)2877111 For technical support outside the U.S., visit the local website below: Canada ca.renogy.com...
