3B Atlas Junior Quick Start Manual

Download this manual

Quick Start Guide

Thank you for purchasing Atlas Junior – the pediatric ALS Simulator P76

Connecting Atlas Junior with REALITi 360: A Simple Guide

Scenario 1: Your existing Wi-Fi router is called iSimulate-5.0

1. Power Up: Start by turning on your iSimulate-5.0 router.

2. Wi-Fi Connection: Ensure both the REALITi Monitor iPad and

the Control iPad are connected to the iSimulate-5.0 network.

WiFi Name: iSimulate-5.0

Password: iSimulate2012

3. Turn On Atlas Junior: Locate and press the power button on

the right side of the manikin, which will automatically join the

iSimulate-5.0 network.

4. Bluetooth Settings: Disable Bluetooth on the Monitor iPad, but enable it on the Control iPad to pair with Atlas Junior's Bluetooth.

Need help?

Do you have a question about the Atlas Junior and is the answer not in the manual?

Page 1 3. Turn On Atlas Junior: Locate and press the power button on the right side of the manikin, which will automatically join the iSimulate-5.0 network. 4. Bluetooth Settings: Disable Bluetooth on the Monitor iPad, but enable it on the Control iPad to pair with Atlas Junior’s Bluetooth.
Page 2 5. Launch REALITi App: Open the REALITi app on both iPads, selecting ‘Staging’ on the Monitor and ‘Control’ on the Control iPad. 6. Connect iPads: Use the ‘Tap to Connect’ feature on the Control iPad to link both devices. If the Monitor iPad does not appear in the list, check that the Staging iPad and the Monitor iPad are both connected to the Wi-Fi network of your REALITi router: iSimulate-5.0 (both iPads must be on the same Wi-Fi network).
Page 3 9. On the Monitor iPad, the scenario or monitor selected from 10. Scan for Atlas Junior: Swipe in from the right screen edge of step 7 should appear. Start the defibrillator. the Monitor iPad to show the ‘Available Devices’. 11. Tap ‘Rescan Devices’. From the available devices select 12.
Page 4 3. Scan for Atlas Junior: swipe in from the right edge of the 4. Upon successfully connecting to ‘Atlas Junior Wi-Fi Config,’ Monitor iPad’s to reveal the ‘Available Devices’ menu. Select access the ‘Settings’. ‘Rescan Devices’ and choose ‘Atlas Junior Wi-Fi Config’ from the list by tapping ‘Connect Device.’...
