12-inch passive loudspeaker cabinet
Hide thumbs Also See for NX35:

Advertisement

Quick Links

Features:
·
350 Watt Passive Loudspeaker Cabinet
80° x 50° Custom Waveguide Horn
·
·
12-inch Neodymium Woofer
1.4-inch Aluminum Diaphragm Horn Driver (1-inch Exit)
·
Designed as Front-of-house or Monitor Loudspeaker
·
Rugged Lightweight Molded Composite Cabinet Construction
·
®
1/4-inch & Speakon
Inputs
·
All-Metal Grille, Integrated Flypoints, Handles
·
& Stand Mount
125 dB Maximum SPL
·
Overview:
The 350-watt NX35 uses a premium high-powered and highly efficient Neodymium 12-inch
woofer. The 80º x 50º horn design, patterned after the custom Waveguide horn technology used
in Yorkville's popular élite loudspeaker line is used in the NX35. An improved dual bulb CTL™
protection circuit is now used to protect the aluminum diaphragm neodymium magnetic high
frequency horn driver.
The non-resonant Polypropylene construction materials, an improved cabinet design with greatly
reinforced internal structure improves the low frequency response of the NX Series boxes, making
for a better and more balanced overall loudspeaker performance.
The modified trapezoidal shape of the NX series loudspeakers allows both active and passive versions
to function flawlessly in any PA application. The reinforced cabinet design ensures a proper up-angle
and stable footing when NX loudspeakers are employed as monitors, and allows NX cabinets to be
packed in more compact arrays or multiple cabinet clusters.
Integrated bar handles and stand mount adaptors make the lightweight NX35 loudspeaker the
ideal highly mobile live or DJ PA box. Integrated 1/4-20 flypoints and optional flyware assemblies
ensure the NX35 can be easily adapted to any installation.
Optional NX Flying Hardware
The NXF flyware is a unique and versatile U-bracket system that attaches to the integrated flypoints
on NX cabinets for a safe and secure installation. Once mounted, the cabinets can be flown at almost
any angle with a standard shackle and cable system. In addition, the cabinet can be angled up to
30 degrees left or right across the horizontal plane within the NXF U-bracket. Flying an array of NX
cabinets with ideal spacing between boxes is possible by joining multiple NXF U-Brackets and their
mounted cabinets together with a simple arraying adaptor.
NXF35U - Steel U-Bracket flying assembly
NXF35W - Wall Mounting Bracket (to attach NXF35U assembly to wall or pillar)
NXF35A - Array Link Assembly (to properly array NXF350U flying assemblies - sold in pairs)
y o r k v i l l e . c o m
NX35
NX35
12-inch Passive Loudspeaker Cabinet
NX35 Specifications:
Model
NX35
SYSTEM TYPE
Passive 2-Way
PROGRAM POWER (watts)
350
IMPEDANCE (ohms)
8
FREQ. RESPONSE (Hz +/- 3dB)
60 - 18000
SENSITIVITY (dB@1W/1m)
100
125
MAXIMUM SPL (dB)
2000
X-OVER FREQUENCY (Hz)
12" Neodymium
LF DRIVER(S)
Molded Composite
HF HORN
1.4" Aluminum
HF DRIVER
1"
HF HORN THROAT DIAMETER
80 X 50
HF DISPERSION (H° x V°)
Dual Bulb CTL™
HF PROTECTION
-
LF PROTECTION
Molded Composite
CONSTRUCTION
GRILLE
Perforated Metal
INPUTS
2 x 1/4" / 1x Speakon™
HANDLES
1 x Side Bar
FLYWARE TYPE / QUANTITY
1/4-20 x 5
FLYWARE LOCATIONS
2 Top / 1 Back / 1 Bottom
OPTIONAL ACCESSORIES
NXF Brackets
STAND MOUNT ADAPTOR
Yes
DIMENSIONS (DxWxHxBW inches)
12.25 x 16 x 26.5 x 9
DIMENSIONS (DxWxHxBW cm)
31.1 x 41.6 x 67.3 x 22.9
WEIGHT (lbs / kg)
28 / 12.7
