- Page 1 Installation Guide Lavastone Console Tabletop Ç Ç Ç Ç Ç Ç Ç Ç K-3020, K-3029 Ç Ç Ç Ç Ç Ç Ç Ç Ç Ç Ç Ç Ç Ç Ç Ç 1013618-2-...
-
Page 2: Before You Begin
Thank You For Choosing Kohler Company We appreciate your commitment to Kohler quality. Please take a few minutes to review this manual before you start installation. If you encounter any installation or performance problems, please don't hesitate to contact us. Our phone numbers and website are listed on the back cover. -
Page 3: Prepare For Installation
32 1/2" (82.6cm) from the finished floor to the top edge of the board. The center of the wall brace should be in line with the drain outlet. - Finish the wall. - Mark a centerline on the floor and wall. Kohler Co. 1013618-2-... - Page 4 2x6. - The wall clips should be 29 5/16" (74.5cm) from the floor to the lower lag bolt and 29 13/16" (75.7cm) apart, 14 7/8" (37.8cm) each side from center. Make sure the wall clips are level. 1013618-2- Kohler Co.
- Page 5 - Drill two holes in the floor, 1/4" D. x 1/2" (1.3cm) deep, for each leg. Determine the proper location according to the information in the diagram. Kohler Co. 1013618-2-...
- Page 6 Installing Octagonal Legs To The Frame - Mount legs on the frame with 3/8" bolts. Legs are interchangeable. - Secure legs with two bolts in each mounting plate. No nut is needed. The receptor holes in the frame are threaded. 1013618-2- Kohler Co.
- Page 7 - Attach top to the wall clips using bolts and nuts provided. Do not fully tighten the bolts. - Make sure top is level side to side. Adjust leg levelers as needed. - Fully tighten bolts to the wall clips. Kohler Co. 1013618-2-...
- Page 8 Do not fully tighten the bolts. Slide the clips to the side so they do not impede the lavatory when it is lifted into place. - Install the drain assembly to the lavatory. Follow the directions provided with the drain assembly. 1013618-2- Kohler Co.
-
Page 9: Finish Installation
- Allow RTV sealant to cure for 24 hours before using the lavatory. 9. Finish Installation - Finish the drain installation and trap connections. - Finish the faucet assembly following the installation instructions provided with the faucet assembly. - Make final supply connections, run water and check for leaks. Kohler Co. 1013618-2-...
