YORKVILLE COLISEUM CM570 Brochure

Features:
· 25-watt 5-inch Ceiling Mount Speaker
· Coaxial 6.5-inch woofer and 3/4-inch
titanium coated tweeter
· 70-volt taps at 5, 10 or 20-watts
· Optional 8-ohm (25 watt) Operation
150 to 20,000 Hz Frequency Response
·
Wire Harness Input
·
Injected Molded ABS Plastic Construction
·
Two-year Unconditional Warranty*
·
*Warrany valid in Canada and the United States only
Overview:
The CM5/70 is a 25-watt 5-inch high performance ceiling mount loudspeaker. Ideal for any
background music or paging system where superior sound quality is a priority, this speaker is
made for louder club or restaurant / retail environments.
Built in 70-volt taps at 5, 10 or 20 watts as well as optional 8-ohm (25 watt) operation means
that virtually any amplification or paging system, including the Coliseum CA1 or CA1T can drive
the CM5/70.
Coliseum CM5/70
Coliseum CM5/70
y o r k v i l l e . c o m
25-watt Ceiling Speaker 25-watt Ceiling Speaker
CM5/70 Specifications:
CM5/70
Model
Ceiling Speaker
TYPE
Full Range Tile Mount
SYSTEM
30
PROGRAM POWER (watts)
70V Transformer / Passive 8Ω
IMPEDANCE (ohms)
SENSITIVITY (dB @ 1W/1m) 91
FREQ. RESP. (+/-3dB) 150 - 20k
WOOFER 6"
TWEETER -
INPUTS Wire Harness
CABINET CONSTRUCTION Injection Molded ABS Plastic
STANDARD COLOR White
OPTIONAL COLOR -
STANDARD HARDWARE -
OPTIONAL HARDWARE -
70V TRANSFORMER TAPS 5W / 10W / 20W
DIMENSIONS (DxWxH inches) 8 (Diameter) x 3 (Depth)
DIMENSIONS (DxWxH cm) 20 (Diameter) x 7.6 (Depth)
WEIGHT (lbs / kg) 3.0 / 1.4
