YORKVILLE COLISEUM C110 Brochure

Features:
· 40 Watt Mini Series Speaker
· 90° x 90° HF Driver
· 5-inch Woofer with Tweeter
· Cabinet Is Available In Either a White (C110W) or
Black (C110) Finish
85 to 19,000 Hz Frequency Response
·
70-volt 'Matching Transformer'
·
Binding Post and 1/4" Phone Connectors
·
Injection Molded, ABS Plastic Cabinet Construction
·
Two-year Unconditional Warranty*
·
*Warrany valid in Canada and the United States only
Overview:
The Coliseum C110 is a high quality, weather resistant speaker which features specially treated drivers in a rugged
plastic enclosure. It is well-suited for many applications including commercial installations, home theaters, home
stereos, reference monitors and personal stage monitors. The C110 is a bass reflex enclosure with a tuned port
and a 5-inch woofer whose computer-optimized design gives improved bass performance over conventional 5-inch
woofer enclosures. With a power rating of 40 watts of continuous music power the C110 is accurate from 85Hz to
19kHz with an efficiency of 92dB.
The C110 features an internal 70-volt 'matching transformer' which allows multiple C110s to be connected
together without danger of overloading the power amplifier due to impedance drop. The user has a choice of three
sensitivity settings (10w, 20w, 30w or off) selected via a rotary switch located on the rear panel of the
speaker, allowing convenient adjustment of the relative volumes of multiple interconnected cabinets.
A wide variety of mounting options are available using the four integral screw-slots or the provided metal L-bracket
which allows it to be angled up, down or sideways depending on the mounting orientation. The C110 is available in
a low-reflectance black or white finish with a matching, perforated metal grille and can be painted to match its
surroundings.
Coliseum C110
Coliseum C110
y o r k v i l l e . c o m
5-inch Mini Series Speaker 5-inch Mini Series Speaker
C110 Specifications:
Model C110
TYPE 2-Way, Tuned Port
SYSTEM Bass Reflex
PROGRAM POWER (watts) 40
IMPEDANCE (ohms) 70V Transformer / Passive 8Ω
SENSITIVITY (dB @ 1W/1m) 92
FREQ. RESP. (+/-3dB) 85 - 19k
WOOFER 5"
TWEETER Mylar
INPUTS Screw Terminals
CABINET CONSTRUCTION Injection Molded ABS Plastic
STANDARD COLOR Black
OPTIONAL COLOR White (C110W)
STANDARD HARDWARE Rear Key Hole Mounts (4) /
L-Bracket
OPTIONAL HARDWARE -
70V TRANSFORMER TAPS 10W / 20W / 30W / 8R
DIMENSIONS (DxWxH inches) 5.5 x 6.26 x 8.9
DIMENSIONS (DxWxH cm) 14 x 15.9 x 22.6
WEIGHT (lbs / kg) 3.8 / 1.7
