- Page 1 Yorkville 550 WATT POWERED LOUDSPEAKER ENCLOSURE TYPE: YS1002 OWNER’S MANUAL MANUEL de L’UTILISATEUR Manual-Owners-nx550p-1v40.pdf...
-
Page 2: Instructions Pertaining To Arisk Of Fire, Electric Shock, Or Injury To Persons
IMPORTANT SAFETY INSTRUCTIONS INSTRUCTIONS PERTAINING TO A INSTRUCTIONS RELATIVES AU RISQUE RISK OF FIRE, ELECTRIC SHOCK, DE FEU, CHOC ÉLECTRIQUE, OU OR INJURY TO PERSONS BLESSURES AUX PERSONNES CAUTION: AVIS: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO AFIN DE REDUIRE LES RISQUE DE CHOC ELECTRIQUE, N’ENLEVEZ PAS LE COUVERT (OU LE PANNEAU ARRIERE) NOT REMOVE COVER (OR BACK). - Page 3 Using the popular nx20 as a base, adding 550 Watts of bi-amped power and topping-it-off with advanced signal processing, the NX550P is destined to set the new standard for active loudspeakers. The woofer amplifier, or low frequency amplifier, amp delivers over 450 Watts to the 12 inch neodymium woofer.
-
Page 4: Operation
The Link Jacks are the correct input to use when driving • High efficiency, high tech, 550 Watt Bi- the NX550P from an external mixer. The Link amped power module Jacks operate at line level (+4 dBv) to achieve •... -
Page 5: Mic Control
Fuse should be used! A much larger number of cabinets may be used with the NX550P mixers The mains fuse should never blow even in disabled on the additional cabinets. extreme operating conditions. A blown fuse will... - Page 6 550 WATT POWERED LOUDSPEAKER ENCLOSURE Specifications 2-Way System Type Active Active or Passive Program Power (Watts) Self Powered Biampable Biamp Operation Only Max SPL (dB) 45 - 18k Frequency Response (Hz +/- 3db) 2300 Crossover Frequency (Hz) 12 inch / 1 inch Driver Configuration 1 inch Throat, Ceramic Magnet, 1 inch Mylar voicecoil HF Driver(s)
- Page 7 Enceinte de haut-parleurs pleine bande, amplifiée NX550P Fondé sur la populaire nx20, la NX550P, avec ses 550 watts de puissance en bi-amplification et un traitement de signal perfectionné, est destiné à établir un nouveau standard pour les enceintes de haut-parleur actives. L'amplificateur des fréquences graves offre 450 watts acheminés au woofer de 12 pouce.
-
Page 8: Caractéristiques
• Module d'amplification de 550 watts plus grande gamme d'ajustement de niveau hautement efficace à la fine pointe de la que ce qu'offre la NX550P ( par exemple technologie si un cabinet dans le regroupement doit fonctionner à un niveau réduit). - Page 9 Pente de Diminution des armés et réduisent les niveaux des signaux. Fréquences Graves Il n'y a pas de problème à opérer la NX550P avec le limiteur actif. Assurez-vous toutefois Lors d'opération avec subwoofer, le que la DEL clip ne s'illumine pas constamment.
- Page 10 550 WATT POWERED LOUDSPEAKER ENCLOSURE Spécifications 2-Voies Type De Système Active Active ou Passive Puissance nominale (Watts) Autoalimenté Double Amplificateurs Opération à double amplificateur seulement Pression sonore Maximum (dB) 45 - 18k Réponse en Fréquence (Hz +/- 3db) 2300 Fréquence de croisement (Hz) 12 pouces / 1 pouce Configuration De Haut-Parleurs George de 1 pouce, Aimant en Céramique, Bobine mobile...
- Page 11 First nx550p ONLY! USE LINK TO MORE NX550Ps note: each enclosure can be adjusted ±6dB individually ONE MICROPHONE, MULTIPLE NX550Ps MIXER OUTPUT TO LINK MIXER OUTPUT TO LINK note: Turn MIXER option OFF on nx550p's STEREO P.A., with EXTERNAL MIXER...
- Page 12 Turn MIXER option ON on nx550p ONE MIC and ONE CD PLAYER TO MIC INPUT TO MIC INPUT TO CD/LINE INPUT TO LINK CD PLAYER note: Turn MIXER option ON on both nx550p's TWO MICS and ONE CD PLAYER...
- Page 13 TO MIC INPUT LINK OUT TO LINK TO CD/LINE INPUT LINK OUT *MIXER LINK OUT *MIXER OPTION OPTION CD PLAYER TO LINE LEVEL TO LINE LEVEL SUB INPUT SUB INPUT SUBWOOFER SUBWOOFER MIC and CD PLAYER, with POWERED SUBWOOFERs...
- Page 14 550 WATT POWERED LOUDSPEAKER ENCLOSURE LINK +24 PHANTOM MIC LEVEL MIXER ON / OFF LINE / CD LEVEL LINE / CD NX550P LEVEL NOTES: ALL LINK CONNECTIONS FUNCTION AS INPUTS OR OUTPUTS. EXTERNAL MIXERS CONNECT TO LINK INPUTS Yorkville...
-
Page 15: Eyebolt Installation
CALLING ATM FLY-WARES TECHNICAL SERVICES IN THE UNITED STATES AT (310)639-8282 MONDAY THROUGH FRIDAY FROM 9 AM TO 6 PM (PST) OR FAX AT (310)639-8284. YORKVILLE SOUND MAKES NO CLAIMS AS TO THE SAFETY OF THE ENCLOSURES IF RECOMMENDED LOAD LIMITS AND HARDWARE ARE NOT STRICTLY ADHERED TO. NOR DOES IT MAKE ANY SAFETY CLAIMS TO THE RESULTANT INSTALLATION. - Page 16 SUGGÉRONS D'APPELER LE SERVICE TECHNIQUE DE ATM FLY-WARE AUX ETATS-UNIS AU (310)639-8282 DU LUNDI AU VENDREDI DE 9 AM À 6 PM (HSP) OU PAR FAX AU (310)639-8284. YORKVILLE SOUND NE GARANTIE PAS UNE UTILISATION SÉCURITAIRE DES ENCEINTES SI LES LIMITES DE CHARGE RECOMMANDÉES NE SONT PAS RESPECTÉES ET SI VOUS N'ADHÉREZ PAS STRICTEMENT À...
- Page 17 Unlimited Warranty Yorkville's two and ten-year unlimited warranty on this product is transferable and does not require registration with Yorkville Sound or your dealer. If this product should fail for any reason within two years of the original purchase date (ten years for the wooden enclosure), simply return it to your Yorkville dealer with original proof of purchase and it will be repaired free of charge.
- Page 18 WORLD HEADQUARTERS CANADA U.S.A. Yorkville Sound Yorkville Sound Inc. 550 Granite Court 4625 Witmer Industrial Estate Pickering, Ontario Niagara Falls, New York L1W-3Y8 CANADA 14305 USA Voice: (905) 837-8481 Voice: (716) 297-2920 Fax: (905) 837-8746 Fax: (716) 297-3689...
