YORKVILLE COLISEUM C165W Brochure

Features:
· 60-watt 6.5-inch Ceiling Mount Speaker
· Coaxial 6.5-inch woofer and 3/4-inch
titanium coated tweeter
· 70-volt taps at 7.5, 15, 30 or 60-watts
· 100-volt taps at 15, 30 or 60-watts
100 to 20,000 Hz Frequency Response
·
Screw Terminal Inputs
·
Aluminum / ABS Plastic Cabinet Construction
·
Two-year Unconditional Warranty*
·
*Warrany valid in Canada and the United States only
Overview:
The C165W is a 60-watt 6.5-inch high performance ceiling mount loudspeaker. Ideal for any
background music or paging system where superior sound quality is a priority, this speaker is
made for louder club or restaurant / retail environments. Featuring an innovative design and
employing high quality materials, the C165W maintains excellent performance from a compact
ceiling loudspeaker. The C165W contains a coaxial 6.5-inch woofer and 3/4-inch titanium
coated tweeter. Built in 70-volt taps at 7.5, 15, 30 or 60-watt operation means that high
fidelity full range sound can be achieved over an extremely wide coverage pattern area. Virtually
any 70-volt amplification or paging system, including the Coliseum CA1 or CA1T can drive the
C165W.
Coliseum Mini Series Overview:
After years of experience with enclosure design, it was logical for Yorkville to apply its knowledge
to the design of a range of speaker cabinets that have been specifically designed for small-scale
installation purposes. The knowledge that we gained while developing the TX, élite, Pulse and
Performance series enclosures was applied to yield a series of practical yet cost effective
installation enclosures.
All enclosures and grilles can be easily refinished and many have the option of coming in either a
black or white finish. Designed for fixed installation or live use, the Coliseum Mini Series like the
C110, C170 and WM5T have a complete list of features that make them an extremely good value.
The practically configured C110 incorporates a multi-tap 70V transformer for fixed installations
while the waterproof C120 is perfect for indoor or outdoor application as a loudspeaker or can be
mounted on a microphone stand as a mini monitor. The WM5T in-wall speaker is a clean, high
performance solution that is sure to solve space constraint issues. Basic mounting hardware is
included with most models.
Coliseum C165W
Coliseum C165W
y o r k v i l l e . c o m
100-watt Ceiling Speaker 100-watt Ceiling Speaker
C165W Specifications:
Model C165W
TYPE Ceiling Speaker
SYSTEM Full Range 'Pot Light'
PROGRAM POWER (watts) 60
IMPEDANCE (ohms) 70V Transformer / Passive 8Ω
SENSITIVITY (dB @ 1W/1m) 92
FREQ. RESP. (+/-3dB) 100 - 20k
WOOFER 6"
TWEETER 3/4"
INPUTS Screw Terminal
CABINET CONSTRUCTION Aluminum / ABS Plastic
STANDARD COLOR White
OPTIONAL COLOR -
STANDARD HARDWARE Ceiling Mount Clips
OPTIONAL HARDWARE -
70V TRANSFORMER TAPS 2.5W / 5W / 10W
DIMENSIONS (DxWxH inches) 10 (Diameter) x 7 (Depth)
DIMENSIONS (DxWxH cm) 25 (Diameter) x 18 (Depth)
WEIGHT (lbs / kg) 7.3 / 3.3
