Features:
· 10 Watt Full Range 'Pot Light' Speaker
· Built In 70-volt Transformer and Taps
· 4-inch Woofer
· Includes Ceiling Mount Clips
100 to 16,000 Hz Frequency Response
·
Solder Lug Inputs
·
ABS Plastic Cabinet Construction
·
Two-year Unconditional Warranty*
·
*Warrany valid in Canada and the United States only
Overview:
Ideal for any paging or background music system, the C160W is a 10-watt, 4-inch diameter
flush mount-ceiling speaker designed specifically for quick and simple installation in office
and retail environments.
The C160W has built in 70-volt transformer and taps, and can operate at 2.5 watts, 5 or 10
watts. It also features an efficiency of 92dB (1 W/m) and a frequency response of 100 - 16kHz.
Rugged ABS plastic construction in a 'pot light' format with an all metal grille make the C160W
ideal for any drywall or tile drop ceiling mount application. The C160W can be easily installed
and driven by any 70-volt amplification system, including the Coliseum CA1, CA1T or CA12.
Coliseum Mini Series Overview:
After years of experience with enclosure design, it was logical for Yorkville to apply its knowledge
to the design of a range of speaker cabinets that have been specifically designed for small-scale
installation purposes. The knowledge that we gained while developing the TX, élite, Pulse and
Performance series enclosures was applied to yield a series of practical yet cost effective
installation enclosures.
All enclosures and grilles can be easily refinished and many have the option of coming in either a
black or white finish. Designed for fixed installation or live use, the Coliseum Mini Series like the
C110, C170 and WM5T have a complete list of features that make them an extremely good value.
The practically configured C110 incorporates a multi-tap 70V transformer for fixed installations
while the waterproof C120 is perfect for indoor or outdoor application as a loudspeaker or can be
mounted on a microphone stand as a mini monitor. The WM5T in-wall speaker is a clean, high
performance solution that is sure to solve space constraint issues. Basic mounting hardware is
included with most models.
Coliseum Mini Series Characteristics
Full range of sub-compact installation specific models ranging from
I
5 watt wall speakers to 100 watt professional quality cabinets
70V option available on most models
I
Attractive and discrete white paintable finish
I
A variety of custom installation hardware available for all models
I
Coliseum C160W
Coliseum C160W
y o r k v i l l e . c o m
Pot Light Ceiling Speaker
Pot Light Ceiling Speaker
C160W Specifications:
Model
C160W
Ceiling Speaker
TYPE
Full Range 'Pot Light'
SYSTEM
10
PROGRAM POWER (watts)
70V Transformer / Passive 8Ω
IMPEDANCE (ohms)
92
SENSITIVITY (dB @ 1W/1m)
100 - 16k
FREQ. RESP. (+/-3dB)
4"
WOOFER
TWEETER
-
INPUTS
Solder Lug
CABINET CONSTRUCTION
Injection Molded ABS Plastic
STANDARD COLOR
White
OPTIONAL COLOR
-
STANDARD HARDWARE
Ceiling Mount Clips
OPTIONAL HARDWARE
-
70V TRANSFORMER TAPS
2.5W / 5W / 10W
DIMENSIONS (DxWxH inches)
5.6 (Diameter) x 4.8 (Depth)
DIMENSIONS (DxWxH cm)
14.2 (Diameter) x 12 (Depth)
WEIGHT (lbs / kg)
3 / 1.4
