Product End-of-Life Disassembly Instructions
Product Category:
Storage
Marketing Name / Model
HPE MSA 2070 Storage
HPE MSA 2072 Storage
Purpose: The document is intended for use by end-of-life recyclers or treatment facilities. It provides the basic instructions
for the disassembly of HPE products to remove components and materials requiring selective treatment, as defined by
Directive 2012/19/EU of the European Parliament and of the Council on Waste Electrical and Electronic Equipment
(WEEE). Detailed removal instructions are available in the server Maintenance and Service Guide on the
Support
Center.
1.0 Items Requiring Selective Treatment
1.1 The items listed below are classified as requiring selective treatment.
1.2 Quantities vary by product configuration
Item Description
Printed Circuit Boards (PCB) or Printed Circuit
Assemblies (PCA)
Batteries
Mercury-containing components
Liquid Crystal Displays (LCD) with a surface
greater than 100 sq cm
Cathode Ray Tubes (CRT)
Capacitors / condensers (Containing PCB/PCT)
Electrolytic Capacitors / Condensers measuring
greater than 2.5 cm in diameter or height
External electrical cables and cords
MF877-00
Template Revision F, 2-December-2024
Copyright 2024 Hewlett Packard Enterprise Development LP
HPE instructions for this template are available at
Notes
With a surface greater than 10 sq cm
2 in each of 2 I/O modules,
1 in each of 2 power cooling modules
1 on the chassis midplane
All types including standard alkaline and lithium
coin or button style batteries.
1 coin battery in each of 2 I/O modules
For example, mercury in lamps, display backlights,
scanner lamps, switches, batteries
Includes background illuminated displays with gas
discharge lamps
Quantity varies by product configuration and power
supply model selected
1 capacitor in each of 2 power supplies
1 supercapacitor in each of 2 I/O modules
Quantity depends on number of power supplies,
networking devices, and I/O devices
1 power cord for each 2 Power supplies
2 sas expansion cables per storage system
HPE Product
MF877-01
Quantity
of items
included
in product
7
2
0
0
0
0
4
4
Page 1
