For spare parts drawings refer to the document "LIST OF COMPONENTS" to be requested from the manufacturer.
• For any further information please contact your local dealer or call:
Phone (+39) 051 6781511 - Fax (+39) 051 846349 - e-mail: aftersales.emea@vsgdover.com
7109-M008-00
TYRE-CHANGER SERIES
AIKIDO.EVO
INSTRUCTION MANUAL
Applicable to the following models
ROT.AIKID.200235
ROT.AIKID.200075
ROT.AIKID.200099
TRANSLATION OF THE
EN
ORIGINAL INSTRUCTIONS
VEHICLE SERVICE GROUP ITALY S.r.l
Via Filippo Brunelleschi, 9 - 44020 Ostellato - Ferrara - Italy
7109-M008-00 - Rev. n. 00 (04/2024)
