Instruction
Manual
X-Series Wideband UEGO AFR Gauge
STOP! - READ THIS BEFORE INSTALL OR USE!
WARNING:
THIS INSTALLATION MAY REQUIRE WELDING OR INTEGRATION INTO A VEHICLE'S ELECTRICAL SYSTEM. DAMAGE
TO SENSITIVE ELECTRONICS, FIRE, OR EXPLOSION MAY OCCUR IF PROPER PRECAUTION IS NOT TAKEN. IF THERE
IS ANY DOUBT, DO NOT ATTEMPT THE INSTALLATION AND CONSULT A PROFESSIONAL.
NOTE: IT IS THE RESPONSIBILITY OF THE ENGINE TUNER TO ULTIMATELY CONFIRM THE CALIBRATION USE FOR
ANY PARTICULAR ENGINE IS SAFE FOR ITS INTENDED USE. AEM HOLDS NO RESPONSIBILITY FOR ANY ENGINE
DAMAGE THAT RESULTS FROM THE MISUSE OF THIS PRODUCT.
The 52mm (2-1/16") AEM X-Series Universal Exhaust Gas Oxygen (UEGO) Gauge features a four digit central readout and
sweeping 24-color-coded LED display, providing immediate reference to the engine air fuel ratio (or lambda) in real-time.
The AEM gauge is ideal for all vehicles including carbureted applications and engine dynamometers. An OBD-II output can
be used in conjunction with CAN based OBD-II ports found in 2008 and newer vehicles to replace or supplement stock O2
sensors with the fast LSU4.9 sensor for more accurate mixture control. An EFILive Flashscan V2 output is also available
via the OBD-II connection. A 0-5V analog output and serial output is included and can be used with data loggers or
aftermarket ECUs including the AEM Infinity Engine Management System.
The X-Series Digital Wideband technology is US Patent #9,575,030.
Features
·
X-Digital Technology
·
Free air or resistor trim calibration modes
·
Fast response, 20ms typical
·
2-1/16" / 52mm outer diameter mounting
·
8.0:1 to 20.0:1 AFR / 0.55 to 2.00 Lambda
·
Configurable 3 or 4 digit precision display mode
·
Lambda, AFR, O2 % display modes with reversible
faceplate
·
Black bezel/faceplate supplied; Silver/white available
as optional purchase
·
Locking connectors
·
Supports vehicle/system voltages up to 16V
·
Supports Bosch LSU4.9 Sensor
·
OBD-II Output; CAN based compatible with 2008 or
newer vehicles
o Daisy-chain up to eight (8) 30-0334 gauges
·
EFILive Flashscan V2 Output (V8 Software: V8.2.5,
Build 316 or newer)
o Daisy-chain up to two (2) 30-0334 gauges
·
0-5V Analog Output
·
Serial RS-232 Output
AEM Performance Electronics, 2205 126th Street Unit A, Hawthorne, CA 90250 - Phone: (310) 484-2322
P/N 30-0334
w/ OBD CAN Integration
Bosch LSU4.9
http://www.aemelectronics.com
KIT CONTENTS
PN
10-0334 INST, X-SERIES UEGO GAUGE
35-0334 GAUGE ASSY, X-SERIES AFR GAUGE
- RED INSULATED BUTT CONNECTORS (4)
35-4005 WELD-IN BUNG,02 SENSOR 1214 MILD STEEL
35-8618 NUT, KNURLED, M4x0.7 (2)
35-8614 BRACKET, X-SERIES GAUGE
35-3459 Cable, X Gauge OBD2 Pass THRU
35-3427 SENSOR CABLE, X-SERIES GAUGE LSU4.9
35-8617 RUBBER BAND, X-SERIES GAUGE
35-2003 SENSOR, WIDEBAND UEGO BOSCH LSU 4.9
*OPTIONAL* ACCESSORIES
PN
30-0300-ACC BEZEL, X-SERIES GAUGE SILVER
FACEPLATE, X-SERIES AFR WHITE
30-2355-200 NO WELD UEGO CLAMP KIT, 1.75" to 2.00"
30-2355-250 NO WELD UEGO CLAMP KIT, 2.25" to 2.50"
30-2355-300 NO WELD UEGO CLAMP KIT, 2.75" to 3.00"
30-2355-350 NO WELD UEGO CLAMP KIT, 3.25" to 3.50"
30-4008 WELD-IN FINNED BUNG, O2 LONG, STAINLESS STEEL
35-4001
Description
Description
BUNG PLUG,02 SENSOR
