ESP Switchboard Configuration via ESP Controller Section 3: Switchboard settings screens
Section 3: Switchboard settings screens
3.1 SWITCHBOARD MENUS
The following menus are available for Switchboard when the Power Analyzer Card is inserted into Controller
and none of the Controller communication ports, nor the slots' function is configured to VSD.
1. Summary
2. Backspin
3. Alarms
4. IO
5. Configure
6. Startup Chart
Figure 3.1: Summary Screen
