Moen AURA SW1631N Installation Instructions Manual

Wall mount easy smart integrated toilet

Advertisement

Quick Links

坐便器(轻智能壁挂坐便器)
奥拉系列
Wall Mount Easy Smart
Integrated Toilet
AURA Series
如需安装支持,配件丢失或替换等,请联系本公司。
对于中国大陆以外的市场,请咨询当地经销商。
(中国大陆) 400-630-8866
(中国大陆) www.moen.cn
(中国大陆以外) www.moen.com.hk
For installation support, missing or replacing
parts, etc., please contact the company. For
consumers in markets outside the Chinese
mainland, please consult the local dealer.
(Chinese Mainland) 400-630-8866
(Chinese Mainland) www.moen.cn
(Outside Chinese Mainland) www.moen.com.hk
推荐工具
为了安全和让安装和替换变得容易,本公司建议
您使用以下工具:
HELPFUL TOOLS
For safety and ease of installation and
replacement, the company recommends the use
of the following tools:
锉刀
直尺
Ruler
File
锯子
剪线钳
Saw
Wire Nippers
水平尺
密封胶
Level Ruler
Sealant
INS14516 - 11/28

Advertisement

loading
Need help?

Need help?

Do you have a question about the AURA SW1631N and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Moen AURA SW1631N

  • Page 1 For consumers in markets outside the Chinese mainland, please consult the local dealer. (Chinese Mainland) 400-630-8866 (Chinese Mainland) www.moen.cn (Outside Chinese Mainland) www.moen.com.hk 推荐工具 为了安全和让安装和替换变得容易,本公司建议 您使用以下工具: HELPFUL TOOLS For safety and ease of installation and...
  • Page 2 功能表 Function Table 功能分类 型号 Model SW1631N Functional 功能 Function 白色 White Classification 虹吸冲水 Siphon Flush 预润净瓷 Pre-flush 冲水类 易洁釉面 Easy Clean Glaze Washing 离座冲水 Automatic Flush 侧边键冲水 Side Button Flush 清洗类 Cleaning Pre-filter with SUS Screen 前置过滤(不锈钢网) 座圈加热 Seat Heating 抗菌座圈...
  • Page 3 产品整体图 Product Overview 安全须知标贴 Caution Label 座盖 Lid 侧边按键 Side Button 感应区域 Seat Sensor...
  • Page 4 EVA 缓冲垫 角阀 Installation Instructions, EVA Cushion Angle Valve Hazardous Substance List 完工墙面 The finished wall 180mm 963mm 596mm 300mm 383mm 423mm 170mm 15mm 388mm 530mm 俯视图 Top View...
  • Page 5: Precautions Before Installation

    产品安装 Product Installation Precautions before Installation 一. 安装前注意事项 The following precautions are related to safety and may cause 以下注意事项均与安全密切相关,根据不同情况可能造成重大 major consequences according to different situations. Please 后果,请您务必遵守。 be sure to observe them. Warning: If you ignore this warning and misuse it, it may 警告:如果无视警告而误操作时,有可能造成人员伤亡。...
  • Page 6 二. 安装前确认 Pre-installation Confirmation 单位:mm Unit:mm 固定安装孔 Fixation Hole 以前的供水角阀 The Previous Angle Valve 排污孔 Drain Hole 安装好固定架后,露出尺寸参考图示(固定架安装请详见固定架安装说明书)。 After installing the fixture, the size reference diagram is exposed (please refer to the fixture installation manual for details).
  • Page 7 单位:mm Unit:mm 410±3 必须接地 Must be Grounded 小心触电 Caution Electricity EVA 缓冲垫 EVA Cushion 固定安装孔 Fixed Mounting Hole 外置防水插座 供水角阀 420±3 External Waterproof Socket Angle Valve 400-700 200-300 水平地面 Level Ground 在墙壁预留位置套上EVA 缓冲垫,EVA 缓冲垫的固定安装孔对准固定架的固定螺栓插入,与水箱的排污孔对齐;拆卸以前的供水角阀, 安装上所配置的供水角阀。 Put an EVA cushion on the reserved position on the wall, and the fixed mounting hole of the EVA cushion is inserted into the fixing bolt of the fixing frame and aligned with the sewage hole of the water tank;...
  • Page 8 三.安装步骤 Installation Steps 插座 Socket 60mm 在墙上预先安装一个220V/50Hz的插座。 完成示意图 Pre-install a 220V/50Hz socket on the wall. Complete The Diagram Note: If you need to install a hidden power supply, please contact your local dealer. 供水角阀 Angle Valve EVA 缓冲垫 EVA Cushion 排污孔...
  • Page 9 水平尺 Level Ruler 缓冲垫片 Cushion Gaskets 平垫圈 Flat Washer 螺母(M12) Nut (M12) 用水平尺使产品保持水平位置,然后将缓冲垫片、平垫圈和螺母 抽出泡沫垫并切掉多余的EVA 缓冲垫,再沿陶瓷边缘打上密封胶。 Pull out the foam pad and cut off excess EVA cushion, and apply 按照上图顺序安装将马桶固定在墙上。 Hold the product in a horizontal position by level ruler, then sealant along the edge of the ceramic.
  • Page 10 复位开关 Reset Switch 漏电测试键 Leakage Test Key 指示灯 Indicator Light 连接电源 1.连接地线。 2.电源插头插入AC 220V的插座内。 3.确认是否接通电源。 Connect the power supply 1.Connect the ground wire. 2.Plug the power plug into the socket of AC 220V. 3.Make sure the power is switched on. 通电检查...
  • Page 11: Safety Precaution

    使用说明 Instructions for Use Safety Precaution 一. 安全注意事项 Read All Instructions before Use 使用前请详细阅读 Thanks for purchasing our products.In order to make a better 感谢您购买本公司的产品,为了您更好的享用本产品,请详 use of the product,please read this manual carefully and install 细阅读本说明书后正确使用,阅读完毕后请妥善保管。 the product correctly.Keep this manual properly for future 此处列出的注意事项是与安全相关的重要内容,根据不同情...
  • Page 12 WARNING 警告 本产品必须可靠接地。 请勿将点燃的香烟及其他燃烧物投入坐便器内。 ※否则可能会因故障或短路而导致触电。 ※否则容易发生火灾。 Do not throw the lit cigarettes or other burning things ※当不确定时,请联系电器安装公司。 into the toilet. The product should be electrically grounded appropriately. Otherwise fire hazard may occur. Not doing so may cause electric shock due to malfunction ※...
  • Page 13 请勿把电源线随意拉拽、破损、强行弯曲和 儿童不应玩耍本产品。 扭曲、拉伸、卷曲、打捆、承重、过度夹挤。 ※否则可能造成人身伤害。 Do not leave your children playing with the product. ※否则电源线破损会导致触电或火灾。 Do not pull, damage, bend by force, twist, tense, curl, knot, Doing so may cause the children get injured. ※ crimp the cord. ※ Doing so would cause the broken of the cord, which would leads electric shock or fire hazard.
  • Page 14 请勿向坐便器或遥控器内部加水或清洁剂。 请避免安装在潮湿及易浸到水的浴室内使用。 请勿用水或清洁剂弄湿坐便器及电源插头。 请勿将水喷淋到本产品上面或用水冲洗,以 ※否则可能会有触电和发生火灾的危险。 防内部进水,造成损失。 Do not add water or detergent to the toilet bowl or remote ※否则容易引发触电、火灾。 controller. Do not wet the toilet bowl or power plug with water Please do not install it in the wet environment or in the or detergent.
  • Page 15 二. 侧面按键的使用说明 Side Button Use Instructions 冲水 Flush 按压此键启动大冲水。 快速按压此键2次启动小冲水。 长按此键3秒以上开启/关闭离座冲水功能。当离座冲水开启时,人离开坐便器5秒后,自动冲洗 坐便器一次。 注意:当人离开坐便器时,使用按键冲洗过坐便器,人离开后离座冲水将不再启动。 Press this button to start full flush. Press this button quickly twice to start a small flush. Press and hold this button for more than 3 seconds to turn on/off the automatic flushing function. When the automatic flush is turned on, the person leaves the toilet for 5 seconds and flushes automatically toilet seat once.
  • Page 16 休眠模式Automatic Power Off The system detects that there is no operation for 24 hours, and it 系统检测连续24小时无任何操作,将自动关闭座圈加热。 will automatically turn off the seat ring heating function. 当您和家人外出旅游或者出差时,系统检测连续24小时无任何 ● When you and your family are traveling or on business, the 操作,将自动关闭座圈加热。 ●...
  • Page 17 电源开关 Power Switch 故障现象 故障分析 故障处理 Failure Phenomenon Failure Analysis Troubleshooting 检查是否有电/插座是否松动。 请检查电路。 Check if there is electricity / if the socket is loose. Please check the circuit. 检查产品电源是否开启(电源指示灯未亮)。 按下电源/停止键,坐便器的电源指示灯点亮。 Check whether the power of the product is turned on Press the power/stop button, the power indicator 产品不工作。...
  • Page 18 其他 Other 故障现象 故障分析 故障处理 Failure Phenomenon Failure Analysis Troubleshooting 座盖/座圈下落过快。 阻尼缓降功能失效。 请专业人员进行维修。 Seat cover/seat ring Damping slow down function fails. Ask a professional for repair. falling too fast. 额定电压 220V Rated Voltage 额定频率 Rated Frequency 额定消耗功率 100W Rated Power Consumption 使用环境温度...
  • Page 20: Product Limited Warranty

    PRODUCT LIMITED WARRANTY 产品售后保修条款 We offer limited warranty and lifetime maintenance for 本产品是在高质量标准及生产工艺下制造的,本公司承诺为消 the products, which are all manufactured with high 费者购买的产品提供有期限免费保修及终身维修服务。 standards of workmanship. 材质为陶瓷的部件免费保修期为5年,非陶瓷材质部件,如智 The free warranty period for ceramic parts is 5 years, 能盖板、智能一体机的盖板组件、水箱内的水件、冲洗阀、坐 non-ceramic parts, such as the smart toilet seat, water 便器盖板等免费保修期为3年,均自消费者购买日(以本产品...
